AEG TP7050TW Manuel utilisateur

USER

MANUAL

EN User Manual 2

Tumble Dryer

DE Benutzerinformation 25

Wäschetrockner

TP7050TW

CONTENTS

1. SAFETY INFORMATION.............................................................................................3

2. SAFETY INSTRUCTIONS.............................................................................................5

3. PRODUCT DESCRIPTION...........................................................................................7

4. CONTROL PANEL....................................................................................................... 7

5. PROGRAMME TABLE................................................................................................. 8

6. OPTIONS....................................................................................................................10

7. SETTINGS...................................................................................................................11

8. BEFORE FIRST USE................................................................................................... 12

9. DAILY USE..................................................................................................................13

10. HINTS AND TIPS..................................................................................................... 14

11. CARE AND CLEANING.......................................................................................... 15

12. TROUBLESHOOTING.............................................................................................17

13. TECHNICAL DATA..................................................................................................18

14. QUICK GUIDE.........................................................................................................20

15. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION

1369/2017........................................................................................................................22

16. GUARANTEE .......................................................................................................... 24

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you

impeccable performance for many years, with innovative technologies that help

make life simpler features you might not find on ordinary appliances. Please

spend a few minutes reading to get the very best from it.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.aeg.com/webselfservice

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.aeg.com

1. SAFETY INFORMATION

Before beginning the installation and use of this

appliance, carefully read the supplied instructions. The

manufacturer is not responsible for any injuries or

damages that are the result of incorrect installation or

usage. Always keep the instructions in a safe and

accessible location for future reference.

- Read the supplied instructions.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent

disability.

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning the use of the appliance in a

safe way and understand the hazards involved.

•Children between 3 and 8 years of age and persons

with very extensive and complex disabilities shall be

kept away from the appliance unless continuously

supervised.

•Children of less than 3 years of age should be kept

away from the appliance unless continuously

supervised.

•Do not let children play with the appliance.

•Keep all packaging away from children and dispose of

it appropriately.

•Keep detergents away from children.

•Keep children and pets away from the appliance when

the door is open.

•If the appliance has a child safety device, it should be

activated.

•Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

ENGLISH 3

1.2 General Safety

•Do not change the specification of this appliance.

•If the tumble dryer is put on top of a washing

machine, use the stacking kit. The stacking kit,

available from your authorized vendor, can be used

only with the appliance specified in the instructions

supplied with the accessory. Read it carefully before

installation (refer to the Installation leaflet).

•The appliance can be installed as freestanding or

below a kitchen counter with correct space (refer to

the Installation leaflet).

•Do not install the appliance behind a lockable door, a

sliding door or a door with a hinge on the opposite

side, that would prevent the appliance door from

being fully open.

•The ventilation opening in the base must not be

covered by a carpet, mat, or any floor covering.

•WARNING: The appliance must not be supplied

through an external switching device, such as a timer,

or connected to a circuit that is regularly switched on

and off by a utility.

•Connect the mains plug to the mains socket only at

the end of the installation process. Make sure that the

mains plug is accessible after installation.

•If the mains power supply cable is damaged, it must

be replaced by the manufacturer, its Authorised

Service Centre or similarly qualified persons to avoid

an electrical hazard.

•Do not exceed the maximum load of 8 kg (refer to the

"Programme chart" chapter).

•Do not use the appliance if items have been soiled

with industrial chemicals.

•Wipe away lint or packaging debris that has

accumulated around the appliance.

•Do not run the appliance without a filter. Clean the lint

filter before or after each use.

•Do not dry unwashed items in the tumble dryer.

www.aeg.com

•Items that have been soiled with substances such as

cooking oil, acetone, alcohol, petrol, kerosene, spot

removers, turpentine, waxes and wax removers should

be washed in hot water with an extra amount of

detergent before being dried in the tumble dryer.

•Items such as foam rubber (latex foam), shower caps,

waterproof textiles, rubber backed articles and clothes

or pillows fitted with foam rubber pads should not be

dried in the tumble dryer.

•Fabric softeners, or similar products, should only be

used as specified by the product manufacturer’s

instructions.

•Remove all objects from items that could be a source

of fire ignition such as lighters or matches.

•WARNING: Never stop a tumble dryer before the end

of the drying cycle unless all items are quickly

removed and spread out so that the heat is

dissipated.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the

socket.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Follow the installation instructions

supplied with the appliance.

• Always take care when moving the

appliance as it is heavy. Always use

safety gloves and enclosed footwear.

• Do not install or use the appliance

where the temperature can be lower

than 5°C or higher than 35°C.

• The floor area on which the appliance

is to be installed must be flat, stable,

heat resistant and clean.

