IntroductionIndex
EPIC 1D
Introduction
1.1 PRESENTATION pag. 3
1.2 DESCRIPTION pag. 3
1.3 HANDLING pag. 3
Safety informations
2.1 WARNINGS pag. 4
2.2 CAUTION pag. 4
Installation
3.1 ASSEMBLING pag. 5
3.2 ELECTRICAL CONNECTIONS pag. 6
3.3 ADJUSTMENTS AND SETTINGS pag. 8
(INITIALIZATION)
3.4 ADJUSTMENTS AND SETTINGS pag. 10
(ADVANCED MENU)
3.5 TRIMMER SETTINGS pag. 25
3.6 CONTACT ALARM OUTPUTS pag. 25
General use
4.1 KEYPAD AND LIGHTS INDICATIONS pag. 27
4.2 ALARMS pag. 28
4.3 TYPICAL INSTALLATIONS pag. 30
Maintenance
5.1 PUMPS STOP pag. 32
5.2 SERVICE pag. 32
5.3 SPARE PARTS pag. 32
5.4 WASTE DISPOSAL pag. 32
Certifications
6.1 CERTIFICATE OF CONFORMITY pag. 33
1.1 PRESENTATION
The purpose of this manual is to provide the
necessary information for the proper installation,
use and maintenance of EPIC 1D.
The user should read this manual before operating
the unit. Improper use may cause damage to
the machine and lead to the forfeiture of the
warranty coverage. Always specify the model
identification code and the construction number
when requesting technical information or spare
parts from our Sales and Service department.
The instruction and warnings given below
concern the standard version; refer to the sale
contract documentation for modifications and
special version characteristics. For instructions,
situations and events not considered in this
manual or in the sale documents, please contact
our customer service.
Our units must be installed in sheltered, well-
ventilated, non-hazardous environments and
must be used at a maximum temperature of
+40°C and minimum of -5°C.
These control panels are designed for controlling
1 motor or electric pump used in pressurization
systems or in applications for emptying wells or
water tanks. In case of any failure of the main
pump, the reserve pump start automatically.
Atlantic S.r.l.s shall not be liable for any
damage caused or suffered by the unit as a
result of its unauthorised or improper use.
TECHNICAL FEATURES
Self learning of the motor data; min-max
amperage protection (A); dry running protection
made by cosφamd min Amperage; min and max
voltage protection (V); phase failure protection;
start and stop delay; delay network restore,
protection delay, frequency 50-60Hz.
OUTPUT ALARMS AND PROTECTIONS
Acoustic alarm; light alarm, alarm output Relais
220V CA, alarm output Relais 12 V CC, alarm
output with Buzzer 12 V; min-max water level;
min-max Voltage; phase failure; frequency
failure alarm; min-max motor Amperage; min
cosφ; motor klixon alarm; water in oil chamber
alarm.
1.2 DESCRIPTION
The control panel must be handled with
care, as falls and knocks can cause damage
without any visible external signs.
PRELIMINARY INSPECTION
After you have removed the external packaging,
visually inspect the control panel to make sure it
has suffered no damage during shipping.
If any damage is visible, inform an Atlantic dealer
as soon as possible, no later then five days from
the delivery date.
STORED
If for any reason the unit is not installed and
starter immediately after it has reached its
destination it must be stored properly. The
external packaging and the separately packed
accessories must remain intact, and the whole
must be protected from the weather, especially
from freezing temperatures, and from any
knocks or falls.
1.3 HANDLING
