AEMC 6417 Manuel utilisateur

Clamp-on Ground Tester

Model 6417

ENGLISH

USER MANUAL

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Statement of Compliance

Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

certiﬁes that this instrument has been calibrated

using standards and instruments traceable to

international standards.

We guarantee that at the time of shipping your

instrument has met its published speciﬁcations.

An NIST traceable certiﬁcate may be

requested at the time of purchase, or obtained

by returning the instrument to our repair and

calibration facility, for a nominal charge.

The recommended calibration interval for this

instrument is 12 months and begins on the date of

receipt by the customer. For recalibration, please

use our calibration services. Refer to our repair

and calibration section at .

Serial #: ________________________________

Catalog #: 2141.02

Model #: 6417

Please ﬁll in the appropriate date as indicated:

Date Received: _________________________________

Date Calibration Due: _______________________

Chauvin Arnoux®, Inc.

d.b.a AEMC®Instruments

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Clamp-on Ground Resistance Tester Model 6417

(1) Clamp-on Ground Tester

Model 6417

Cat. #2141.02

5WCalibration Loop

Cat. #2141.51

Bluetooth Adapter

Cat. #2126.45

Hard Accessory Case

Cat. #2141.50

Quick Start Guide

USB Stick with

DataView®Software & User Manual

PRODUCT PACKAGING

Shipping Contents:

Also Included:

(4) 1.5V AA Batteries

(1) Wrist Strap

(1) Safety Sheet (20 languages)

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

2Clamp-on Ground Resistance Tester Model 6417

Thank you for purchasing an AEMC Clamp-on Ground Resistance Tester.

For best results from your instrument and for your safety, read the enclosed

operating instructions carefully and comply with the precautions for use. These

products must be only used by qualied and trained users.

WARNING, risk of DANGER! The operator must refer to these instructions whenever

this danger symbol appears.

CAUTION! Risk of electric shock. The voltage at the parts marked with this symbol

may be dangerous.

Application or withdrawal authorized on conductors carrying dangerous voltages.

Type A current sensor as per IEC 61010-2-032.

Equipment is protected by double insulation.

The product has been declared recyclable after analysis of its life cycle in accordance

with the ISO14040 standard.

Important instructions to read and to fully understand.

Useful information or tip to read.

The CE marking guarantees conformity with European directives and with regulations

covering EMC.

The trash can with a line through it means that in the European Union, the product

must undergo selective disposal for the recycling of electric and electronic material,

in compliance with Directive WEEE 2002/96/EC.

Denition of Measurement Categories (CAT)

CAT IV Measurement Category IV corresponds to measurements taken at the

source of low-voltage installations.

Example: power feeders, counters and protection devices.

CAT III Measurement Category III corresponds to measurements on building

installations.

Example: distribution panel, circuit-breakers, machines or xed

industrial devices.

CAT II Measurement Category II corresponds to measurements taken on

circuits directly connected to low-voltage installations.

Example: power supply to domestic electrical appliances and portable

tools.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Clamp-on Ground Resistance Tester Model 6417

PRECAUTIONS FOR USE

This instrument and its accessories comply with safety standards EN 61010-1,

EN 61010-030, and EN 61010-2-032 for voltages of 600V in Category IV at an

altitude of less than 2000m with a pollution degree of not more than 2.

Failure to observe the safety instructions may result in electric shock, re,

explosion, and destruction of the instrument and of the installations.

■The operator and/or the responsible personnel must carefully read and clearly

understand the various precautions to be taken in use. Sound knowledge

and a keen awareness of electrical hazards are essential when using this

instrument.

■ If you use this instrument other than as specied, the protection it provides

may be compromised, thereby endangering you.

■Do not use the instrument on networks of which the voltage or category

exceeds those mentioned.

■Do not use the instrument if it seems to be damaged, incomplete, or poorly

closed.

■Before each use, check the condition of the insulation on housing. Any item

of which the insulation is deteriorated (even partially) must be set aside for

repair or scrapping.

■Use personal protection equipment systematically.

■ When handling the instrument, keep your ngers behind the physical guard.

■All troubleshooting and metrological checks must be performed by competent

and accredited personnel.

■Avoid impacts on the measurement head, in particular the air gap.

■Keep the surfaces of the air gap clean; even a little dirt can cause the clamp

to malfunction.

■All metal objects or wires connected to the electrical system should be

assumed to be lethal until tested. Grounding systems are no exception.

■Use extreme caution when using the instrument around energized electrical

equipment.