• Make sure that there is air circulation

between the appliance and the floor.

• Always keep the appliance vertical

when it is being moved.

• The rear surface of the appliance

must be put against a wall.

• When the appliance is in its

permanent position, check if it is

levelled correctly with the aid of a

spirit level. If it is not, adjust the feet

accordingly.

2.2 Electrical connection

WARNING!

Risk of fire and electric

shock.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• The appliance must be earthed.

• Make sure that the parameters on the

rating plate are compatible with the

electrical ratings of the mains power

supply.

ENGLISH 5

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• Do not touch the mains cable or the

mains plug with wet hands.

• This appliance complies with the

E.E.C. Directives.

2.3 Use

WARNING!

Risk of injury, electric shock,

fire, burns or damage to the

appliance.

• This appliance is for household use

only.

• Do not dry damaged (torn, frayed)

items that contain padding or fillings.

• Only dry fabrics which are suitable for

drying in a tumble dryer. Follow the

instructions on the fabric label.

• If you have washed your laundry with

a stain remover start an extra rinse

cycle before you start the dryer.

• Do not drink or prepare food with the

condensed water/distilled water. It

can cause health problems to people

and pets.

• Do not sit or stand on the open door

of the appliance.

• Do not dry dripping wet clothes in a

tumble dryer.

2.4 Care and cleaning

WARNING!

Risk of injury or damage to

the appliance.

• Do not use water spray and steam to

clean the appliance.

• Clean the appliance with a moist soft

cloth. Only use neutral detergents. Do

not use any abrasive products,

abrasive cleaning pads, solvents or

metal objects.

• To prevent damage to the cooling

system be careful when you clean the

appliance.

2.5 Compressor

WARNING!

Risk of damage to the

appliance.

• The compressor and its system in the

tumble dryer is filled with the special

agent which is free from fluoro-chloro-

hydrocarbons. This system must stay

tight. The damage of the system can

cause a leakage.

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains electrical and water supplies.

• Cut off the mains electrical cable

close to the appliance and dispose of

it.

• Remove the door catch to prevent

children or pets from becoming

trapped in the drum.

• Dispose of the appliance in

accordance with local requirements

for the disposal of Waste Electrical

and Electronic Equipment (WEEE).

www.aeg.com

3. PRODUCT DESCRIPTION

1 2

1Water container

2Control panel

3Appliance door

4Filter

5Rating plate

6Airflow slots

7Heat Exchanger lid

8Heat Exchanger cover

9Adjustable feet

For ease of loading laundry

or ease of installation the

door is reversible. (see

separate leaflet).

4. CONTROL PANEL

789 6 5

1Programme knob and RESET

switch

2Display

3Zeit (Time Dry) touch button

4Zeitvorwahl (Delay Start) touch

button

5Start/Pause touch button

6Knitterschutz (Extra Anticrease)

touch button

7Reverse Plus touch button

8Indicator: clean filter, drain

water container, check

condenser

9On/Off button

ENGLISH 7

Press the touch buttons with

your finger in the area with

the symbol or name of the

option. Do not wear gloves

when you operate the

control panel. Make sure

that the control panel is

always clean and dry.

4.1 Display

Symbol on the display Symbol description

child lock on

wrong selection or knob is in the "Reset" posi-

tion

programme duration

- time Drying duration

- delay start duration

5. PROGRAMME TABLE

Programme Load 1) Properties / Fabric type2)

3) Baumwolle (Cot-

ton) Eco 8 kg

Cycle to be used to dry cotton with

"cotton cupboard" dryness level,

with maximum energy saving. /

Baumwolle (Cotton)

Extratrocken (Extra Dry) 8 kg Drying level: extra dry. /

Baumwolle (Cotton)

Schranktrocken (Cup-

board Dry)

8 kg

Cycle defined to dry all types of

cotton ready to store (cupboard

dry). /

Baumwolle (Cotton)

Bügeltrocken (Iron Dry) 8 kg Drying level: suitable for ironing. /

Mischgewebe (Synthetics)

Extratrocken (Extra Dry) 3,5 kg Drying level: extra dry. /

www.aeg.com8

Programme Load 1) Properties / Fabric type2)

Mischgewebe (Synthetics)

Schranktrocken (Cup-

board Dry)

3,5 kg Drying level: cupboard dry. /

Leichtbügeln (Easy Iron) 1 kg (or 5

shirts)

Easy care fabrics for which a mini-

mum of ironing is necessary. The

drying results can be different from

one type of fabric to another.

Shake the items before putting

them in the appliance. When the

programme has ended, immedi-

ately remove the items and put

them on a hanger.

Zeitprogramm (Time Dry-

ing) 5 kg

With this programme you can use

the Zeit (Time Dry) option and set

the programme duration.

