AEG LAVATHERM 65170AV Manuel utilisateur

EN User Manual 2

Tumble Dryer

DE Benutzerinformation 20

Wäschetrockner

LAVATHERM 65170AV

CONTENTS

1. SAFETY INFORMATION...........................................................................................3

2. SAFETY INSTRUCTIONS.......................................................................................... 5

3. ACCESSORIES...........................................................................................................6

4. PRODUCT DESCRIPTION........................................................................................ 7

5. CONTROL PANEL.....................................................................................................8

6. PROGRAMME TABLE...............................................................................................8

7. OPTIONS................................................................................................................... 9

8. SETTINGS................................................................................................................ 11

9. BEFORE FIRST USE.................................................................................................11

10. DAILY USE............................................................................................................. 11

11. HINTS AND TIPS...................................................................................................12

12. CARE AND CLEANING........................................................................................ 13

13. TROUBLESHOOTING...........................................................................................14

14. TECHNICAL DATA............................................................................................... 15

15. INSTALLATION..................................................................................................... 16

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you

impeccable performance for many years, with innovative technologies that help

make life simpler features you might not find on ordinary appliances. Please

spend a few minutes reading to get the very best from it.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.aeg.com

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.aeg.com

1. SAFETY INFORMATION

Before the installation and use of the appliance,

carefully read the supplied instructions. The

manufacturer is not responsible if an incorrect

installation and use causes injuries and damages. Always

keep the instructions with the appliance for future

reference.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent

disability.

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

•Do not let children play with the appliance.

•Children of less than 3 years should be kept away

unless continuously supervised.

•Keep all packaging away from children.

•Keep all detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•If the appliance has a child safety device, we

recommend you activate it.

•Cleaning and user maintenance shall not be made by

children without supervision.

1.2 General Safety

•Do not change the specification of this appliance.

•If the tumble dryer is put on top of a washing

machine, use the stacking kit. The stacking kit,

available from your authorized vendor, can be used

only with the appliance specified in the instructions,

ENGLISH 3

supplied with the accessory. Read it carefully before

installation (Refer to the Installation leaflet).

•The appliance can be installed as freestanding or

below the kitchen counter with correct space (Refer to

the Installation leaflet).

•Do not install the appliance behind a lockable door, a

sliding door or a door with a hinge on the opposite

side, where the appliance door can not be fully

opened.

•The ventilation openings in the base (if applicable)

must not be obstructed by a carpet.

•Connect the mains plug to the mains socket only at

the end of the installation. Make sure that there is

access to the mains plug after the installation.

•Ensure you have good ventilation in the installation

room to avoid the back flow of gases into the room

from appliances burning other fuels, including open

fires.

•Exhaust air must not be discharged into a flue which is

used for exhausting fumes from appliances burning

gas or other fuels. (if applicable)

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

•Obey the maximum load volume of 7kg (refer to the

“Programme chart” chapter).

•Do not use the appliance if industrial chemicals have

been used for cleaning.

•Wipe away lint that has accumulated around the

appliance.

•Do not run the appliance without a filter. Clean the lint

filter before or after each use.

•Do not dry unwashed items in the tumble dryer.

•Items that have been soiled with substances such as

cooking oil, acetone, alcohol, petrol, kerosene, spot

removers, turpentine, waxes and wax removers should

be washed in hot water with an extra amount of

detergent before being dried in the tumble dryer.

www.aeg.com

•Items such as foam rubber (latex foam), shower caps,

waterproof textiles, rubber backed articles and clothes

or pillows fitted with foam rubber pads should not be

dried in the tumble dryer.

•Fabric softeners, or similar products, should be used

as specified by the fabric softener instructions.

•Remove all objects from pockets such as lighters and

matches.

•Never stop a tumble dryer before the end of the

drying cycle unless all items are quickly removed and

spread out so that the heat is dissipated.

•The final part of a tumble dryer cycle occurs without

heat (cool down cycle) to ensure that the items are left

at a temperature that ensures that the items will not

be damaged.

•Before maintenance, deactivate the appliance and

disconnect the mains plug from the mains socket.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Obey the installation instruction

supplied with the appliance.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Do not install or use the appliance

where the temperature is less than

5°C or higher than 35°C.

• Make sure that the floor where you

install the appliance is flat, stable,

heat resistant and clean.

• Make sure that there is air circulation

between the appliance and the floor.

• Always move the appliance vertically.

• The rear surface of the appliance

must be put against the wall.

