AEQ DIGITAL COMMENTARY UNIT Guide de référence

A.E.Q., S.A. manufacturer of this equipment holds the AENOR ER-080/1/96

certificate according to UNE EN - ISO - 9001 Quality Standard

AEQ

DIGITAL COMMENTARY SYSTEM

CUSTOMER’S MANUAL

ED. 11/ 99

(VALID ONLY FOR EQUIPMENT WITH SOFTWARE VERSION CU V3.2 AND CM V3.4 Y3.5 OR HIGHER)

Digital Commentary System

-2-

AEQ DIGITAL COMMENTARY SYSTEM MANUAL INDEX

1.- Introduction to the Digital Commentary System

1.1.- General description

1.2.- Commentary unit (CU)

1.3.- Commentary Control Unit (CCU)

1.4.- Control software

2.- Commentary unit (CU)

2.1.- Features Description

2.2.- Functional diagram

2.3.- Installation & wiring

2.3.1.- Front panel description

2.3.1.1.- Micro headset connection

2.3.1.2.- Micro connection

2.3.1.3.- Tape connection

2.3.2.- Rear panel description

2.3.2.1.- Commentary Control Unit connection

2.3.2.2.- STAND ALONE connection

2.3.2.3.- Auxiliary line connection

2.3.2.4.- Control connection

2.3.2.5.- DIP switch configuration

2.3.2.6.- Power supply

2.3.3.- Lower panel description

2.3.3.1.- Input Sensibility adjust trimmers

2.4.- Description and operation

2.4.1.- Configuring the unit

2.4.2.- Working panel

2.4.2.1.- Commentator panel functions

2.4.2.2.- Mic/Tape functions

2.4.2.3.- Status functions

2.5.- Using the Commentary Unit (CU) with a Commentary Control Unit (CCU)

2.6.- STAND ALONE use

2.7.- Commentary unit specifications (functional and physical)

2.8.- Commentary unit specifications (electrical)

Digital Commentary System

-3-

3.- Commentary Control Unit (CCU)

3.1.- Features description

3.2.- Functional diagram

3.3.- Installation & wiring: rear panel description

3.3.1.- Monitor connections

3.3.2.- External specific connections

3.3.3.- Individual CU connection

3.3.4.- Mains switch, connector and fuses

3.4.- Description and operation : the working surface panel

3.4.1.- Introduction

3.4.2.- Control module (CM) functional description

3.4.2.1.- CM : Upper section

3.4.2.2.- CM : INTL SOUND section

3.4.2.3.- CM : Reference signals control section : GUIDE, AUX,

CUE

3.4.2.4.- CM : CU channels control section : COM1,2,3 and

MIC/LINE

3.4.2.5.- TAPE WITHOUT IS MIS

3.4.2.6.- CM : IDENTIFIER section (ID)

3.4.3.- Monitor module functional description

3.4.3.1.- MM : Upper section

3.4.3.2.- MM : Lower section

3.5.- Commentary Control Unit specifications (functional and physical).

3.6.- Commentary Control Unit specifications (electrical)

4.- Control software

4.1.- System overview

4.1.1.- System description

4.1.2.- System requirements

4.2.- Wiring the control network

4.2.1.- CCU wiring

4.2.2.- Control computer wiring

4.3.- Software installation

4.4.- Using the DCS Realtime Control software in a control network

4.4.1.- General overview

4.4.2.- Setting the network operational parameters

4.4.3.- Commentary System Network screen

4.4.4.- Commentary Control Unit monitor screen

4.4.5.- Commentary Control Module screen

4.4.6.- Commentary Unit screen

4.4.6.1.- The Commentary Unit screen

4.4.6.2.- Digital Level Processor (DLP)

4.4.6.2.1.- Independence of the DLP in a CU

4.4.6.2.2.- DLP Transfer Function

4.4.6.2.3.- Configuring the DLP

4.4.6.3.- HPF button

4.4.6.4.- Store audio parameters button

Digital Commentary System

-4-

4.4.6.5.- Retrieve audio parameters button

4.5.- Using the DCS Realtime Control software in a direct connection

4.5.1.- Controlling a single Commentary Unit

4.5.2.- Customizing the Commentary Unit audio parameters

4.5.3.- Remote control of the Commentary Unit using serial data

transmission

4.6.- Using the DCS Engineering Planning software

4.6.1.- Menu options

4.6.2.- Creating a new configuration file

4.6.3.- Opening an existing structure

4.6.4.- Adding and deleting elements in the network structure

4.6.5.- Assigning profiles to the elements

4.6.5.1.- Special Profiles : <NEW>

4.6.5.2.- Special Profiles : <NONE>

4.6.5.3.- Stored Profiles

APPENDIX 1: AEQ Warranty

Digital Commentary System

-5-

1.- INTRODUCTION TO THE DIGITAL COMMENTARY SYSTEM

The AEQ broadcaster digital commentary system was specially designed for

radio and television reporting. Its flexibility makes it versatile enough to be

used in most remote program situations.

