Advantech FWA-6510 Manuel utilisateur

FWA-6510 H/W Installation

APPROVALS

Name (printed)

Title

Signature

Date

FWA-6510 H/W installation

Version: V1.0 Page 2 of 21

HISTORY

Revision

Date

Person

Description

V1.0

FWA-6510 H/W installation

Version: V1.0 Page 3 of 21

CONTENT INDEX

1. Hardware installation Introduction................................................................................4

1-1 Open Chassis cover......................................................................................….4

1-2 CPU & heat-sink Installation..............................................................................5

1-3 Memory module installation...............................................................................9

1-4 Extend cable & module installation .................................................................11

1-5 Riser card installation......................................................................................13

1-6 Close Chassis Cover.......................................................................................15

1-7 HDD and HDD tray installation........................................................................16

2. Front Panel connector Introduction............................................................................18

2-1 RJ45 connector introduction............................................................................18

2-2 LED, USB and power button introduction........................................................19

FWA-6510 H/W installation

Version: V1.0 Page 4 of 21

1. HARDWARE INSTALLATION INTRODUCTION

1-1 Open Chassis cover

1. Kindly use screwdriver to unlock 2 side screws & chassis rear screw.

Side screw

Rear screw

2. Kindly push top cover back about 1.5cm, and pick up top cover, it may remove FWA-6510 Chassis cover

FWA-6510 H/W installation

Version: V1.0 Page 5 of 21

1-2 CPU & heat-sink Installation

1. Kindly unlock FAN duct’s 2 screws

2. Kindly pull a “OPEN 1st”lever of CPU socket , pull another lever of CPU socket and pull back load plate

FWA-6510 H/W installation

Version: V1.0 Page 6 of 21

3. Kindly remove a protected cover from socket.

4. Kindly put CPU on the socket, and please checks CPU’s gaps and socket’s prominence, please don’t put

wrong

FWA-6510 H/W installation

Version: V1.0 Page 7 of 21

5. Kindly lay down load plate; close a “close 1st”lever of CPU socket, and close another lever of CPU socket

6. Kindly smear the HEAT SINK COMPOUND on CPU well mixed

FWA-6510 H/W installation

Version: V1.0 Page 8 of 21

7. Please use screwdriver to fix heat-sink module and please follow diagonal to fix screw.

FWA-6510 H/W installation

Version: V1.0 Page 9 of 21

1-3 Memory module installation

1, kindly installs DDR3 ECC+REG RAM module on the socket, and please checks RAM gaps and socket’s

prominence.

2. When customer installs 2 CPU in system, the minimum RAM requirement is 4 PCs, and it needs to

install in A1/C1/E1/G1 DIMM socket.

3. If customer installs CPU in FWA-6510, A CPU needs to install in CPU socket 1 , the minimum RAM

requirement is 2 PCs, and it needs to install in A1/C1 DIMM socket.

4. When customer needs to install more RAM module in system; recommending RAM installation sequence is

A1/B1/C1/D1/E1/F1/G1/H1, and then A2/B2/C2/D2

FWA-6510 H/W installation

Version: V1.0 Page 10 of 21

3. When CPU & Memory installs finish, kindly install FAN duct in chassis.
