AEG LAVATHERM T 520 Manuel utilisateur

LAVATHERM T 520 electronic520 electronic

Condenser Dryer

Operating Instructions

Dear customer,

Please read these operating instructions through carefully.

Please make sure you read the safety instructions on the first pages of

these operating instructions! Keep the operating instructions for future

reference. Pass them on to any future owners.

1With the warning triangle and/or by means of key words (Danger!,

Caution!, Attention!), information is emphasized which is important

for your safety or the correct functioning of the appliance. It is

essential that this information is observed.

0This symbol guides you step by step when operating the appliance.

3Next to this symbol you receive additional information and practical

tips on using the appliance.

2Tips and information about the economical and environmentally

friendly use of the machine are marked with the clover.

• These operating instructions contain information about how to

independently solve any problems which may arise. See "Something not

working".

nte

on env

ronmenta

y paper ...

Whoever thinks ecologically also acts ecologically.

Content

Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Environmental protection tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Description of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Front view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

The program selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Before using the appliance for the first time . . . . . . . . . . . . . . . . . . . . . 14

Brief instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Prepare the laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Open the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Load the laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Closing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Select the drying program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Start the drying program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Removing laundry or loading laundry when necessary . . . . . . . . . . . . . . . . 17

End of the drying process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Removing the laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Empty the water reservoir . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Cleaning the door seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Clean the fluff filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Cleaning the condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Switch-off the dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Program tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

A small glossary of textile information . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Care symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Content

Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Cleaning the condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Cleaning the filter area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Cleaning the drum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Cleaning the panel and operating parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Cleaning the door seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Something not working? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Door Reversal Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Installation and electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Information for the electrician . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Special accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Drainage kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Stacking kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Important Safety Information

1Important Safety Information

The safety of AEG electrical appliances complies with the established

technical principles and statutory equipment safety regulations. Never-

theless, as manufacturer we have to draw your attention to the follow-

ing safety instructions.

General safety

• Repairs of the dryer may be carried out only by trained personnel.

Incompetently carried out repairs can entail considerable hazards for

the user. Please get in touch with our customer service or with an

authorised AEG dealer when repair is necessary.

• Before commencing operation please make sure that the nominal volt-

age and type of supply specified on the type plate of the appliance cor-

respond to the actual nominal voltage and supply type at the place of

utilisation. The fuse rating is also specified on the type plate.

• Never operate the dryer when the mains cable is damaged or when the

operator control mask, work plate or base shrouding are damaged such

that there is direct access to the interior of the appliance.

• Switch-off the dryer before carrying out any cleaning, care and main-

tenance tasks! You are quite safe if you disconnect the mains plug from

the power outlet or – if the electrical connection is permanent – if you

switch-off the circuit breaker in the fusebox or screw the fuse cartridge

right out of its holder.

• Never pull on the cable to disconnect the mains plug from the power

outlet. Always grasp and pull-out the plug.

• Don’t lean on the opened door; this could make the appliance fall over.

• Don’t use a water jet to spray-down the appliance. Danger of electric

shock!

• When closing the door, please check that the washing is not caught in

it.

• If you interrupt the drying process to take out laundry, bear in mind

that the laundry and the drum could be hot.

• Adaptors and extension cables must not be used. There is risk of fire

because of overheating!

Important Safety Information

Safety of children

• Children are often not aware of the dangers involved when handling

electrical equipment. Therefore provide the necessary supervision of

children when operating the appliance and do not let children play

with the dryer – there is a danger that children could become trapped

inside the appliance.

• Packaging parts (e.g. films, styropore) can be dangerous for children.

Danger of suffocation! Keep packaging parts out of reach of children.

• Make sure that children or small animals do not climb into the drum of

the dryer. For this purpose keep the door of the dryer closed when the

appliance is not in use.

Utilisation in accordance with the intended purpose

• Conversions or modifications of the dryer are forbidden for safety rea-

sons.

• Use the dryer only to dry ordinary household laundry! The manufac-

turer accepts no liability for any damage resulting from incorrect oper-

ation or utilisation for an unintended purpose.

• Dry only laundry which has been washed in water. In particular, textiles

which have been treated with inflammable cleaning agents and sol-

vents (petrol-ether, alcohol, stain remover and similar materials) must

not be dried in the dryer. Danger of fire! Explosion hazard!

• Laundry items containing sponge rubber or rubber-like materials must

not be dried in the dryer. Danger of fire!

• Washing that is in poor condition (heavily worn) and items with loose

fillings (cushions) that could break open must not be dried or refreshed.

There is a risk of fire!

• Washing with rigid components (foot mats) will cover the air slots; the

slots will also be covered if the drum is overfilled. Observe the maxi-

mum load of 5 kg. There is a risk of overheating which could cause a

fire!

• Only dry washing that does not contain any explosive objects (fire

lighters, spray cans). There is a risk of fire or an explosion!

• Clean the fluff filter after each drying procedure.

• Clean the condenser regularly.

• In the case of washer / dryer tower combinations, do not place any

objects on the dryer during use as they could drop down.

Important Safety Information

Installation and connection

• Check the dryer for Transportation damage. Never connect-up a dam-

aged appliance! Contact your supplier if the appliance is damaged.

• If the tumble dryer has to be carried, first remove the plinth!