Drying time should be adequate to

the load, e.g. 2h for 5 kg of cotton.

Mix (Mixed) 3kg

Cotton and synthetic fabrics. Low

temperature programme. Delicate

programme with warm air. /

Bettwäsche (Bedlinen) 3kg

Bed linen such as single and dou-

ble sheets, pillowcases, duvet cov-

er. /

Seide (Silk) 1 kg Silk suitable for tumble drying. /

Wolle (Wool) 1 kg

Woollen fabrics. Gentle drying for hand-washa-

ble woollens. Remove items immediately when

the programme is completed.

Denim 4 kg

Leisure clothing such as jeans,

sweat-shirts of different material

thicknesses (e.g. at the neck, cuffs

and seams).

Feinwäsche (Delicates) 4 kg Delicate fabrics such as viscose,

rayon, acrylic, and their blends. /

1) The maximum weight refers to dry items.

2) For fabric mark meaning see chapter

HINTS AND TIPS: Preparing the laundry.

3) The Baumwolle (Cotton) Schranktrocken (Cupboard Dry) ECO programme is the “Standard cot-

ton programme” according to Commission Regulation EU No. 392/2012. It is suitable for drying normal

wet cotton laundry and it is the most efficient programme in terms of energy consumption for drying wet

cotton laundry.

ENGLISH 9

6. OPTIONS

6.1 Reverse Plus

Increase drum reversing frequency to

reduce items twisting and entanglement.

To increase uniformity of drying result

and help reduce creases. Recommended

for large or long items (e.g. sheets,

trousers, long dresses)"

6.2 Knitterschutz (Extra

Anticrease)

Extends the anti-crease phase by 60

minutes at the end of the drying cycle.

This function reduces creases. The

laundry can be removed during the anti-

crease phase.

6.3 Zeit (Time Dry)

You can set the programme duration,

from a minimum of 10 minutes to a

maximum of 2 hours. The required

duration is related to the quantity of

laundry in the appliance.

We recommend that you set

a short duration for small

quantities of laundry or for

only one item.

6.4 Zeit (Time Dry) on Wolle

(Wool) programme

Option suitable for Wolle (Wool)

programme to adjust final dryness level.

6.5 Options table

Programmes1) Reverse Plus Knitterschutz

(Extra Anticrease) Zeit (Time Dry)

Baumwolle (Cot-

ton) Eco ■

Baumwolle (Cotton)

Extratrocken (Extra

Dry)

■ ■

Baumwolle (Cotton)

Schranktrocken (Cup-

board Dry)

■ ■

Baumwolle (Cotton)

Bügeltrocken (Iron Dry) ■ ■

Mischgewebe (Syn-

thetics)

Extratrocken (Extra

Dry)

■ ■

Mischgewebe (Syn-

thetics)

Schranktrocken (Cup-

board Dry)

■ ■

www.aeg.com10

Table des matières

Langues :

Autres manuels AEG Séchoir

AEG

AEG LAVATHERM 7DBM730G Manuel utilisateur

AEG

AEG LAVATHERM 65270AC Manuel utilisateur

AEG

AEG LAVATHERM T6DCE821B Manuel utilisateur

AEG

AEG T8DBA2 Manuel utilisateur

AEG

AEG LAVATHERM 65179AV Manuel utilisateur

AEG

AEG TR3050TW Manuel utilisateur

AEG

AEG T8DBG48WC Manuel utilisateur

AEG

AEG T8DEC846R Manuel utilisateur

AEG

AEG LAVATHERM 6DBG720N Manuel utilisateur

AEG

AEG LAVATHERM 86580IH Manuel utilisateur

AEG

AEG T8DEE48S Manuel utilisateur

AEG

AEG TR822N94P Manuel utilisateur

AEG

AEG T6DB82GP Manuel utilisateur

AEG

AEG LAVATHERM 56740 Manuel utilisateur

AEG

AEG LAVATHERM 740 MICROCOMPUTER Manuel utilisateur

AEG

AEG lavatherm 540 microcomputer Manuel utilisateur

AEG

AEG TR78432B Manuel utilisateur

AEG

AEG TR808A2OB Manuel utilisateur

AEG

AEG LAVATHERM 86285IC Manuel utilisateur

AEG

AEG LAVATHERM 6DB82GP Manuel utilisateur

AEG

AEG LAVATHERM 75280AC Manuel utilisateur

AEG

AEG TR3060TW Manuel utilisateur

AEG

AEG TR959M6BC Manuel utilisateur

AEG

AEG TR938H2C Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur

Frigidaire

Frigidaire CAQE7077KW0 Manuel du propriétaire
