Agilent E2969A Protocol Compliance Test Card

for PCI Express

User Manual

Agilent Technologies

E2969-91020

Important Notice

Manual Part Number

E2969-91020

Revision

Revision 2.0, December 2004

Printed in Germany

Agilent Technologies,

Deutschland GmbH

Herrenberger Str. 130

71034 Boeblingen, Germany

Warranty

The material contained in this

document is provided "as is," and is

subject to being changed, without

notice, in future editions. Further, to

the maximum extent permitted by

applicable law, Agilent disclaims all

warranties, either express or

implied, with regard to this manual

and any information contained

herein, including but not limited to

the implied warranties of

merchantability and fitness for a

particular purpose. Agilent shall not

be liable for errors or for incidental

or consequential damages in

connection with the furnishing, use,

or performance of this document or

of any information contained herein.

Should Agilent and the user have a

separate written agreement with

warranty terms covering the

material in this document that

conflict with these terms, the

warranty terms in the separate

agreement shall control.

Technology Licenses

The hardware and/or software

described in this document are

furnished under a license and may

be used or copied only in

accordance with the terms of such

license.

Restricted Rights Legend

If software is for use in the

performance of a U.S. Government

prime contract or subcontract,

Software is delivered and licensed

as “Commercial computer software”

as defined in DFAR 252.227-7014

(June 1995), or as a “commercial

item” as defined in FAR 2.101(a) or

as “Restricted computer software”

as defined in FAR 52.227-19 (June

1987) or any equivalent agency

regulation or contract clause. Use,

duplication or disclosure of

Software is subject to Agilent

Technologies’ standard commercial

license terms, and non-DOD

Departments and Agencies of the

U.S. Government will receive no

greater than Restricted Rights as

defined in FAR 52.227-19(c)(1-2)

(June 1987). U.S. Government users

will receive no greater than Limited

Rights as defined in FAR 52.227-14

(June 1987) or DFAR 252.227-7015

(b)(2) (November 1995), as

applicable in any technical data.

Safety Notices

CAUTION

A CAUTION notice denotes a

hazard. It calls attention to an

operating procedure, practice, or the

like that, if not correctly performed

or adhered to, could result in

damage to the product or loss of

important data. Do not proceed

beyond a CAUTION notice until the

indicated conditions are fully

understood and met.

WARNING

A WARNING notice denotes a

hazard. It calls attention to an

operating procedure, practice, or the

like that, if not correctly performed

or adhered to, could result in

personal injury or death. Do not

proceed beyond a WARNING notice

until the indicated conditions are

fully understood and met.

Specific Cautions

Do not use the test card for any

other purposes or in any other way

than described in this manual.

The test card may become hot

during use. Do NOT touch any of the

components on the test card. Do

NOT place the test card on

flammable surfaces during or after

operation.

Trademarks

Windows®, Windows 2000®, and

Windows XP® are U.S. registered

trademarks of Microsoft

Corporation.

Safety Symbols on the E2969A:

Indicates that antistatic precautions

should be taken.

Indicates hot surfaces, please do not

touch.

This product complies with the

relevant legal directives.

E2969-91020 Content-1

Contents

Introduction 1-1

Test Modes 1-3

Installation 2-1

Prerequisites 2-1

Installing the Software 2-3

Installing the Hardware 2-8

Testing the Installation 2-10

Working with the PTC 3-1

Setting up the Test Hardware for Add-In Card Mode 3-1

Setting up the Test Hardware for Topology Test Mode 3-3

Using the Test Software for AIC Tests under Linux 3-4

Using the Test Software for AIC Tests under Windows 3-7

Using the Test Software for Topology Mode Tests under

Windows 3-8

Administering the PTC 3-10

Troubleshooting 4-1

Appendix 5-1

Hardware Description 5-1

Technical Specifications 5-8

Declaration of Conformity 5-10

Content-2 E2969-91020

E2969-91020 1-1

Introduction

The Agilent E2969A protocol test card (PTC) is a combination of software

and plug-in card that can be used for PCI Express compliance tests.

The PTC performs tests to verify and ensure compliance with PCI

Express as defined by the PCI-SIG.

