Sending voice message/alarm report via an PABX system .....................25
Dialing attempts for communicator ...........................................26
Dialing attempts for auto-dialer ..............................................26
Message repeats .........................................................27
Backup or non-backup reporting ............................................27
Listen-in enable and duration ...............................................28
Arm-disarm report.........................................................29
Selection of dialing combination .............................................29
Selection of dialing mode for calling the telephone central office..................30
Numbering beep tones for control panel identification ...........................30
Number of rings to pick-up telephone line ....................................31
Periodic report ...........................................................32
Power-up delay ...........................................................32
Periodic battery test .......................................................33
Dial tone and telephone line fault detects .....................................34
Putting the habitual isolation zones in memory for HOME mode ..................35
Recording the voice message...............................................35
Setting the system with default values ........................................36
Exit The Programming Mode ...................................................36
Description Of The Report Parameters (The Source Codes) .........................42
Client ID.................................................................42
User number ............................................................42
Zone status codes ........................................................42
System status codes ......................................................42
Check sum ..............................................................43
The Acknowledgement Signal for Communicator ..................................43
Interpreting The Report - Examples .............................................43
The Meaning Of The Answering Beeps ..........................................45
The Command Codes For Remote Access Control ................................45
Remote Arm-Disarm The System By Telephone ...................................46
Call For A Status Report ......................................................47
AC Power Failure And Restoration ..............................................48
Dynamic Battery Testing .......................................................48
Battery Low Indication And Auto Reset ..........................................48
Power-up Delay ..............................................................49
The Back-up Battery ..........................................................49
Function keys corresponding to DTMF symbols & instruction for sending report .....26
PROGRAMMING SUMMARY CHART .............................................37
COMMUNICATOR'S ALARM-STATUS REPORT FORMAT ............................41
ALARM--SYSTEM STATUS--TESTING EVENTS REPORTING MEDIA SUMMARY CHART . . 44
CONTROL THE SYSTEM REMOTELY BY TELEPHONE ..............................45
THE AC AND BATTERY POWER ................................................48
GENERAL SPECIFICATION.....................................................50
OPENING THE CABINET FOR SERVICE .........................................51
TABLE OF CONTENTS -- INSTALLATION SECTION
4
4HA-266
NOTE:
5 BEEPS
2 BEEPS+5 BEEPS
ARM PROHIBITED FORCED TO ARM
i) The system will terminate the session and hang up after the command is accepted.
ii) The answering beep of stands for unsuccessful command code entry,
please try again. If four incorrect attempts are made, the system will terminate the
session and hang up.
iii) The answering beep of stands for arm prohibited which
means that the system can not be armed due to faulty zone(s) existing. The
system will terminate the session and hang up after the beeps.
5. Hang up the telephone immediately to allow the communicator
of the system to ring the monitor
station as a result of armed or disarmed the system.
In case of or occurred, the communicator will always
ring the monitor station and will send a status report because it is a system problem.
The report will be sent 10 seconds after the answering beep is heard.
(if it is enabled, please see
INSTALLATION SECTION Location 76 and 80 for details)
THE COMMAND CODES FOR REMOTE ACCESS CONTROL--SUMMARY
REMOTE ACCESS THE SYSTEM BY TELEPHONE
USER CODE 1 6#
USER CODE 1 3#
USER CODE 1 #
CLIENT CODE #
NO.
A
B
C
D
COMMAND CODES
To arm the system if it is disarmed, or
To disarm the system if it is armed
To clear the alarm memory and keep the system in
disarmed mode
To clear the alarm memory and re-arm the system
Requesting the system to send a report of its currently
registered status to the monitor station or to an auto-pager
The report will be sent 10 seconds after the command code
is successfully entered, 2 beeps will be generated to
confirm successful code entry
MEANINGS
!
!
!
!
!
!
73
HA-266
