Advantech PCM-4822 Manuel utilisateur

PCM-4822

486-Based Single Board

Computer with Ethernet

Interface

This document is copyrighted, 1996. All rights are reserved. The

original manufacturer reserves the right to make improvements to

the products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated or

transmitted in any form or by any means without the prior written

permission of the original manufacturer. Information provided in

this manual is intended to be accurate and reliable. However, the

original manufacturer assumes no responsibility for its use, nor for

any infringements upon the rights of third parties which may result

from its use.

Acknowledgements

VIA is a trademark of VIA Technology, Inc.

AMD is a trademark of Advanced Micro Devices, Inc.

Award is a trademark of Award Software International, Inc.

Cyrix is a trademark of Cyrix Corporation.

IBM, PC/AT, PS/2 and VGA are trademarks of International

Business Machines Corporation.

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows ®is a registered trademark of Microsoft Corp.

RTL is a trademark of Realtek Semi-Conductor Co., Ltd.

UMC is a trademark of United Microelectronics Corporation.

All other product names or trademarks are properties of their

respective owners.

PartNo.2006822010 2ndEdition

PrintedinTaiwan September1997

Packing list

Before you begin installing your card, please make sure that the

following materials have been shipped:

• 1 PCM-4822 All-in-One Single Board Computer

• 1 utility disk with utility programs and Ethernet drivers

• 1 3.5" IDE flat cable

• 1 keyboard/mouse cable

• 1 secondary serial port cable (RS-232/422/485)

• 1 10-pin pigtail DIO cable (optional)

If any of these items are missing or damaged, contact your

distributor or sales representative immediately.

Contents

Chapter 1 General Information................................. 1

Introduction............................................................................ 2

Features................................................................................... 3

Specifications.......................................................................... 4

Standard SBC functions ....................................................... 4

Mechanical and environmental ............................................ 5

Board layout and dimensions................................................ 6

Chapter 2 Installation................................................ 7

Jumpers and connectors........................................................ 8

Locating jumpers ................................................................. 10

Locating connectors ............................................................. 11

Setting jumpers .................................................................... 12

Safety precautions................................................................ 13

Installing the CPU................................................................ 13

Removing a CPU................................................................ 13

Installing a CPU ................................................................. 14

CPU type select (J1-J9) ...................................................... 15

CPU power supply select (J6, J8) ...................................... 17

CPU clock select (J2, J3, J4).............................................. 17

CMOS setup (J14).............................................................. 17

DIO port select (J11).......................................................... 18

Installing DRAM (SIMMs) ................................................. 18

Installing SIMMs ............................................................... 18

IDE hard drive connector (CN2) ........................................ 19

Connecting the hard drive .................................................. 19

Keyboard and PS/2 connector (CN8)................................. 20

Power connectors (J13) ....................................................... 20

Serial ports (CN7, CN3) ...................................................... 20

COM1 RS-232 port (CN7)................................................. 20

COM2 RS-232/422/485 selection (CN3)........................... 20

COM2 Selection (J10).......................................................... 21

Chapter 3 Ethernet Interface Connection.............. 23

Introduction.......................................................................... 24

Utility Disk............................................................................ 24

10Base-2/10Base-5 AUI Connector (CN1) ......................... 25

10Base-T RJ-45 Connector (CN4)...................................... 25

Network Boot........................................................................ 25

Ethernet Interface Configuration....................................... 27

Chapter 4 Award BIOS Setup ................................. 29

System test and initialization .............................................. 30

System configuration verification...................................... 30

AWARD BIOS setup ........................................................... 31

Entering setup..................................................................... 31

Standard CMOS setup........................................................ 32

BIOS features setup............................................................ 33

CHIPSET features setup .................................................... 34

Power management setup................................................... 35

Load BIOS defaults............................................................ 36

Change password ............................................................... 37

Auto detect hard disk ......................................................... 38

Save & exit setup ............................................................... 38

Exit without saving ............................................................ 38