The card runs on a PCI Express x1 lane at 2.5 Gbit/s. It is plugged into

one of the PCI Express slots of the target platform.

As an R&D engineer, you can use the PTC to validate the functional

compliance of your PCI Express-based designs, including chips, add-in

cards or systems.

The PTC provides a set of automated pre-programmed compliance tests

for testing both transaction layer and data link layer as well as power

management and configuration space. Furthermore, it monitors the

Introduction Test Modes

1-2 E2969-91020

behavior of the DUT (device under test) in response to certain error

conditions.

For more detailed analysis, the PTC provides a connector to Agilent’s

E2960 protocol analyzer. With the analyzer, you can monitor and analyze

captured PCI Express traffic between an adapter card and a system, for

example.

Further features include

• Field-upgradeable FPGA-based card

• USB 2.0 interface for programming and topology simulation mode

• Can act either as a PCI Express standalone add-in card, or as a PCI

Express interposer card for x1 operation

• Card supplied with two different software packages:

– The AIC test mode software which runs under Linux Operating

system with the PCI Express compliance tests for Add-In-Cards

– A windows software package that contains the AIC Tests for

Windows as well as the Topology Tests. This package contains also

some additional tools for checking and updating the Protocol Test

Card, which runs under Windows via the USB connector.

Test Modes Introduction

E2969-91020 1-3

Test Modes

The protocol test card provides three test modes:

• Add-In-Card test mode

• Known Endpoint test mode

• Topology test mode

The test software provides a list of tests for each of these modes. You can

select the mode and execute the tests from the graphical user interface.

The current version of the PTC only supports the Add-In-Card test mode

and Topology Test Mode. Known Endpoint test mode will be supported by

one of the next releases.

Add-In-Card Test Mode

In the Add-In-Card test mode, the PTC acts as a switch device between

the target platform and another PCI Express add-in card (DUT). The DUT

is plugged into the PCI Express slot on top of the PTC.

Though the upper slot of the PTC is capable of accepting up to x16 cards,

only x1 links are supported.

The tests in this mode check the correct behavior of the add-in card. The

test software communicates with the PTC using PCI Express commands

and performs various tests with the DUT.

In this mode it is necessary to power the PTC through the external power

connector. Any standard ATX Power Supply can be used for this purpose.

NOTE

Introduction Test Modes

1-4 E2969-91020

Known Endpoint Test Mode

In the Known Endpoint test mode, the PTC behaves like a known

endpoint device.

This mode is used for system testing. No other card can be plugged into

the PTC in this mode. The software runs various KEP tests to test the

systems behavior on certain error conditions.

The KEP mode will be supported by one of the next software releases.

Topology Mode

The Topology mode is used to test BIOS settings.

Controlled by software running on an external host connected through

USB, the PTC pretends to behave like a variety of PCI Express devices. No

other card can be plugged into the PTC in this mode.

All configuration accesses are handled via the software connected

through the USB link. No other accesses or transactions are supported in

this mode.

In this mode it is necessary to power the PTC through the external power

connector. Any standard ATX Power Supply can be used for this purpose.

NOTE

E2969-91020 2-1

Installation

Test setups using the Agilent E2969A protocol test card (PTC) include the

following components:

• E2969A Protocol Test Card (PTC) card plugged into the target platform

• Add-In-Card Tests: PTC software running on the target platform

providing a graphical user interface used for controlling the tests and

monitoring the test results

• Topology Mode Tests: PTC software running running on an extra

controlling host PC connected to the test card through USB to run the

tests. This software package is also used for administration purposes.

This chapter shows how to install these components and verify their

operation.

Prerequisites

The PTC supports the PCI Express Specification 1.0a.

It is intended to be used standalone or as part of Intel’s Product

Development Kits (PDKs) for PCI Express Technology. The PTC integrates

into the PDK Software environment and tests.

For the Add-In-Card test mode as well as the Topology test mode, the PTC

must be plugged into a target platform, for example, the one provided

with the Intel PDK.

Installation Prerequisites

2-2 E2969-91020

PCI Express traffic must be scrambled as described in the PCI Express

specification. Unscrambled data transfer is not supported.