The digital commentary system engineering and operational design meets

international broadcasters standards and requirements, making it very easy to

operate while preserving a high level of maintainability. Unit configuration and

functional changes are by software, and are centralized in the venue technical

control room and therefore can be accomplished in a very short time. It is also

possible to carry out these functions, via a modem, from the Program Control

Ccenter (PCC) or similar, located in the International Broadcasting Center

(IBC).

The controls of each Commentary Unit (CU) are easily accessible and their

number has been reduced to a minimum in order to simplify “on air” operation.

Controls are clearly identified by color and visual displays.

Normally at each venue the signal comes to each Commentary Unit (CU)

through a Commentary Control Unit console (CCU) consisting of ten

commentary modules and one associated monitor unit. Both units are

interconnected by digital cable.

A Commentary Control Unit (CCU) is not used at smaller events, the

commentary unit operates as a STAND ALONE, sending and receiving signals

through the analog inputs and outputs, while keeping remote control

capabilities through the built-in serial port.

Both, the CU and the CCU, accepts in-system programming, which insures an

easy and inexpensive way of system upgrading up to the latest available

version.

Digital Commentary System

-6-

1.1.- General description

Each Commentary System consists of ten commentator units (CU) connected

to a commentator console (CCU) through 4 pair data transmission STP or FTP

shielded cables used in data transmission.

The signals carried are as follows:

•Audio and control signals. There are two pairs for carrying digital data

related to audio feeds from commentators to the different output circuits, as

well as input signals to be monitored at the commentator’s side. Also

included are remote control signals, call signaling etc. The system includes

remote on field programming of the CU´s operational parameters (filtering,

AGC, compression etc.) and CU permanent software upgrade capabilities.

Digital Commentary System

-7-

•Power supply. There is a dedicated pair for remote CU powering from the

CCU. CUs can also be powered locally, using a external DC power supply.

•Auxiliary line. The system offers one pair for direct auxiliary line connection,

thus avoiding supplementary wiring costs.

Each commentator position at the venues will be equipped with a commentator

unit that can be used by up to three commentators and a guest announcer

simultaneously. The position of the guest announcer can also be used to

playback a pre-recorded tape. The Commentator Units have been designed to

provide the commentators with their own commentary circuit and easy access

to all their coordination talkback circuits.

Through their microphone headset combination, commentators have access to

the following circuits:

Their own commentary output circuit (Program).

•A choice of incoming signals such as International sound TV from the venue,

International sound Radio from the venue, Public Address (P.A.) system,

cues from the venue mobile producer, a local cue, beeping signals and an

optional feed from another commentator or cue circuit.

•Two-way communications with the venue technician responsible for the

commentary system and with the IBC or their home studio.

Digital Commentary System

-8-

1.2.- Commentary unit (CU)

The main function of this unit is to provide access to a combined microphone

headset for the broadcast of commentary or communication with a studio at the

IBC or the home country. The unit provides several operational possibilities,

which will vary in relation to the technical and operating criteria forecast for

each event, and in general are:

•The use of a microphone for commentary broadcast.

•Talkback from the producer at the IBC, studio or country to the commentator

at the venue.

•Commentator communication to the IBC studio or country producer.

•A return feed of the studio program output to the commentator.

•A feed which gives the results from the venue P.A. system.

•A two - way communications circuit between the commentator and the

operator at the Commentary Control Room (C.C.R.).

•Cue and venue information from the mobile producer.

•Cue information from additional organizations.

•Beeping signals of T’Back circuit.

•The option of disposing to listen the IS signal (preselected as the television

one or the radio one). from the competition site while broadcasting.

•The option of selecting a signal from the commentator GUIDE and an

auxiliary input (AUX) as a listening reference for the commentator to obtain

a data source for his commentaries.

All these functions are remotely controllable according to the technician’s

choice.