■Never attempt to use the instrument to twist or pry the ground electrode or

ground wire away from the equipment being grounded.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

4Clamp-on Ground Resistance Tester Model 6417

Table of Contents

1. INTRODUCTION .............................................................................................7

1.1 Receiving Your Shipment......................................................................7

1.2 Ordering Information.............................................................................7

1.2.1 Replacement Parts...................................................................7

2. PRODUCT FEATURES .....................................................................................8

2.1 Description............................................................................................8

2.2 Features................................................................................................9

2.3 Applications...........................................................................................9

2.4 Display................................................................................................10

2.5 Control Features .................................................................................12

2.6 Audible Signals ...................................................................................13

2.7 Rotary Switch Functions .....................................................................13

2.8 Button Functions.................................................................................14

3. PRINCIPLE OF OPERATION ..........................................................................15

4. SET-UP .......................................................................................................17

4.1 Menu Items .........................................................................................17

4.2 SET-UP Menu Displays ......................................................................17

4.3 Selecting a Specic Menu ..................................................................18

4.4 SET-UP Menus ...................................................................................18

4.5 Calibration Loop..................................................................................21

5. OPERATION.................................................................................................22

5.1 Inserting the Batteries.........................................................................22

5.2 Setting the Date and Time ..................................................................22

5.3 Display Example .................................................................................23

5.4 Turning the Instrument ON .................................................................23

5.5 Turning Bluetooth ON .........................................................................24

5.6 Turning the Instrument OFF................................................................24

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Clamp-on Ground Resistance Tester Model 6417

5.7 Standard and Advanced Modes..........................................................24

5.8 Memory...............................................................................................25

5.8.1 Memory Capacity....................................................................25

5.8.2 Storing Measurements into Memory.......................................25

5.8.3 Reading Stored Data..............................................................25

5.8.4 Erasing the Memory ...............................................................25

5.8.5 Using the ▲ and ▼ Buttons ...................................................26

5.8.6 Exporting Data to a PC...........................................................26

5.9 Alarm Management.............................................................................26

5.9.1 Voltage Alarm .........................................................................26

5.9.2 Current Alarm .........................................................................27

5.9.3 Impedance Alarm....................................................................27

5.9.4 No Alarm Detection.................................................................27

5.9.5 Priority of the Alarms ..............................................................28

6. MEASUREMENT MODES..............................................................................29

6.1 Rotary Position Ω+A...........................................................................29

6.1.1 Standard Mode.......................................................................29

6.1.2 Advanced Mode......................................................................30

6.1.3 General Information................................................................31

6.2 Rotary Position (A)..............................................................................33

6.2.1 Making a Measurement..........................................................33

6.3 Rotary Position - (MR) ........................................................................33

6.3.1 Displaying Stored Measurements...........................................33

7. DATAVIEW®SOFTWARE...............................................................................36

7.1 Installing DataView®............................................................................36

7.2 Ground Clamp Control Panel..............................................................38

8. ANDROID APPLICATION ..............................................................................39

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

6Clamp-on Ground Resistance Tester Model 6417

9. SPECIFICATIONS .........................................................................................43

9.1 Reference Conditions .........................................................................43

9.2 Electrical .............................................................................................43

9.2.1 Loop Resistance Measurement..............................................43

9.2.2 Loop Inductance Measurement..............................................44

9.2.3 Contact Voltage (Touch Voltage) ............................................44

9.2.4 Current Measurement.............................................................44

9.2.5 Power Supply .........................................................................45

9.3 Environmental.....................................................................................45

9.4 Mechanical..........................................................................................45

9.5 Safety..................................................................................................46

10. MAINTENANCE..........................................................................................47

10.1 Cleaning............................................................................................47

10.2 Battery Replacement ........................................................................47

10.3 Repair and Calibration......................................................................48

10.4 Technical and Sales Assistance........................................................48

10.5 Limited Warranty...............................................................................49

10.6 Warranty Repairs..............................................................................49

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Clamp-on Ground Resistance Tester Model 6417

1. INTRODUCTION

1.1 Receiving Your Shipment

Upon receiving your shipment, make sure that the contents are consistent with

the packing list. Notify your distributor of any missing items. If the equipment

appears to be damaged, le a claim immediately with the carrier and notify

your distributor at once, giving a detailed description of any damage. Save the

damaged packing container to substantiate your claim.

1.2 Ordering Information

Clamp-on Ground Resistance Tester Model 6417 ....................... Cat. #2141.02

Includes a hard carrying case, Bluetooth USB adapter, calibration loop, four 1.5V

AA batteries, quick start guide, and USB stick with DataView®software and user

manual.

