SERVICE MANUAL
COOFEE-MAKERS
599 72 00-47
SOI
Edition: 06.2009 - Rev.00
EN/SERVICE/FV
Coffee-maker
for built-in installation
JBA63810X
EBA6310X
P3810-M
QCA6000X
SOI 06.09 FV 2/10 599 72 00-47
SOI 06.09 FV 3/10 599 72 00-47
TABLE OF CONTENTS
1 - TECHNICAL DATA ------------------------------------------------------------------------------- page 4
1.1 - COFFEE SECTION --------------------------------------------------------------------------------page 4
1.2 - STEAM SECTION----------------------------------------------------------------------------------page 4
2 - ELECTRICAL DIAGRAMS---------------------------------------------------------------------- page 5
2.1 - BASIC DIAGRAM-----------------------------------------------------------------------------------page 4
2.2 - WIRING DIAGRAM---------------------------------------------------------------------------------page 4
3 – OPERATING ELEMENT TEST PROCEDURE-------------------------------------------- page 7
4 – DISPLAY TEST PROCEDURE---------------------------------------------------------------- page 8
5 - WATER FLOW DIAGRAM---------------------------------------------------------------------- page 9
6 - GRIDER SET-UP ---------------------------------------------------------------------------------- page 10
SOI 06.09 FV 4/10 599 72 00-47
1 - TECHNICAL DATA
Voltage 220 - 240 V 60 Hz
Mx. imput power 1350 W
1.1 - COFFEE SECTION
Coffee temperature probe 98 °C
Hot water temperature probe 98 °C
Thermal fuse TCO 192 °C
Heating element 600 + 600 W
Pump Type ULKA EP5
Power 48 W
1.2 - STEAM SECTION
Steam temperature probe 145 °C
Thermal fuse TCO 318 °C
Heating element 1000 W
SOI 06.09 FV 5/10 599 72 00-47
2 - ELECTRICAL DIAGRAMS
2.1 - BASIC DIAGRAM
Reed
Sensor
IFD Boiler Temp.
Sensor
Control
Board
Hall
Sensor
Water Flow
Meter
Motor Filter Board
Ifusor Grou
p
Moto
r
Grinder Motor
Steam Heating
Element
Coffee Heating
Element Steam valve 2 way
Discharge valve 2 way
P
ump
Coffee
Temperature
Senso
r
LED
Board
Cooling Fan
Motor
Pump Thermal
Proctector
SOI 06.09 FV 6/10 599 72 00-47
2.2 - WIRING DIAGRAM
SOI 06.09 FV 7/10 599 72 00-47
3 - OPERATING ELEMENT TEST PROCEDURE
CORRESPONDENCE BETWEEN ICON
AND OPERATING ELEMENT
TEST PROCEDURE
icon Operating element
OK
Pump
MENU
Upper motor
1 cup
Tank
On / stand by
Steam device
Hot water
Solenoid 2
(delivery)
2 cups
Solenoid 1
(discharge)
Steam
Solenoid 1 +
Solenoid 2
TASTE
Grinder motor
LOAD TEST
MODE
When the appliance is in stand-by mode
(not operating) and the main switch
however in position I, open the service
door and press simultaneously the icons
MENU, 1 CUP and HOT WATER for at
least 8 seconds until the message
“SELECT TEST” is displayed. Then close
the service door and press the LIGHT
icon: the text “LOAD TEST MODE” is
displayed.
LIGHT
Lower motor
To exit the procedure, unplug the appliance or turn it off.
SOI 06.09 FV 8/10 599 72 00-47
4- DISPLAY TEST PROCEDURE
CORRESPONDENCE BETWEEN ICON
AND OPERATING ELEMENT
TEST PROCEDURE
icon position
NOTE
BUTTON 0
MENU
BUTTON 1
OK
BUTTON 2
TASTE
BUTTON 3
LIGHT
BUTTON 4
Hot water
BUTTON 5
BUTTON 6
BUTTON 7
2 cups
BUTTON 8
1 cup
BUTTON 9
LOAD TEST
MODE
When the appliance is in
stand-by mode (not
operating) and the main
switch however in position
I, open the service door
and press simultaneously
the icons MENU, 1 CUP
and HOT WATER for at
least 8 seconds until the
message “SELECT TEST”
is displayed. Then close
the service door and press
the MENU: the text
“DISPLAY TEST MODE”
is displayed.
Steam
BUTTON 10
The access to
display mode
sets back the
selected
language and
activates the first
setting.
When not operating, the appliance will automatically exit the procedure after 1 minute.
SOI 06.09 FV 9/10 599 72 00-47
5- WATER FLOW DIAGRAM
Water pump
Water flowmeter
Water tank
Coffee outlet
Coffee heating element
Exaust solenoid valve
Steam heating element
Temperature sensor
Solenoid valve for steam
and hot water
Dispensing tube
Temperature
sensor
SOI 06.09 FV 10/10 599 72 00-47
5- GRINDER SET-UP
Remove the coffee beams
container, the back finger saver
and the knob.
Turn the white shaft clockwise
till it stops. Remove the upper
part of the grinder by pulling it
upwards.
Verify the position of the white
basket (has to be as on the
picture).
Remove the white plastic ring by
pulling it. Turn the white shaft counter-
clockwise till it stops. Pull to
remove it.
Now you can change the setting:
Turn the gear clockwise* to
reduce the coarseness (fine
coffee).
Turnr the gear
counterclockwise* to
increase the coarseness
(thicker).
Insert the white shaft, making
sure its longer notch is aligned
with the one on the grinder.
Insert the white ring making sure
its notch as well is inserted on
the correct position.
Turn the shaft CLOCKWISE till it
stops to insert the upper gear.
Then turn the shaft all the way
COUNTERCLOCKWISE.
(*) before changing the setting, check and mark the initial position taking as reference the position of the
metal ball you see through the holes on the white ring.
Change the setting carefully by turning the white ring one or max two steps (one or two holes) either way as
required.