Digital Commentary System

-9-

1.3.- Commentary Control Unit (CCU)

The Commentary Control Unit (CCU) is designed to control and monitor up to

ten commentator signals from the commentator units, as well as provide the

required remote powering.

Each of the ten modular control sections has:

•a level meter for the PRG output

•an output selector (oscillator, ID, program)

•a digital mixing section, where the selected IS can be added to the

commentary signals to get the PROG/IS feed. The IS signal can be

upgraded by the Digital Level Processor (DLP). Audio parameters

associated with the DLP are fully programmable under the control software.

•A section to enable the AUX and GUIDE signals to the commentator

•A section for the routing and aperture of CUE 1 and CUE 2 signals to the

commentator

•An individual remote control and configuration section for each of the four

CU channels (COM 1, COM 2, COM 3 and MIC/LINE)

•A section for switching and signaling talkback calls

•A line identification section (ID) for the program and coordination circuits.

The monitor unit provides the operator with access to all program and cue

circuits for listening via a built-in speaker or set of earphones. A precision dB

meter is provided to measure absolute levels on all circuits. The unit also has

intercommunication functionality with the program and coordination circuits.

The monitor allows access to the local talk back circuit or a connection to the

external 4 wire circuit.

The power supply section, located on the rear panel, consists of two

independent modules, giving the redundancy level required for these types of

events. Each one of the modules is thus able to fulfill the power requirements of

the CCU and the associated CUs. The power supply design includes advanced

techniques like power factor correction, input voltage autoranging, high

efficiency switching conversion, etc.

Digital Commentary System

-10-

1.4.- Control software

The control software is a native 32 bits application, designed to run under

Windows 95 or Windows NT operating systems. It performs the following tasks:

•Can work in direct connection to a single CU, through the serial port, for

upgrading, setting audio parameters and real time remote controlling of the

unit.

•Can be used in a network configuration, carrying the full control of a given

number of CCUs and their associated CUs. Up to 32 CCUs (320 CUs) can

be controlled in this way.

•Performs real time supervision of the Commentary Control Network, using a

standard RS 485 (2 wire) interface. The required hardware is included in the

CCU as a standard option.

•Enables the user to define off-line configurations of the venue commentary

system, including audio and operational pre-settings. These pre-settings can

be downloaded to the real venue Commentary System. The setup time and

presetting tasks are dramatically reduced.

*Microsoft Corporation registered trademark

Table des matières

Autres manuels AEQ Équipement d'enregistrement

AEQ

AEQ FORUM Manuel utilisateur

AEQ

AEQ NETBOX 4 MH Manuel utilisateur

AEQ

AEQ Phoenix Mobile Instructions d'installation et d'utilisation

AEQ

AEQ FORUM Manuel utilisateur

AEQ

AEQ PHOENIX ALIO Manuel utilisateur

AEQ

AEQ PAW 120 Instructions d'installation

AEQ

AEQ FORUM LITE Manuel utilisateur

AEQ

AEQ PAW 120 Manuel utilisateur

AEQ

AEQ NETBOX DSP Manuel utilisateur

AEQ

AEQ BRAVO Manuel utilisateur

Manuels Équipement d'enregistrement populaires d'autres marques

KV2 Audio

KV2 Audio 500 Series Manuel utilisateur

Robotics Technologies

Robotics Technologies microBus-Cam II Manuel utilisateur

Seca

Seca 460 Manuel utilisateur

Cognex

Cognex MVS-8000 Series Manuel utilisateur

Mect

Mect MPNC006 Series Manuel utilisateur

Bad Caf

Bad Caf THE LEASH Manuel utilisateur

Strymon

Strymon NIGHTSKY Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manuel utilisateur

Tews Technologies

Tews Technologies TPMC465 Manuel utilisateur

Honeywell

Honeywell Excel 50 Manuel utilisateur

SeaLevel

SeaLevel COMM+8.LPCI Manuel utilisateur

Arturia

Arturia AUDIOFUSE STUDIO Manuel utilisateur

Rukra

Rukra RK-1240 Manuel utilisateur

Samson

Samson SCOM Manuel utilisateur

Dynacord

Dynacord DPS260 Manuel utilisateur

Nice

Nice Core Manuel utilisateur

Pyle Pro

Pyle Pro PSS8 Manuel utilisateur

RF-System

RF-System TinyGate Manuel d'utilisation et d'entretien
