AGFEO System DECT 30 Manuel utilisateur

User Guide

System DECT 30

System Phone

About this User Guide

This user manual is intended for the telephone system with the firmware installed at the time of

shipment. As the DECT30 Cordless System Phone is controlled from the telephone system certain

features described in this manual may no longer apply if the system firmware is changed.

This manual contains user instructions for the DECT 30 Cordless System Phone and a brief

reference regarding the system features. A detailed description of features relating to the telephone

system can be found in the user guide of the telephone system.

The AGFEO DECT 30 Cordless System Phone is designed for the connection / registration to an

AGFEO DECT-Module or AGFEO DECT-SO-Base.

AGFEO GmbH & Co. KG will not accept any liability whatsoever for any damages which may be

caused by improper use of the DECT 30 Cordless System Phone.

User Instruction

System DECT 30

User Instruction .................................................................................................................................... 2

About this User Guide ........................................................................................................................... 2

This Pack Contains: .............................................................................................................................. 4

Charging the Battery Pack .................................................................................................................... 4

DECT 30 Handset ................................................................................................................................... 5

Buttons of the DECT 30 Cordless Phone .............................................................................................. 6

DECT 30 Display ..................................................................................................................................... 7

Status Display ........................................................................................................................................ 7

Display of Features Set .......................................................................................................................... 7

Switch Handset ON / OFF .................................................................................................................... 8

Keypad Lock ........................................................................................................................................... 8

Ringer Switch ........................................................................................................................................ 8

Telephone Settings ................................................................................................................................ 9

Register DECT 30 to Base Unit ............................................................................................................ 10

DECT Delete Registration .................................................................................................................... 11

Delete Registration in Telephone System ........................................................................................... 11

Delete Registration in DECT 30 Handset ............................................................................................. 11

Function Buttons- Overview of freely programmable Function Buttons .......................................... 12

Function Button Assignment .............................................................................................................. 14

Store / Change a Function .................................................................................................................. 14

Making Calls ........................................................................................................................................ 14

Exchange Line Seizure „Direct“......................................................................................................... 14

Exchange Line Seizure with „9“......................................................................................................... 15

Call Log ................................................................................................................................................ 15

Store an Entry ...................................................................................................................................... 16

Calling Stored Number (or Delete) ...................................................................................................... 16

Phone Book of the DECT 30 ................................................................................................................ 16

Cleaning the DECT 30 ......................................................................................................................... 17

Accessories /Range ............................................................................................................................. 17

Rechargeable Battery .......................................................................................................................... 17

Battery Replacement ........................................................................................................................... 17

Changing the Battery .......................................................................................................................... 18

Declaration of Conformity ................................................................................................................... 19

Table of Contents

System DECT 30

ThisPack Contains:

Charging the Battery Pack

1 System DECT 30 Cordless Handset

1 Rechargeable Battery Pack

1 Charging Cradle with Plug In Power Supply

1 User Manual

NOTE: The supplied battery has not been charged.

To charge the battery insert the handset in the charging cradle of the DECT 30. The charging status

will be shown in the display of the phone. However, the display may remain without any indication

for a few minutes if the battery will be charged for the first time. The handset will sound a beep

once the battery has been fully charged.

- NOTE: The first initial charge should be carried out for at least 16 hours - regardless of the

charging status display.

- After the initial charge you may return the handset into the charging cradle after each call. The

charging of the battery is electronically controlled to guarantee an optimal and gentle charging

process.

- The battery may get warm during charging.

An even longer battery life can be achieved if you discharge the battery completely every so often. To

discharge the battery, leave the handset switched on until this will switch off by itself.

System DECT 30

DECT 30 Handset

AGFEO

ABC DEF

JKL

GHI MNO

PQRS TUV WXYZ

Volume Control

Earpiece

LED Indicator

Browse

Last Number Redial

Stop

Programming

Illuminated Display

Browse

Phone Book

Confirmation

Call Log / Set Features

2nd Level

Recall

Delete

Initiate or End Call

Keypad Lock

Headset Connection Microphone

Ringer Off

Mute (not used)

Keypad / Characters

programmable Buttons

CLR

DECT 30

ALT

789

System DECT 30

Buttons of the DECT 30 Cordless Phone

1...0

N L

I J

A B

Keypad - to dial or enter data

Arrow Buttons - To browse through the

display

OK - To confirm entry

Alt - To initiate a function within the

telephone system. To go to 2nd keypad

level. To use the freely programmable

function buttons. To switch to Phone

Book.

Recall - Enquiry or Brookers Call.

Answer or End a Call. Quit a function.

Phone Book -Access DECT 30 Phone

Book.

ALT Phone Book - Access phone book of

telephone system. (Central Dialling)

Messages - Currently without function.

ALT Mail - To access Call Log,

Answering Machine and to check

active features in the telephone

system.

Last Number Redial - To use LNR of

the DECT 30 handset.

ALT Last Number Redial - use LNR of

the telephone system.

Programming - To program functions

of the DECT 30 handset.

ALT Programming - To program

functions of the telephone system.

Key - Used to lock keypad.

without function

Bell - Switch off tone ringer. Incoming

calls will be signalled by vibration or

visual in display.

Clear - Delete an entry.

A G

A P

A Q

Q M

Q E

A C

System DECT 30

BRI ISDN trunk line. One line (one B-Channel) is in use. The x will be flashing on an incoming

call.

BRI ISDN trunk line. Both channels of the line are in use.

ISDN Extension line. One line (one B-Channel) is in use.

ISDN Extension line. Both channels of the line are in use.

