Agilent Technologies E5070BU Guide de démarrage rapide

Agilent E5070BU/E5071BU Option 017

Removable Hard Disk Upgrade Kit

Upgrade Manual

Second Edition

Agilent Part No. E5070-90118

June 2005

Printed in Japan

Notices

The information contained in this document is subject to change without notice.

This document contains proprietary information that is protected by copyright.All rights

are reserved. No part of this document may be photocopied, reproduced, or translated to

another language without the prior written consent of the Agilent Technologies.

Manual Printing History

The manual’s printing date and part number indicate its current edition. The printing date

changes when a new edition is printed. (Minor corrections and updates that are

incorporated at reprint do not cause the date to change.) The manual part number changes

when extensive technical changes are incorporated.

May 2005 First Edition

June 2005 Second Edition

Typeface Conventions

Sample (bold) Boldface type is used when a term is defined or

emphasis.

Sample (Italic) Italic type is used for emphasis.

key Indicates a hardkey (key on the front panel or

external keyboard) labeled “Sample.” “key” may

be omitted.

Sample menu/button/box Indicates a menu/button/box on the screen labeled

“Sample” which can be selected/executed by

clicking. “menu,” “button,” or “box” may be

omitted.

Sample block/toolbar Indicates a block (group of hardkeys) or a toolbar

(setup toolbar) labeled “Sample.”

Sample 1 - Sample 2 - Sample 3 Indicates a sequential operation of Sample 1,

Sample 2, and Sample 3 (menu, button, or box).

“-” may be omitted.

1 General Information

This chapter describes the Upgrade Kit, contents of the kit, and required tools to install the

Option 017 into the Agilent E5070B/E5071B.

4Chapter1

General Information

Option 017 Upgrade Kit

The purpose of this kit is to install the option 017 removable hard disk upgrade into the

Agilent E5070B/E5071B.

This upgrade can be performed by Agilent qualified personnel. After incoming inspection,

this kit should be sent to the nearest Agilent Technologies service office with the

E5070B/E5071B for option upgrade.

Contents of the Agilent E5070BU/E5071BU Option 017

Upgrade Kit

The kit includes the parts listed in Table 1-1. If anything is missing, contact the nearest

Agilent Technologies office.

Table 1-1 Contents of the Agilent E5070BU/E5071BU Option 017 Upgrade Kit

Description Agilent PN Qty.

Upgrade Manual (This manual) E5070-90108 1

HDD BOX E5070-01254 1

INNER COVER E5070-01253 1

INTERFACE BD PCA E5070-66534 1

CONNECTOR BD PCA E5070-66535 1

HDD BRACKET E5070-01255 1

HEAT TRANSFER SHEET E5070-25051 1

FLAT CABLE ASSY E5070-61638 1

LID E5070-01252 1

COVER ASSY FOR E5070B/E5071B E5070-04023 1

ANGLE E5070-01256 1

GUIDE-PC BOARD NYL 19 MM-LG 0403-1143 1

CLAMP-CABLE .187-DIA .25-WD NYL 1400-0866 1

SADDLE-WIRE 1400-1051 1

CLAMP-FL-CA 1-WD PVC 1400-0611 1

CABLE-TIE .062-1 .25-DIA .14-WD NYL 1400-0493 1

BRACKET E5070-01258 1

WIRE ASSY E5070-61637 1

Chapter 1 5

General Information

Contents of the Agilent E5070BU/E5071BU Option 017 Upgrade Kit

SCREW-MACH M3.0 x 6 PN T10 0515-0430 9

SCREW-MACH M3.0 x 8 PN T10 0515-0372 1

SCREW-MACH M2.5 x 6 FL T8 0515-2028 2

SCREW-MACH M3.0 x 4 FL T10 0515-2146 8

SCREW-MACH M3.0 x 10 PN T10 0515-0374 4

Table 1-1 Contents of the Agilent E5070BU/E5071BU Option 017 Upgrade Kit

Description Agilent PN Qty.

6Chapter1

General Information

Contents of the Agilent E5070BU/E5071BU Option 017 Upgrade Kit

2 Option Installation

This chapter describes the procedure to install the option 017 into the Agilent

E5070B/E5071B.

8Chapter2

Option Installation

Introduction

This chapter describes the procedure to install Option 017 into the E5070B/E5071B. The

procedure consists of the following items.

• Installation Requirements

• Hardware Installation

Update Procedure

Installation Requirement

• TORX Screwdriver, T8, T10, T15, and T20

Hardware Installation

Refer to Figure 2-2, Figure 2-3, and Figure 2-4 for this procedure.

Step 1. Remove the outer cover.

Step 2. Remove the two TORX T10 screws (item 1) fastening the A27 mass storage disk drive

assembly.

Step 3. Disconnect the three cables connected to the A27 assembly, and lift the A27 assembly.

Step 4. Remove the four TORX T10 screws (item 2), and remove the mass storage disk drive from

the A27 assembly.

Step 5. Remove two TORX T10 screws (item 3) fastening the handler I/O bracket on rear panel.

Step 6. Pull the bracket with handler I/O board only a little.

Step 7. Remove two TORX T10 screws (item 4) fastening the handler I/O bracket, and remove the

bracket from the handler I/O board.

Step 8. Fasten the new bracket using the two TORX T10 screws to the handler I/O board.

Step 9. Fasten the new bracket with the handler I/O board using the two TORX T10 screws to the

rear panel.

Step 10. Connect the power cable (item 5) to the removable hard disk assembly.

Twist the flat cable (item 5) and connect to the removable hard disk assembly.

Replace the wire connected to the Oven assembly with the new wire, and connect it (item

5) to the removable hard disk assembly.

Step 11. Fasten the removable hard disk assembly with angle to chassis using the five TORX T10

screws (item 6).

Chapter 2 9

Option Installation

Update Procedure

Step 12. Clamp the slack cable between the power unit and the FDD, the Oven assembly and the

removable hard disk assembly (item 7).

Step 13. Clamp wires between the power unit and the FDD (item 8).

Step 14. Stick the cable clamp included in this kit as shown Figure 2-2 (item 9), and then clamp the

slack flat cable between the mother board and the removable hard disk assembly.

Step 15. Clamp all unused cables of the power unit by cable tie (item 10).

Step 16. Stick the heat transfer sheet to the mass storage disk drive rear side (Refer to Figure 2-1).

Figure 2-1 Heat Transfer Sheet

Step 17. Remove the four TORX T10 screws (item 11), and remove the two TORX T8 screws (item

12).

Step 18. Remove the HDD bracket from the connector board.

Step 19. Connect the mass storage disk drive with heat transfer sheet to the connector board.

Step 20. Fasten the mass storage disk drive with the connector board to the HDD bracket using the

four TORX T10 screws (item 13) and the two TORX T8 screws (item 12).

Step 21. Fasten the HDD bracket to the HDD box using the four TORX T10 screws (item 11).

Step 22. Connect the flat cable between the connector board and the interface board.

Step 23. Fasten the cover assembly for the removable hard disk.

10 Chapter2

Option Installation

Update Procedure

Figure 2-2 Hardware Installation (1 of 3)