1.2.1 Replacement Parts

Bluetooth USB Adapter Class 2........................................................Cat. #2126.45

Wrist Strap........................................................................................Cat. #2135.47

Hard Carrying Case..........................................................................Cat. #2141.50

5W Calibration Loop..........................................................................Cat. #2141.51

Order Accessories and Replacement Parts Directly Online

Check our Storefront at for availability

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

8Clamp-on Ground Resistance Tester Model 6417

2. PRODUCT FEATURES

2.1 Description

The Clamp-on Ground Resistance Tester Model 6417 measures grounding

electrodes and grid resistance without the use of auxiliary rods. Clamp-on ground

resistance testers can be used in multi-grounded systems without disconnecting

the ground system under test. The Model 6417 simply clamps around the

ground conductor or rod and measures the resistance to ground. By performing

measurements on intact ground systems, the user also veries the quality of the

grounding connections and bonds. Resistance and continuity of grounding loops

around pads and buildings can also be measured.

The Model 6417 includes a current measurement function. The ground tester’s

high sensitivity enables measurement of leakage current owing to ground or

circulating in ground loops from 0.2mA to 40A and resistances from 0.01 to

1500W.

Battery life information is displayed at power-up and the Auto Power OFF feature

can be enabled for power management. Additional features include the large

OLED (Organic Light Emitting Diode) display that ensures high readability of

data. The Buzzer and Auto Power OFF features can be disabled at any time.

The Model 6417 is equipped with an alarm function and a data storage function.

In the Alarm mode, the probe will audibly and visually indicate when the reading

is beyond an input set point. You can also have the alarm activate above or

below the set point. This alarm feature permits quick eld checks where only

“pass” or “fail” readings are required.

The data storage function logs up to 2000 measurements (Wand/or A). This

enables you to conduct eld surveys, and to retrieve and analyze the readings at

a later time. The alarm settings and stored data are saved on the ground tester

and remain stored even when the instrument is turned OFF. You can retrieve and

analyze the results at a later time with DataView®software or with an Android app

through the Bluetooth communication port.

Two new features unique to AEMC®are test frequency selection and touch

voltage indication.

The ability to select the test frequency provides more accurate measurements in

inductive environments.

Displaying voltage derived from current and resistance measurements provides

an extra level of safety for the user, indicating a potentially dangerous touch

condition.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Autres manuels pour 6417

Table des matières

Autres manuels AEMC Équipement de test

AEMC

AEMC 6240 Manuel utilisateur

AEMC

AEMC 6472 Manuel utilisateur

AEMC

AEMC SR601 Manuel utilisateur

AEMC

AEMC 6418 Manuel utilisateur

AEMC

AEMC OX III Series Manuel utilisateur

AEMC

AEMC OX 5022B Manuel utilisateur

AEMC

AEMC 6470-b Manuel utilisateur

AEMC

AEMC 6417 Manuel utilisateur

AEMC

AEMC 6416 Instructions d'installation et d'utilisation

AEMC

AEMC 6472 Manuel de service

AEMC

AEMC SR751 Manuel utilisateur

AEMC

AEMC 6418 Manuel utilisateur

AEMC

AEMC MF 300-6-2-10-HF Manuel utilisateur

AEMC

AEMC MA114 Manuel utilisateur

AEMC

AEMC MN210 Manuel utilisateur

AEMC

AEMC CM605 Manuel utilisateur

AEMC

AEMC Simple Logger AmpFlex AL24-2500 Manuel utilisateur

AEMC

AEMC SR652 Manuel utilisateur

AEMC

AEMC MN213 Manuel utilisateur

AEMC

AEMC OX 7102 Guide de configuration

AEMC

AEMC MN122 Manuel utilisateur

AEMC

AEMC 6470 Manuel utilisateur

AEMC

AEMC JM845A Manuel utilisateur

AEMC

AEMC OX7102-CII Manuel utilisateur

Manuels Équipement de test populaires d'autres marques

SMART

SMART KANAAD SBT XTREME 3G Series Manuel utilisateur

Agilent Technologies

Agilent Technologies BERT Serial Manuel utilisateur

Agilent Technologies

Agilent Technologies N3280A Manuel utilisateur

Vernier

Vernier Go Direct Voltage Manuel utilisateur

Lifeloc

Lifeloc R.A.D.A.R. Manuel utilisateur

Fluke

Fluke T5-600 Instructions d'utilisation et d'installation

Mercury

Mercury TSL01 Manuel utilisateur

MAHA

MAHA MBT Series Manuel utilisateur

Fuji Electric

Fuji Electric P-61 Manuel utilisateur

ETC

ETC SealerAtor Manuel utilisateur

Skyfine

Skyfine ETHYWAY V2 Manuel utilisateur

Appion

Appion G5 Twin Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0112A Manuel utilisateur

BW Technologies

BW Technologies MicroDock II Manuel utilisateur

Sun Nuclear

Sun Nuclear 1027 Manuel utilisateur

Biomark

Biomark HPR LITE READER Manuel utilisateur

Hioki

Hioki 3169-20 Manuel utilisateur

Ashcroft

Ashcroft ATE-100 Manuel utilisateur
