Agora Models JAGUAR E-TYPE Manuel
STAGE 32: STEERING SYSTEM COMPONENTS
STAGE 33: COOLING SYSTEM COMPONENTS
STAGE 34: THE FRONT BULKHEAD
STAGE 35: BULKHEAD FITTINGS
AND PIPEWORK
STAGE 36: BULKHEAD FITTINGS
STAGE 37: ENGINE BAY FITTINGS
STAGE 38: RIGHT FRONT WHEEL
STAGE 39: RIGHT FRONT WHEEL
STAGE 40: RIGHT FRONT WHEEL
Pack 05
BUILD INSTRUCTIONS
AGORAMODELS JAGUAR E-TYPE
2
Spare screws are included with each part. Occasionally, you may be instructed to keep spare or
unused screws for a later stage. Keep these spares in a safe place and label them correctly.
Please make sure you don’t mix up the screws. They look quite similar, but the threads do vary
slightly. Using the wrong screws may damage the parts.
When securing parts together using multiple screws, fit each screw loosely to ensure all the
parts are correctly aligned before gently tightening them firmly, but not overtight, in the order
in which you placed them.
The screwdriver can be magnetized by stroking it with a magnet (fridge magnet, etc.) enabling
it to hold the screws and make assembly easier.
If a screw is tight going into a metal part, do not force it as you may shear the head off. Remove
it and put a tiny smear of Vaseline, soap or light oil on the thread. That will lubricate it and make
it easier to drive home.
During the course of this build, you will receive many pieces that you will assemble immediately
– following the instructions in the corresponding stage – and other pieces that you should store
safely to one side, for use in future assembly stages.
Left and Right! When building your Jaguar, the left or right hand side refers to each side as you
are sitting in the car.
WARNING: Some parts are assembled using magnets. These magnets can cause serious injury
if they are swallowed. Keep away from children. If you suspect a magnet has been swallowed,
seek medical help straight away.
Advice from the experts
!
AGORAMODELS JAGUAR E-TYPE
3
Name
Steering column assembly Steering column assembly
Rack mountings x2
Water pump
Steering rack assembly
Radiator hose
Anti roll-bar links x2
Anti roll-bar mountings x2
Anti-roll bar
Steering rack mounting
Water hose
Screws type AM01 x5
Screws type AG04 x3
Screws type AM16 x3
Screws type AM17 x3
Screws type AG06 x3
Screws type AG08 x5
STAGE 32 PARTS LIST
In this first stage of pack 5, you will add
components for the steering system
to the subframe, and add further
components to the engine, before
fitting the engine to the subframe.
Stage 32: Steering System Components
Steering rack assembly
AM01 x5
Anti-roll bar
Rack mountings x2 Water pump
Steering column assembly
AG08 x5
AG06 x3
AM17 x3
AM16 x3
AG04 x3
Steering rack
mounting
Water hose
Anti roll-bar mountings x2
Anti roll-bar links x2
Radiator hose
AGORAMODELS JAGUAR E-TYPE
4
STEP 1
1
3
2
4
Take the anti-roll bar and push one of the anti-roll bar links over the
pin at one end. Make sure the pin on the link faces the anti-roll bar.
Repeat the process to fit the second link on the opposite end.
Secure the link with an AG08 screw.
Position the anti-roll bar on the front of the subframe, within the
triangles formed by the diagonal stays at the front of the subframe.
Stage 32: Steering System Components
AG08
AG08
AGORAMODELS JAGUAR E-TYPE
5
5
7
6
8
Locate the flat tabs on both ends of the anti-roll bar on the supports
on the subframe.
Secure the link from the front using an AG08 screw.
Feed the pins on the end of the links into the holes in the bottom
wishbone.
Fit the link on the other end of the anti-roll bar in the same way,
securing it with another AG08 screw.
Stage 32: Steering System Components
AG08 AG08
AGORAMODELS JAGUAR E-TYPE
6
9
11
10
12
Take one of the anti-roll bar mountings and fit it over the anti-roll bar,
lining up the hole and the pin. Note: you may need to file a little excess
plastic off the pin and/or clearn any flash or paint from the hole to
ensure a good fit.
Repeat the process on the opposite end of the anti-roll bar, securing
the second mounting in place with another AM17 screw.
Secure the mounting in place with an AM17 screw.
Take the steering rack mounting and align the pins on the underside
with the matching holes in the subframe.
Stage 32: Steering System Components
AM17
AM17
AGORAMODELS JAGUAR E-TYPE
7
13
15
14
16
Press the mounting onto the subframe
Take the right-hand lower brace from stage 26 and fit it across the
subframe with the screwhole in the end aligned with the second
screwhole on the steering rack mounting.
Secure in place from the underside using an AG04 screw.
Secure the right-hand lower brace to the steering rack mounting
using an AG04 screw. Be careful not to over tighten this screw.
Stage 32: Steering System Components
AG04
AGORAMODELS JAGUAR E-TYPE
8
17
19
18
20
Now take the engine assembly and position the water pump above
the engine pulleys as shown.
Fit the water hose by pushing one end over the pin on the water
pump, and tuck the other end behind the plug leads.
Fit the water pump behind the uppermost pulley.
This is how the water hose should look once fitted.
Stage 32: Steering System Components
AGORAMODELS JAGUAR E-TYPE
9
21 22
24
Returning to the subframe assembly, feed the steering column
assembly through the subframe until the gear at the end of the
steering column sits in the steering rack mounting (see step 22).
Now feed the steering rack assembly through the triangular braces
at the front of the subframe. Check that the teeth on the rack are
positioned so that they will align with the gear.
Note: when the wheels are pointing straight ahead, the flat side of the
‘D’ on the end of the steering column assembly (opposite the gear)
should be level and facing upwards (inset).
Press the gear into the mounting.
Check that the teeth on the rack are positioned so that they align and
mesh with the gear (arrow No 1). Fit the ends of the steering rack over
the posts on the steering uprights (arrow No 2).
Stage 32: Steering System Components
1.
2.
2.
23
AGORAMODELS JAGUAR E-TYPE
10
25
27
26
28
Secure the steering rack to each upright using an AM16 screw
Secure the mounting in place using 2 x AM01 screws.
Take one of the steering rack mountings, using tweezers, position it
over the steering rack, lining up the two screwholes with the holes on
the subframe.
Repeat steps 26 & 27 to fit the other mounting to the right-hand side.
Stage 32: Steering System Components
AM16 AM16
2 x AM01 2 x AM01