• When the appliance is put in its

permanent position, check if it is fully

level with the aid of a spirit level. If it

is not, adjust the feet until it is.

2.2 Electrical connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not, contact

an electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• Do not touch the mains cable or the

mains plug with wet hands.

• Only for UK and Ireland. The

appliance has a 13 amp mains plug. If

it is necessary to change the fuse in

the mains plug, use a 13 amp ASTA

(BS 1362) fuse.

• This appliance complies with the

E.E.C. Directives.

ENGLISH 5

2.3 Use

WARNING!

Risk of injury, electrical

shock, fire, burns or damage

to the appliance.

• Use this appliance in a household

only.

• Do not dry the damaged items which

contain padding or fillings.

• Only dry fabrics which are applicable

to dry in the tumble dryer. Follow the

instructions on the fabric label.

• If you have washed your laundry with

a stain remover start an extra rinse

cycle before you start the dryer.

• Do not drink or prepare food with the

condensed water/distilled water. It

can cause health problems to people

and pets.

• Do not sit or stand on the open door.

• Do not dry dripping wet clothes in the

tumble dryer.

2.4 Care and cleaning

WARNING!

Risk of injury or damage to

the appliance.

• Do not use water spray and steam to

clean the appliance.

• Clean the appliance with a moist soft

cloth. Only use neutral detergents. Do

not use abrasive products, abrasive

cleaning pads, solvents or metal

objects.

2.5 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

3. ACCESSORIES

3.1 Stacking kit

Product name: SKP11.

Available from your authorized dealer.

Stacking kit can be used only with the

washing machines specified in the

leaflet. See leaflet attached. Read

carefully the instructions supplied with

the kit.

3.2 Pedestal with the drawer

Product name: PDSTP10.

www.aeg.com

Available from your authorized dealer.

To put the appliance higher at the level

which helps to easy load and remove the

laundry.

The drawer can be use for laundry

storage e.g. : towels, cleaning products

and more. Read carefully the instructions

supplied with the accessory.

3.3 Vent kit

Universal kit for vented dryers where an

outdoor outlet is not possible. The tank

collects lint and condensation, thus

avoiding dirt and damage due to

moisture in the room where the tumble

dryer is placed.

Read carefully the instructions supplied

with the kit.

4. PRODUCT DESCRIPTION

1Control panel

2Appliance door (reversible)

3Primary Filter

4Adjustable feet

5Plastic ring

6Side/rear ventilation opening

7Rating plate

ENGLISH 7

5. CONTROL PANEL

1 2

4 36789 5

1Programme knob and OFF switch

2Push button Startuitstel (Delay Start)

3Indication lamp: clean the filter

4Push button Start/Pauze (Start/Pause)

5Function status LED

6Push button Zoemer (Buzzer)

7Push button Anti-kreuk (Anticrease)

8Push button Sensitive (Sensitive)

9Push button Behoedzaam (Delicate)

6. PROGRAMME TABLE

Programmes Type of load Load (max.)1) /

Fabric mark

Katoen (Cotton)

Extra Droog (Extra Dry) Drying level: extra dry. 7kg/

Intensief Droog

(Strong Dry) Drying level: strong dry. 7kg/

Kastdroog (Cupboard)

2) 3) Drying level: cupboard dry. 7kg/

Strijkdroog (Iron Dry) 2) Drying level: applicable for iron. 7kg/

Synthetica (Synthetic)

Extra Droog (Extra Dry) Drying level: extra dry. 3kg/

Kastdroog (Cup-

board) 2) Drying level: cupboard dry. 3kg/

Strijkdroog (Iron Dry) Drying level: applicable for iron. 3kg/

www.aeg.com8

Programmes Type of load Load (max.)1) /

Fabric mark

Speciaal (Special)

30 min Time programme to dry individual items of

laundry. 1kg/

Opfrissen (Refresh) Refreshing a textiles that were in storage. 1kg

Beddengoed (Bed Lin-

en)

To dry bed linen such as: single and double

sheet, pillowcase, bedspread. 2kg/

Jeans

Leisure clothing such as jeans, sweat-shirts

of different material thicknesses (e.g. at the

neck, cuffs and seams). 7kg/

Sportkleding (Sports) Sportswear, thin and light fabrics, microfib-

er, polyester, which are not ironed. 2kg/

Strijkvrij (Easy Iron)

Easy care fabrics for which a minimum of

ironing is necessary. The drying results can

be different from one type of fabric to the

other. Shake the items before you put them

in the appliance. When the programme is

completed, Immediately remove the items

and put them on a hanger.

