Aeroflex 2975 Manuel utilisateur

2975

Operation Manual

1002-4202-2P0

Issue-3

Radio Test Set

OPERATION MANUAL

RADIO TEST SET

2975

PUBLISHED BY

Aeroflex

transmitted in any form or by any means, electronic, mechanical, photocopying, recording or

otherwise without the prior permission of the publisher.

Original Printing Jan 2005

Issue-2 Feb 2006

Issue-3 Aug 2006

10200 West York Street/ Wichita, Kansas 67215 U.S.A. / (316) 522-4981 / FAX (316) 524-2623

ELECTROMAGNETIC COMPATIBILITY

Double shielded and properly terminated external interface cables must be used with this equipment

when interfacing with the RS-232 and IEEE-488.

For continued EMC compliance, all external cables must be shielded and 3 meters or less in length.

NOMENCLATURE STATEMENT

The 2975 Radio Test Set is the official nomenclature for the 2975 Radio Test Set. In this manual,

2975, unit or test set, refers to the 2975 Radio Test Set.

THIS PAGE INTENTIONALLY LEFT BLANK.

SAFETY FIRST: TO ALL OPERATIONS PERSONNEL

REFER ALL SERVICING OF UNIT TO QUALIFIED TECHNICAL PERSONNEL. THIS UNIT CONTAINS NO

OPERATOR SERVICEABLE PARTS.

CASE, COVER OR PANEL REMOVAL

Removing protective covers, casings or panels from this unit exposes the operator to electrical hazards that

can result in electrical shock or equipment damage. Do not operate this unit with the case, cover or panels

removed.

SAFETY IDENTIFICATION IN TECHNICAL MANUAL

This manual uses the following terms to draw attention to possible safety hazards, that may exist when

operating or servicing this equipment.

CAUTION: THIS TERM IDENTIFIES CONDITIONS OR ACTIVITIES THAT, IF IGNORED, CAN RESULT IN

EQUIPMENT OR PROPERTY DAMAGE (e.g., FIRE).

WARNING: THIS TERM IDENTIFIES CONDITIONS OR ACTIVITIES THAT, IF IGNORED, CAN RESULT IN

PERSONAL INJURY OR DEATH.

SAFETY SYMBOLS IN MANUALS AND ON UNITS

CAUTION: Refer to accompanying documents.

AC TERMINAL: Terminal that may supply or be supplied with ac or alternating voltage.

SWITCH OFF: AC line power to the device is OFF.

SWITCH ON: AC line power to the device is ON.

DANGEROUS VOLTAGE: Indicates electrical shock hazard due to high voltage levels.

EQUIPMENT GROUNDING PRECAUTION

Improper grounding of equipment can result in electrical shock.

USE OF PROBES

Check the specifications for the maximum voltage, current and power ratings of any connector on the unit

before connecting it with a probe from a terminal device. Be sure the terminal device performs within these

specifications before using it for measurement, to prevent electrical shock or damage to the equipment.

USE RECOMMENDED FUSES ONLY

Use only fuses specifically recommended for the equipment at the specified current and voltage ratings.

CAUTION: SIGNAL GENERATORS CAN BE A SOURCE OF ELECTRO-MAGNETIC INTERFERENCE (EMI) TO

COMMUNICATION RECEIVERS. SOME TRANSMITTED SIGNALS CAN CAUSE DISRUPTION AND

INTERFERENCE TO COMMUNICATION SERVICES OUT TO A DISTANCE OF SEVERAL MILES.

USERS OF THIS EQUIPMENT SHOULD SCRUTINIZE ANY OPERATION THAT RESULTS IN

RADIATION OF A SIGNAL (DIRECTLY OR INDIRECTLY) AND SHOULD TAKE NECESSARY

PRECAUTIONS TO AVOID POTENTIAL COMMUNICATION INTERFERENCE PROBLEMS.

THIS PAGE INTENTIONALLY LEFT BLANK.

ESD WARNING!

PROTECTING THE 2975 AGAINST ELECTROSTATIC DISCHARGE

Electrostatic Discharge (ESD) can cause damage or even destroy circuitry within the 2975.

This damage is often unseen and can occur whenever the 2975 is incorrectly touched or

connected to other equipment.

To help reduce the chances of ESD damage, observe the following:

OMake sure the 2975 and all associated equipment are properly earth-grounded to

prevent build up of static charge.

OAll persons using the 2975 should be grounded with a 1 MΩresistor-isolated wrist

strap before touching any conductor on the 2975, or any equipment connected to

the 2975.

OBefore connecting an open coaxial cable to the 2975, short the center conductor of

the coaxial cable to the outer conductor of the coaxial cable to discharge any

potential static that may exist.

OIf a “rubber-ducky,” telescopic, or similar antenna is directly connected to the 2975,

DO NOT touch the antenna unless properly grounded.

OAll external antennas must use approved outdoor ESD and/or lightning suppression.

Use extreme caution whenever an external antenna is connected to any device!

OUse the 2975 and associated equipment at static-safe workstations that includes

conductive mats, ionizing blowers, wrist straps and any other necessary items as

appropriate.

OKeep all static-generating materials at least one meter away from the 2975 and

connected equipment.

OStore and transport the 2975 in an approved container.

OTouch and handle all printed circuit assemblies by the edges to reduce the chances

of ESD damage.

For more information about ESD and how to prevent damage, check the Electrostatic

Discharge Association web site at:

http://www.esda.org

THIS PAGE INTENTIONALLY LEFT BLANK.

PREFACE

SCOPE

This manual provides operational information for using the 2975 and describes features and functions

implemented with software version 1.9.1.4.

ORGANIZATION

The 2975 Operation Manual is composed of the following sections:

SECTION 1 - DESCRIPTION

Contains the 2975 Functions, Capabilities (Product Specifications) and Connector

Descriptions.

SECTION 2 - OPERATION

Contains a functional description of the Generator, Receiver, Duplex, Function Generator,

Oscilloscope, Spectrum Analyzer and Meters.

SECTION 3 - OPTIONAL FEATURES

Contains description of optional features available for the 2975.

SECTION 4 - APPLICATIONS

Contains step-by-step procedures for operating the 2975.

SECTION 5 - REMOTE COMMANDS

Tool Command Language (TCL) allows creation of automated sequences and remote

operation.

SECTION 6 - SYSTEM SETTINGS

Contains descriptions for network, remote and system features settings.
