Advantech ITA-8100 Manuel utilisateur

User Manual

ITA-8100

10.4” Panel PC with Intel®

Atom™ Processer and EN50155

Certification for Railway

Applications

ITA-8100 User Manual ii

The documentation and the software included with this product are copyrighted 2019

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated, or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. The information provided in this manual is intended to be accurate and reliable.

However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any

infringements of the rights of third parties that may result from its use.

Acknowledgements

The ITA-8100 is trademark of Advantech Co., Ltd.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants the original purchaser that each of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products that have been repaired or altered by

persons other than repair personnel authorized by Advantech, or products that have

been subject to misuse, abuse, accident, or improper installation. Advantech

assumes no liability under the terms of this warranty as a consequence of such

events.

Because of Advantech’s high quality-control standards and rigorous testing, most

customers never need to use our repair service. If an Advantech product is defective,

it will be repaired or replaced at no charge during the warranty period. For out-of-war-

ranty repairs, customers are billed according to the cost of replacement materials,

service time and freight. Please consult your dealer for more details.

If you believe your product is defective, follow the steps outlined below.

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any messages displayed onscreen when the prob-

lem occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain a return merchandize authori-

zation (RMA) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a completed Repair and Replacement

Order Card, and a proof of purchase date (such as a photocopy of your sales

receipt) into a shippable container. Products returned without a proof of pur-

chase date are not eligible for warranty service.

5. Write the RMA number clearly on the outside of the package and ship the pack-

age prepaid to your dealer.

Part No. 2001810000 Edition 1

Printed in Taiwan November 2019

iii ITA-8100 User Manual

Technical Support and Assistance

1. Visit the Advantech website at http://support.advantech.com to obtain the latest

product information.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the

following information ready before calling:

–Product name and serial number

–Description of your peripheral attachments

–Description of your software (operating system, version, application software,

etc.)

–A complete description of the problem

–The exact wording of any error messages

Safety Instructions

1. Read these safety instructions carefully.

2. Retain this user manual for future reference.

3. Disconnect this equipment from the power outlet before cleaning. Use only a

damp cloth for cleaning. Do not use liquid or spray detergents.

4. For pluggable equipment, the power outlet socket must be located near the

equipment and easily accessible.

5. Protect the equipment from humidity.

6. Place the equipment on a reliable surface during installation. Dropping or letting

the equipment fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. Do not cover the openings.

8. Ensure that the voltage of the power source is correct before connecting the

equipment to a power outlet.

9. Position the power cord away from high-traffic areas. Do not place anything over

the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source

to avoid damage from transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following occurs, have the equipment checked by qualified service

personnel:

The power cord or plug is damaged.

Liquid has penetrated into the equipment.

The equipment has been exposed to moisture.

The equipment is malfunctioning, or does not operate according to the user

manual.

The equipment has been dropped and damaged.

The equipment shows obvious signs of breakage.

15. Do not leave the equipment in an environment with a storage temperature of

below -40 °C (-40 °F) or above 70 °C (158 °F) as this may cause damage. The

equipment should be kept in a controlled environment.

ITA-8100 User Manual iv

16. CAUTION: The battery is at risk of exploding if incorrectly replaced. Replace

only with the same type recommended by the manufacturer or an equivalent.

Discard used batteries according to the manufacturer’s instructions.

17. CAUTION: To avoid risk of electric shock, this equipment must only be con-

nected to supply mains with protective earthing.

In accordance with IEC 704-1:1982 specifications, the sound pressure level at the

operator's position does not exceed 70 dB (A).

DISCLAIMER: These instructions are provided in accordance with IEC 704-1. Advan-

tech disclaims all responsibility for the accuracy of any statements contained herein.

Consignes de sécurité

1. Lisez attentivement ces consignes de sécurité.

2. Gardez ce manuel pour référence future.

3. Déconnectez cet équipement de toute prise secteur avant de le nettoyer. Utili-

sez un chiffon humide. Ne pas utilisez de liquide ou de sprays détergents pour

le nettoyage.

4. La prise de courant doit être située près de l'équipement et doit être facilement

accessible.

