SKYLINE 13
13.3" Smart Wifi Digital Photo Frame
User Manual
LANGUAGE DIRECTORY
Italiano 71-84
Español 57-70
日本語 43-56
Français 29-42
Deutsch 15-28
English 01-14
TABLE OF CONTENTS
AEEZO Frame Overview
Initial Setup
Download the AiMOR App on Your Phone
Connecting to a Frame
Sharing Photos/Videos
Quick Menu
Detailed Settings Menu
Warranty & Contact Us
1
4
5
6
7
8
10
10
11
11
12
12
13
13
13
13
14
Frame
Manage
Friends
Display
Slideshow
Wi-Fi
Notifications
Backup
Help & About
SD cards can be used to import photos to the frame. Photos can also be exported to an
SD card from the frame to make a backup or move to a computer, etc. Note that photos
cannot be displayed directly from an SD card.
Hold the power button for about 5 seconds to power on the frame.
When the frame is on, press the power button once to turn the screen on or o.
Hold the power button for about 2 seconds to get power o option. To avoid any
possible damage to the frame, please do not unplug the power adapter from the frame
while the device is on.
3. SD Card Slot
2. Power Button
1. Wall Mount Hole
Digital Photo Frame
Frame Overview
- 01 -
EN
MENU
6
5
4
3
2
1
9
8
7
The Mini USB port is for use by our technicians during setup and service only. It does not
support importing or exporting photos.
The USB 2.0 port is for use with flash storage devices (USB/thumb drive) for importing
and exporting photos. Note that photos cannot be displayed directly from a USB drive.
Additionally, the frame cannot be connected to a computer via the USB port.
6. DC (Power) Port
5. Mini USB
4. USB 2.0 Port
EN
- 02 -
Specifications
Screen 13.3" Touchscreen (16:10)
Resolution
Built-in Speakers
Storage*
Wi-Fi
CPU
1280*800 IPS HD Display
1W x 1
16GB
2.4GHz
Quad-core ARM CortexTM-A53
* Storage specifications refer to capacity before formatting. Actual formatted capacity
will be less.
9. Menu
8. Navigation buttons
7. Speakers
10 9
EN
- 03 -
1. Screen on/off
2. Navigation buttons
3. Back
4. Delete a photo
5. Screen brightness
6. Favorite a photo
7. Home
8. Volume control
9. Remote receiver
10. Motion sensor
Remote Control & Motion Sensor
8
7
61
5
4
3
2
Detects motion up to 5 meters away and turns on the display. Automatically turns
off the display to save energy when no one is around.
EN
AEEZO Frame Initial Setup
Plug in the power adapter included in the box to turn on the frame.
You may need to wait for up to 15 seconds as the AiMOR system is loading.
Follow the prompts to set up the frame. You can use the touchscreen to navigate
through the setup menus.
- 04 -
Enter your name and the location
where you will place the frame
(e.g. “John Smith” and “Living room,”
“Kitchen,” or “Oce.”) Finally, set
the time zone you are in.
First start by selecting a language.
This will be used as the system
language and in all menus.
Connect your frame to the internet
by selecting a Wi-Fi network and
entering the password.