Both B-channels of the ISDN – line are available. (Extension or BRI trunk line)

Extension, Static: Extension is busy, Flashing: Extension is ringing.

DECT 30 Display

Status Display

Display of Features Set

Call Waiting ON

Do Not Disturb (DND) ON

Diversion / ISDN-Diversion ON.

Call Forwarding / Alternative Extension ON

Night Service

Appointment Reminder ON.

Wake Up Call ON

CallLog

Answering Machine (AGFEO A-Module 30 only)

Sensorenabled

To access ALT-Display press ALT button once.

DECT 30 is off hook and has a radio connection to the system

Browse trough menu

DECT 30 is within reach of base station

Status Indication of S0 Connection

Extension Status

ALT-Display

Indicates the features enabled

active WRL

System DECT 30

Switch Handset ON / OFF

Switch to ON:

Press the call button for 1 second

Switch OFF:

Press the OK button for 3 seconds

The DECT 30 will switch ON after the battery is

connected and the handset is inserted into the

chargingcradle.

KeypadLock

Enable the keypad lock by pressing the SET Button

follwed by the STAR * button.

Disable the keypad lock by pressing the SET But-

ton follwed by the STAR * button.

Pressing any buttons will have no functions when

the keypad is locked.

To answer a call press the „call button“, the

keypad lock is automatically disabled during a call.

D O

H O

Q N

1 sec.

Ringer Switch

To switch the ringer off press the SET Button

followed by the #-Button.

To switch the ringer back to on press the SET

Button followed by the #-Button.

Q L

System DECT 30

TelephoneSettings

Press the „Set“ button longer to change the settings of the DECT 30 Cordless System Phone:

Note, two different user profiles can be set in the menu PROFILE SET UP.

Each of the profiles will have the following settings available:

- Tone Ringer: Will set the various ring tones.

- Ringer Volume: 5 Volume settings are available.

- Keypad Click: Here you can set if a click should be heard on pressing a button on the keypad.

- Vibrator: To switch the vibration alarm on or off.

- Auto Answer: Will answer an incoming call automatically. This feature is useful if a headset is

worn by the user and each call wants to be answered without pressing a button.

- Charging Cradle: Will set if a call should be answered if the ringing DECT 30 is lifted out of the

chargingcradle.

- Handset Volume: Here the volume can be set in 5 steps.

- Range: Will set if a warning tone should sound once the handset is out of range of the DECT base

station.

- Illumination: Background illumination of the Display area can be set here.

- Keypad Lock: Will set if the keypad lock should activate automatically after 1 minute.

The menu LOGIN offers following selection:

- 10 DECT Base Stations to be stored and selected,

- to register your DECT 30 to another Base Station,

- to delete Base Stations from your DECT 30 handset.

Telephone Settings

Press the „Set“ button.

Select using the arrow buttons the Menu „Profi-

le“. Confirm the selection with „OK“.

Select by using the arrow buttons the profile to

which the changes should apply. Confirm the

selection with „OK“.

You now can select the above described settings.

The required section is selected by pressing

„OK“, use the arrow buttons to change the

setting.

By pressing „Ok“ the required setting will be

stored.

To leave this programming menu press briefly the

„Set“ button.

IJH

System DECT 30

The DECT 30 handset can be registered to a

maximum of 10 Base Units.

Should you only have one base unit, then you may

ignore this point and all other relating infor-

mation regarding the selection of a base unit.

Should you have more than one base unit in use

with your telephone system, then you select the

base unit to which you want to register the DECT

30 handset to. The base unit can be allocated by

use of the Identnumber. (Sticker on module or

indication in display)

First switch your DECT Base to registration mode

as described in the user manual of your DECT

SO-Base or DECT Module.

Press the „Set“ button on the DECT 30.

Using the arrow buttons select the menu LOGIN

and confirm with „OK“.

With the arrow buttons go to the menu

„SUBSCRIPTION CREATE“ and confirm with

„OK“. The DECT 30 will now search for a base

unit which is in registration mode.

Once a base is found, then this will be shown in

the display area. You may select the required base

with the arrow buttons should more than one

base be in registration mode. Confirm selection

by pressing „OK“

Use the arrow buttons select the required

location. Enter the system PIN if so required

(default is 2580) and confirm with OK.

The DECT 30 is now registered to the base unit.

Table des matières

Autres manuels AGFEO Téléphone sans fil

AGFEO

AGFEO DECT 35 Manuel utilisateur

Manuels Téléphone sans fil populaires d'autres marques

3Com

3Com NBX Manuel utilisateur

Panasonic

Panasonic KX-TGK210HK Manuel utilisateur

Panasonic

Panasonic KX-TCA181EX Manuel utilisateur

BT FREESTYLE 3200 Manuel utilisateur

AT&T

AT&T CL84102 Manuel utilisateur

BREZZICNI

BREZZICNI CL-3622 Manuel utilisateur

Panasonic

Panasonic KX-TG1831NZ Manuel utilisateur

Panasonic

Panasonic KX-TG7301E Manuel utilisateur

Furuno

Furuno FM-4721 Manuel utilisateur

Sanyo

Sanyo CLT-J70 Manuel utilisateur

Amplicomms

Amplicomms BigTel 201 Manuel utilisateur

GE 26992 Manuel utilisateur

AT&T

AT&T E1812B Manuel utilisateur

Sanyo

Sanyo CLT-670 Manuel utilisateur

GE 15432970 Manuel utilisateur

Curtis

Curtis TC595 Manuel utilisateur

Gigaset

Gigaset Gigaset 3000 Micro Manuel utilisateur

Poly

Poly VVX D230 Guide de configuration