Appendix A The Expansion Bus ............................ 39

PCM-4822 Expansion Bus................................................... 40

Appendix B Pin Assignments ................................ 41

10 Base-2/5 (AUI) connector (CN1).................................. 42

Ethernet RJ-45 connector (CN4)........................................ 42

Expansion bus connector (CN6) ........................................ 43

DIO Connector ................................................................... 44

COM2 RS-232/422/485 serial port (CN3)......................... 44

Keyboard and mouse connector (CN8).............................. 44

Main power connector (J13) .............................................. 45

IDE hard drive connector (CN2)........................................ 45

COM1 RS-232 serial port (CN7) ....................................... 46

Appendix C Digital Input and Output Operation... 47

Digital input and output operation ..................................... 48

PCM-4822 Digital I/O Interface Specifications ................ 49

General

Information

This chapter gives background informa-

tion on the PCM-4822.

Sections include:

• Card specifications

• Card layout and dimensions

CHAPTER

2PCM-4822 User's Manual

Introduction

The PCM-4822 is the ultimate cost-effective solution for limited

space applications. It offers all the functions of an AT-compatible

industrial computer on a single board, taking no more space than a

3 1/2" hard drive. An integrated 16-bit Ethernet interface and

4-channelTTL levelcompatible digitalI/O makesthe PCM-4822a

complete processing system. High-performance 486 processors

from486DX upto 486DX4-120CPUsand 5x86CPUs aresupported.

Formaximum performance,the PCM-4822also supportsan EDO/

Normal DRAM SIMM socket that can take up to 32MB memory.

On-board features include support for VL-Bus Enhanced IDE

interface with up to Mode 3 transfer protocol, two serial ports (RS-

232and RS-232/422/485)withDB-9 connectorasCOM1, amini-DIN

PS/2 keyboard/mouse interface.

The PCM-4822 complies with the "Green Function" standard and

supports five types of power saving features: Normal, Conserve,

Doze, Sleep, and Suspend modes.

If you need any additional functions, the PCM-4822 has an on-

board expansion bus connector for future upgrades.

Chapter 1 General Information 3

Features

• Ultra-compact size single board computer as small as a 3 1/2" hard disk

drive (145mmx102mm)

• Supports486 CPUsup toDX4-120, and5x86 CPUs

• Up to 32 MB on-board EDO DRAM

•On-board16-bit Ethernetinterface, NovellNE2000 compatible

• Built-in VL-Bus enhanced IDE (AT bus) hard disk drive interface

• On-board mini-DIN PS/2 keyboard/mouse connector

• Twoserial ports:one RS-232,one RS-232/422/485selectable (uses

16C550UARTswith16 byteFIFO)

• Upgradablethrough PC/104 carriermodule

• 4-channeldigital I/O,TTL levelcompatible

• Green engine with sleep mode and low power consumption

• Expansion bus connector for future upgrades

• Single +5 V power supply

4PCM-4822 User's Manual

Specifications

Standard SBC functions

•CPU: SupportsIntel, AMDand Cyrixupto 80486DX/DX2/DX4-25/33/

40/66/80/100/120and5x86CPUs

•BIOS:AWARD128 KBFlash memory

•Chipset:VIAVT82C496G

•RAMmemory: 1 MB to 32 MB. One 72-pin SIMM sockets (accepts 1

MB,2 MB,4 MB,8 MB,16 MBand 32MB)

•EnhancedIDE harddisk driveinterface: Supportsup totwo enhanced

IDE (VL-bus) devices. BIOS auto-detect and Mode 3 transfer protocol

•Serialports:One serialRS-232 port,one serialRS-232/422/485port. Two

16550serialUARTs

•Keyboard/mouseconnector:Mini-DIN connectorsupports standardPC/

AT keyboard and a PS/2 mouse

•Powermanagement: Supports power saving modes including Normal/

Conserve/Doze/Standby/Suspend modes. APM 1.1 compliant

Ethernet interface

•Chipset:RealtekRTL8019AS

•Type:16-bitEthernet, NovellNE2000compatible

•Connector: On-board RJ-45 connector and AUI connector for

transceiver (MAU) such as 10Base-5 or 10Base-FOIRL (fiber optic)