5. Gardez cet équipement à l’abri de l'humidité.

6. La chute de l’équipement pouvant l’endommager, celui-ci doit être installé sur

une surface stable.

7. Les ouvertures du boîtier sont nécessaires au refroidissement de l’appareil.

Veillez à protéger l'appareil contre la surchauffe. Ne pas couvrir less ouvertures.

8. Assurez-vous que la tension de la source d'alimentation est correcte avant de

brancher l'appareil à la prise de courant.

9. Placez le cordon d'alimentation de manière à éviter que des personnes march-

ent dessus. Veillez à ce qu’aucun objet ne soit placé sur le cordon d’alimenta-

tion.

10. Tous les conseils et avertissements concernant ce matériel et son utilisation doi-

vent être lus et compris.

11. Si l'appareil n’est pas utilisé pendant une longue période, débranchez-le de la

source d'alimentation pour éviter les dommages causés par des surtensions

transitoires.

12. Ne jamais verser de liquide dans une ouverture. Cela peut provoquer un

incendie ou un choc électrique.

13. Ne jamais ouvrir l'équipement. Pour des raisons de sécurité, l'équipement ne

peut être ouvert que par du personnel qualifié.

14. Si l'une des situations suivantes se présente, faites vérifier le matériel par le

personnel de service:

• Le cordon d'alimentation ou la prise est endommagé.

• Du liquide a pénétré dans l'appareil.

• L'équipement a été exposé à l'humidité.

• L'équipement ne fonctionne pas bien, ou vous ne pouvez pas le faire fonc-

tionner selon le manuel d'utilisation.

• L'appareil est tombé et est endommagé.

• L'équipement présente des signes évidents de casse.

15. Ne pas laissez ce matériel dans un environnement où la température de stock-

age peut descendre en dessous de -40 °C (-40 °F) ou être supérieure à 70 °C

(158 °F). Ceci pourrait endommager l'équipement. L'équipement doit être main-

tenu dans un environnement contrôlé.

v ITA-8100 User Manual

16. ATTENTION: Risque d’explosion si la batterie est remplacee de maniere incor-

recte. Remplacer uniquement avec un modèle recommandé par le fabricant, et

éliminer les piles usagées selon les instructions du fabricant.

17. ATTENTION: Pour éviter tout risque d'electrocution, cet équipement ne doit

être branché qu'au réseau d'alimentation avec une terre de protection.

Conformément à la norme CEI 704-1:1982, l’opérateur ne doit pas expérimenter un

niveau sonore supérieur à 70 dB (A).

AVERTISSEMENT: Ces consignes suivent la norme CEI 704-1.

Advantech décline toute responsabilité concernant l'exactitude des déclarations con-

tenues dans ce document.

Declaration of Conformity

This equipment has been tested and found to comply with the limits for a Class A dig-

ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-

vide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Opera-

tion of this equipment in a residential area is likely to cause harmful interference. In

such cases, users are required to correct the interference at their own expense.

RTC Battery Information

The computer is provided with a battery-powered real-time clock circuit. The battery

is at risk of exploding if incorrectly replaced. Replace only with same type recom-

mended by the manufacturer or an equivalent. Discard used batteries according to

the manufacturer's instructions.

Disposal of a battery into fire or a hot oven, or by mechanically crushing or cutting the

battery, can result in an explosion.

Risque d’explosion si la batterie est remplacee de maniere incorrecte. Remplacer

uniquement avec un modèle recommandé par le fabricant, et éliminer les piles usa-

gées selon les instructions du fabricant.

Éliminer une batterie dans un feu ou un four chaud, ou écraser ou couper méca-

niquement une batterie peut provoquer une explosion. Veillez à connecter le cordon

d'alimentation à une prise de courant avec mise à la terre.

ITA-8100 User Manual vi

Warnings, Cautions, and Notes

Warning! Warnings indicate conditions that may cause personal injury!

Les avertissements indiquent des conditions qui, si elles ne sont pas

observées, peuvent causer des dommages personnels (blessures).

Caution! Cautions are included to help prevent hardware damage and data

losses. For example, “The battery is at risk of exploding if incorrectly

installed. Do not attempt to recharge, force open, or heat the battery.