• Do not set-up the dryer in frost-endangered rooms!

• Set-up the dryer horizontal!

• If the dryer is placed adjacent to a gas, coal or electric cooking stove,

interpose a thermally insulating non-combustible plate between the

dryer and the stove (dimensions: 85x57,5cm).

• Do not place the dryer on high-pile carpet floors!

This would hinder air circulation at the ventilation slots!

• The electric power plug connector of the appliance must remain acces-

sible even after installation.

• Check that the tumble dryer is not standing on the mains cable.

• The technical conditions of the electric power supply company for

making fixed connections of electrical appliances to the mains require

that such connections may only be made by an authorised electrician.

General Information

3 General Information

• Starched washing leaves traces of starch on the drum and therefore

should not be placed in the tumble dryer.

• If you exceed the maximum load stipulated in the program table your

washing is more likely to get creased! For very delicate fabrics you

should only fill in 1.5kg washing at the most.

• For your information: 70 per cent of fabric wear is caused by being

worn, 20 per cent by washing and only 10 per cent by being dried in a

tumble dryer. As the fabric is worn down, fluff gathers in the fluff fil-

ter. When using a tumble dryer, only approx. 0.03g fluff per kilo-

gramme washing is produced.

Disposal

2 Disposal

Packaging

Dispose of the packaging material!

Dispose of the packaging material of your tumble dryer correctly. All

the packaging materials used are harmless to the environment and can

be recycled.

• Plastic parts are marked with standard international abbreviations:

– >PE< for polyethylene, e.g. sheet wrapping material

– >PS< for polystyrene, e.g. padding material (always CFC-free)

– >POM< for polyoxymethylene, e.g. plastic clips

Cardboard packaging is manufactured from recycled paper and should

be deposited in the waste paper collection for recycling.

Disposal of the old appliance!

When you eventually stop using your tumble dryer please bring it to

the nearest recycling centre or to your dealer who will take it back for a

small fee.

Warning! When disposing of the tumble dryer, pull out the plug, cut

off the flex, dispose of the plug and remaining flex and destroy the

door lock. This hinders children from locking themselves in and endan-

gering their lives.

The materials can be recycled in accordance with their markings. Stan-

dard tools (crosshead screwdriver, hammer) are sufficient to dismantle

the old appliance.

Environmental protection tips

2 Environmental protection tips

• Your laundry will become light and soft in the tumble dryer even with-

out a fabric softening agent.

• Loosen your laundry before loading it into the dryer. This helps to pre-

vent lengthy running times and creasing. Ensure your laundry is well

spun.

• Remove as much water as possible from the washing before drying!

This is based on the principle: the better you spin the washing before

drying the more economical the dryer is.

In the following table we give an overview of specific electric con-

sumption data depending on the spinning speed. This information is

valid for 5kg laundry dried with the program COTTONS CUPBOARD DRY

(KATOEN KAST-DROOG):

• Never obstruct the ventilation slits at the base of the dryer!

• Ensure that the room is well ventilated!

• Observe the maximum load instructions. Whenever possible, dry full

loads.

Spinning/wringing out: Drying cycle:

Revolutions per

minute

Residual dampness Time required in

minutes

Energy requirement

in kWh

in litres in %

800 3.5 70 90 3.5

1000 3.0 59 85 3,0

1200 2.7 53 75 2.7

1400 2.5 50 70 2.6

1600 2.2 44 65 2.5

Autres manuels pour LAVATHERM T 520

Table des matières

Autres manuels AEG Séchoir

AEG

AEG KO-LAVAMAT 88840 Manuel utilisateur

AEG

AEG LAVATHERM T65179AV Manuel utilisateur

AEG

AEG Lavatherm Compact Manuel utilisateur

AEG

AEG Lavatherm Electronic Manuel utilisateur

AEG

AEG LAVATHERM 8DBG48S Manuel utilisateur

AEG

AEG T7DEE834 Manuel utilisateur

AEG

AEG LAVATHERM 56800 Manuel d'utilisation

AEG

AEG T8DBG48S Manuel utilisateur

AEG

AEG LAVATHERM 65179AV Manuel utilisateur

AEG

AEG LAVATHERM 320 U Manuel utilisateur

AEG

AEG Lavatherm 450 R Manuel utilisateur

AEG

AEG LAVATHERM 37320 electronic Manuel utilisateur

AEG

AEG LAVATHERM 7DBE835 Manuel utilisateur

AEG

AEG LAVATHERM 5127AC Manuel utilisateur

AEG

AEG HE 181 Manuel utilisateur

AEG

AEG Lavatherm Electronic Manuel utilisateur

AEG

AEG LAVATHERM 320 U Manuel utilisateur

AEG

AEG T6DB682CBW Manuel utilisateur

AEG

AEG TR822N94P Manuel utilisateur

AEG

AEG LAVATHERM 8DEE95S Manuel utilisateur

AEG

AEG T8DEN95CS Manuel utilisateur

AEG

AEG LAVATHERM T65170AV Manuel utilisateur

AEG

AEG ABSOLUTECARE T8DEE68SC Manuel utilisateur

AEG

AEG LAVATHERM 76785IH3 Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur

Frigidaire

Frigidaire CAQE7077KW0 Manuel du propriétaire