The Add-In-Card (AIC) tests run under the operating system Linux and

Windows. In case of AIC Tests under Linux, the target platform must

fulfill the following prerequisites:

• Red Hat Linux 9 installed, running the uniprocessor kernel

• “Kernel Development” package installed, including the Tk GUI toolkit

for Tcl, with shared libraries

• at least one free PCI Express slot that can be configured to run as x1

PCI Express connection

• CD-ROM drive available

In case of AIC Tests under Windows, the target platform must fulfill the

following prerequisites:

• Windows 2K or Windows XP installed

• at least one free PCI Express slot that can be configured to run as x1

PCI Express connection

• CD-ROM drive available

The controlling host for the Topology tests and administrative purposes

must fulfill the following prerequisites:

• 1 GHz PC with a Pentium 4 or equivalent

• Windows 2000 or Windows XP installed

• USB connector available

• CD-ROM drive available

Table des matières

Autres manuels Agilent Technologies Équipement de test

Agilent Technologies

Agilent Technologies 16043A Manuel d'utilisation

Agilent Technologies

Agilent Technologies E5022A Manuel utilisateur

Agilent Technologies

Agilent Technologies Infiniium 80000 Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 16442A Manuel utilisateur

Agilent Technologies

Agilent Technologies J-BERT N4903B Manuel utilisateur

Agilent Technologies

Agilent Technologies 16047E Manuel d'utilisation

Agilent Technologies

Agilent Technologies 8960 Mode d'emploi

Agilent Technologies

Agilent Technologies InfiniiVision 3000 X-Series Manuel utilisateur

Agilent Technologies

Agilent Technologies U1583A Manuel utilisateur

Agilent Technologies

Agilent Technologies 5530 Manuel utilisateur

Agilent Technologies

Agilent Technologies InfiniiVision 6000 Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 16452A Manuel d'utilisation

Agilent Technologies

Agilent Technologies Medalist i3070 Series 5i Manuel utilisateur

Agilent Technologies

Agilent Technologies E6392B Manuel utilisateur

Agilent Technologies

Agilent Technologies 8960 Manuel d'installation et d'exploitation

Agilent Technologies

Agilent Technologies InfiniiVision 4000 X-Series Manuel

Agilent Technologies

Agilent Technologies 3000 Series Manuel utilisateur

Agilent Technologies

Agilent Technologies HP 83711A Manuel utilisateur

Agilent Technologies

Agilent Technologies 54810A Manuel utilisateur

Agilent Technologies

Agilent Technologies InfiniiVision 4000 X Series Manuel utilisateur

Agilent Technologies

Agilent Technologies ENA Series Manuel utilisateur

Agilent Technologies

Agilent Technologies E7495A RF Mode d’emploi

Agilent Technologies

Agilent Technologies InfiniiVision 7000B Series Manuel utilisateur

Agilent Technologies

Agilent Technologies InfiniiVision 7000B Series Manuel utilisateur

Manuels Équipement de test populaires d'autres marques

SMART

SMART KANAAD SBT XTREME 3G Series Manuel utilisateur

Vernier

Vernier Go Direct Voltage Manuel utilisateur

Lifeloc

Lifeloc R.A.D.A.R. Manuel utilisateur

Fluke

Fluke T5-600 Instructions d'utilisation et d'installation

Mercury

Mercury TSL01 Manuel utilisateur

MAHA

MAHA MBT Series Manuel utilisateur

Fuji Electric

Fuji Electric P-61 Manuel utilisateur

ETC

ETC SealerAtor Manuel utilisateur

Skyfine

Skyfine ETHYWAY V2 Manuel utilisateur

Appion

Appion G5 Twin Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0112A Manuel utilisateur

BW Technologies

BW Technologies MicroDock II Manuel utilisateur

Sun Nuclear

Sun Nuclear 1027 Manuel utilisateur

Biomark

Biomark HPR LITE READER Manuel utilisateur

Hioki

Hioki 3169-20 Manuel utilisateur

Ashcroft

Ashcroft ATE-100 Manuel utilisateur

Rohde & Schwarz

Rohde & Schwarz RTA4000 Manuel utilisateur

Ritmix

Ritmix RAT-701 Manuel utilisateur