Replace the battery only with the same type recommended by the man-

ufacturer or an equivalent. Discard used batteries according to the man-

ufacturer's instructions.”

Des précautions sont incluses pour vous aider à éviter d'endommager le

matériel ou de perdre des données. Par exemple, “Il y a un risque

d'explosion d'une nouvelle batterie, si celle-ci est mal installée.

N'essayez pas de recharger, d'ouvrir de force ou de chauffer la batterie.

Remplacez la batterie exclusivement par le même type ou par un type

équivalent recommandé par le fabricant. Jeter les batteries usagées

conformément aux instructions du fabricant.”

Note! Notes provide additional optional information.

vii ITA-8100 User Manual

Contents

Chapter 1 General Information ............................1

1.1 Introduction ............................................................................................... 2

1.2 Specifications ............................................................................................ 2

1.2.1 System Kernel............................................................................... 2

1.2.2 I/O Ports........................................................................................ 2

1.2.3 LCD............................................................................................... 2

1.3 System Power ........................................................................................... 3

1.4 Safety and Environment............................................................................ 3

1.4.1 Safety............................................................................................ 3

1.4.2 Environment.................................................................................. 3

1.5 Panel and Cutout Dimensions................................................................... 3

Figure 1.1 ITA-8100 Dimensions Diagram .................................. 3

Chapter 2 Connectors and Function Keys .........5

2.1 Introduction ............................................................................................... 6

2.2 I/O Connectors .......................................................................................... 6

2.3 Bezel Key Mapping ................................................................................... 8

Appendix A Panel Mounting..................................11

A.1 Panel Mounting ....................................................................................... 12

Appendix B DC Power Connection.......................13

B.1 DC Power Connection............................................................................. 14

B.2 Connexion Pour Source D'alimentation .................................................. 15

Appendix C Watchdog Sample Code ...................17

C.1 Watchdog Sample Code ......................................................................... 18

ITA-8100 User Manual viii

Chapter 1

1General Information

Introduction

Specifications

Power Information

Safety and Environment

Panel and Cutout Dimensions

ITA-8100 User Manual 2

1.1 Introduction

Advantech’s ITA-8100 touch panel PC is a fanless human machine interface (HMI)

equipped with a 10.4-inch high-brightness (500 nits) display with projective capacitive

touchscreen aimed at railway applications. The panel’s small flat design offers space

savings for easy installation in driver cabins, while the configuration flexibly allows

the system to be adjusted for specific applications and train models. Designed to

withstand operation in harsh environments, ITA-8100 supports a wide operating tem-

perature range (-40 ~ 70 °C/-40 ~ 158 °F), which satisfies EN 50155 railway regula-

tions.

1.2 Specifications

1.2.1 System Kernel

CPU: Intel® Atom™ x7-E3950 quad-core processor @ 2.0 GHz

Memory: 1 x DDR3L SODIMM (4 GB default; supports up to 8 GB)

OS Support: Windows 10/Linux

Storage: 1 x M.2 2242 SSD (64 GB default)

LED: 1 x Power LED

Cooling System: Fanless design

Dimensions (W x H x D): 310 x 214 x 70 mm (12.2 x 8.4 x 2.8 in)

1.2.2 I/O Ports

1 x Power connector (M12 A-coded, 4-pin male)

2 x LAN 100/1000 base (M12 X-coded, 8-pin female)

2 x RS-422/485 (M12 A-coded, 5-pin female)

1 x USB 2.0 (M12 A-coded, 4-pin female)

1 x Audio (M12 A-coded, 5-pin male)

1 x Digital I/O (M12 A-coded 8-pin female)

Optional: MVB, CAN, GSM-R, GPS, Wi-Fi, WWAN, RS-232, and more (contact

Advantech for more information)

1.2.3 LCD

Display Type TFT LED LCD

Size (diagonal) 10.4"

Resolution (Pixels) 1024 x 768 max.

Luminance 500

Contrast Ratio 1000:1

Backlight Adjustment Automatic (built-in light sensor)

Note! The LCD may have several unusually bright or dark pixels. This phe-

nomenon is commonplace in today’s LCD manufacturing.

Autres manuels pour ITA-8100
