NeoV™ Optical Glass - e most
trusted hard glass protection available.
Only on AG Neovo displays
A 24” performance-minded display
tted with hard glass protection and
advanced SDI inputs that promises
to work admirably in security-critical
environments.
On top of Full HD 1920 x 1080 resolution and LED backlighting,
the HX-24 features SDI inputs that make it possible to receive
megapixel images directly from HD-SDI devices without signal
interruption or video delay. e solid protection of NeoV™ Optical
Glass and Anti-Burn-in™ technologies makes it a tting choice for a
full spectrum of professional applications and public places—from
banks to hotels and casinos. Durability stands out as a priority for
this mission-critical 24/7 apparatus—its metal casing is matched
by meticulously selected components to ensure impeccable nonstop
operations.
> 1920 x 1080 Full HD resolution
> NeoV™ Optical Glass
> Anti-Burn-in™ Technology
> AIP technology: PIP and PBP functions; 3D Comb Filter/ Deinterlace/ Noise
Reduction; Image rotation function / Freeze
> Versatile inputs: 3G SDI in/out, CVBS in/out, HDMI, DVI, VGA, Audio in
> SDI connection supports 3Gb/s, 1.5 Gb/s HD, SD SDI video inputs
> Capable of receiving digital video over 75 coaxial cable at lengths up to 100m for SD
and for HD, using RG59 or equivalent
> SDI serial digital looping through
> Embedded audio in SDI up to 8 channels of 48kHz
> EcoSmart Sensor for low watt power consumption
> Black-level alignment
> Durable metal housing
> Rigorous screening of the components for mission-critical 24/7 applications
HX-24
All specications are subject to change without prior notice.
Copyright © 2013 AG Neovo. All rights reserved. e name AG Neovo is a trademark of AIC.
All other trademarks are the property of their respective owners.
P/C: HX2400 Version 1.0, 20130201
Panel Panel Type
Panel Size
Max. Resolution
Pixel Pitch
Brightness
Contrast Ratio
Viewing Angle (H/V)
Display Colour
Response Time (GTG)
LED-Backlit TFT LCD
23.6”
FHD 1920 x 1080
0.2715 mm
300 cd/m2 (Typical)
1,000 : 1 (Typical)
170°/160° (Typical)
16.7 M
3 ms
Frequency (H/V) H.Freq
V.Freq
24kHz – 83kHz
50Hz – 85Hz
Input VGA
DVI
HDMI
SDI
CVBS
15-Pin D-Sub
24-Pin DVI-D
HDMI x 1
BNC x 1
BNC x 1
Output SDI
CVBS
BNC x 1
BNC x 1
Audio Aduio In
Speaker
1 x Stereo audio in for PC (audio
jack, 3.5ø)
RCA L+R for video
2W x 2
SDI Format 3G Video Format
HD Video Format
SD Video Format
1080p@50/60fps
1080p@24/25/30fps
1080i@50/60fps
720@24/25/30/50/60fps
625i (PAL)/ 525i (NTSC)
SDI Audio Embedded Audio Up to 8 channels, 24bit, 48kHz
Power AC-DC Adaptor
Power
Consumption
External DC 12V
100 - 240V, 50 - 60Hz
< 27W (On)
< 0.5W (Active Off)
< 0.5W (Off)
Operating
Conditions
Temperature
Humidity
0°C ~ 40°C (32°F~104°F)
10%~90% (No condensation)
Storage
Conditions
Temperature
Humidity
-20°C ~ 60°C (-4°F~140°F)
5%~95% (No condensation)
Mounting VESA FPMPMI Yes (100mm x 100mm & 75mm x
75mm)
Dimensions Product (W x H x D)
Packaging (W x H x D)
562 x 397 x 155 mm
(22.1” x 15.6” x 6.1”)
676 x 525 x 213 mm
(26.6” x 20.7” x 8.4”)
Weight Product Weight (with base)
Packaging weight
7.9 kg (17.4 lbs)
10.6 kg (23.4 lbs)
Regulation
Approval
Accessories
Certications &
Compliance
Supplied
CB, CE, RoHs, WEEE, REACH
CD ROM (user manual), power cord,
power adaptor, 15-Pin D-Sub cable,
audio cable
HX-24
NeoV™ Optical Glass and durable metal casing
for water, dust and scratch resistance
Viewing versatility with PIP and PBP
Anti-Burn-in™ technology prevents image sticking
Specications HX-24
SDI inputs bring forth megapixel images without
interruption