1kg (or 5 shirts)/

Wol Opfrissen (Wool

Refresh)

Refreshing a wool fabrics. Wool items be-

come soft and cosy. Remove the items im-

mediately after the programme end.

1kg

1) The maximum weight refers to dry items.

2) For test institutes only: Standard programmes for tests are specified in the EN 61121 document.

3) The Katoen (Cotton) Kastdroog (Cupboard) programme is the “Standard cotton programme”

and it is suitable to dry normal wet cotton laundry and it is the most efficient programme in terms of en-

ergy consumption for drying wet cotton laundry.

7. OPTIONS

7.1 Behoedzaam (Delicate)

With this option you can set a delicate

drying programme that has a low

temperature. Use this option with a

fabrics that have the symbol on the

fabric label (e.g. acrylic, viscose).

7.2 Sensitive (Sensitive)

To dry lightly of fabrics that are

frequently worn. Programme starts on full

heat setting, which is then decrease as

the programme continue to be lightly to

the laundry.

7.3 Anti-kreuk (Anticrease)

Extends of 60 minutes the standard

anticrease phase (30 minutes) at the end

of the drying cycle. This function

prevents the laundry from creases. The

laundry can be removed during the

anticrease phase.

7.4 Zoemer (Buzzer)

you can hear the buzzer at the:

• cycle end

• start and end of crease guard phase

• cycle interruption

ENGLISH 9

The buzzer function is by default always

on. You can use this function to activate

or deactivate the sound.

You can activate the Zoemer

(Buzzer) option with all

programmes.

7.5 Options table

Programmes1) Behoedzaam (Deli-

cate)

Sensitive (Sensi-

tive)

Anti-kreuk (Anti-

crease)

Katoen (Cotton)

Extra Droog (Extra Dry) ■ ■ ■

Intensief Droog

(Strong Dry) ■ ■ ■

Kastdroog (Cupboard) ■ ■ ■

Strijkdroog (Iron Dry) ■ ■ ■

Synthetica (Synthetic)

Extra Droog (Extra Dry) ■ ■ ■

Kastdroog (Cupboard) ■ ■ ■

Strijkdroog (Iron Dry) ■ ■ ■

Speciaal (Special)

30 min ■■

Opfrissen (Refresh) ■■

Beddengoed (Bed Lin-

en) ■■

Jeans ■ ■ ■

Sportkleding (Sports) ■■

Strijkvrij (Easy Iron) ■■

Wol Opfrissen (Wool

Refresh)

1) The Behoedzaam (Delicate) and Sensitive (Sensitive) functions cannot be set together.

www.aeg.com10

Autres manuels pour LAVATHERM 65170AV

Table des matières

Langues :

Autres manuels AEG Séchoir

AEG

AEG TR749M4OB Manuel utilisateur

AEG

AEG T6DBG822N Manuel utilisateur

AEG

AEG LAVATHERM T97689IH Manuel utilisateur

AEG

AEG LAVATHERM 75280AC Manuel utilisateur

AEG

AEG LAVATHERM 57520 electronic Manuel utilisateur

AEG

AEG Minerva Manuel d'instructions

AEG

AEG LAVATHERM 56600 Manuel utilisateur

AEG

AEG T9DEC866R Manuel utilisateur

AEG

AEG LAVATHERM TP7071TWF Manuel utilisateur

AEG

AEG LAVATHERM 97689IH3 Manuel utilisateur

AEG

AEG T8DBE48S Manuel utilisateur

AEG

AEG T7DBK73P Manuel utilisateur

AEG

AEG LAVATHERM 86580IH Manuel utilisateur

AEG

AEG T6DBM720G Manuel utilisateur

AEG

AEG LAVATHERM 6DBG721M Manuel utilisateur

AEG

AEG T8DBA2 Manuel utilisateur

AEG

AEG LAVATHERM 3200 Manuel utilisateur

AEG

AEG LAVATHERM 33600 Manuel utilisateur

AEG

AEG LAVATHERM 37320 electronic Manuel utilisateur

AEG

AEG TR859P4B Manuel utilisateur

AEG

AEG LAVATHERM 7DBE38S Manuel utilisateur

AEG

AEG TR819P4B Manuel utilisateur

AEG

AEG LAVATHERM 320 U Manuel utilisateur

AEG

AEG LAVATHERM T6DCE821B Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur

Frigidaire

Frigidaire CAQE7077KW0 Manuel du propriétaire
