Advantech FPM-40T Manuel utilisateur

FPM-40T/S

Flat Panel Monitor with

10.4" Color TFT/DSTN LCD

Display

This document is copyrighted by Advantech Co., Ltd. All rights are

reserved. Advantech Co., Ltd. reserves the right to make

improvements to the products described in this manual at any time.

Specifications are thus subject to change without notice.

No part of this manual may be reproduced, copied, translated, or

transmitted in any form or by any means without the prior written

permission of Advantech Co., Ltd. Information provided in this

manual is intended to be accurate and reliable. However, Advantech

Co., Ltd. assumes no responsibility for its use, nor for any

infringements upon the rights of third parties which may result from

its use.

All brand and product names mentioned herein are trademarks or

registered trademarks of their respective holders.

FCC Class A

This equipment has been tested and found to comply with the limits

for a Class A digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses and can radiate radio

frequency energy. If not installed and used in accordance with this

user's manual, it may cause harmful interference to radio

communications. Operation of this equipment in a residential area is

likely to cause harmful interference, in which case the user will be

required to correct the interference at his own expense.

Part No. 2002040000

1st Edition Printed in Taiwan June 1998

iii

Packing List

Before installing your equipment, make sure that the following

materials have been received:

• FPM-40T/S

• Accessory pack, including:

- FPM-40T/S User's Manual

- PCA-6654 User's Manual

- PCA-6654 disks

- PCA-6654 video display card

- Component bag

- Screw bag

- 1.8 m shielding cable

If any of these items are missing or damaged, contact your

distributor or sales representative immediately.

Additional Information and Assistance

1. Visit the Advantech web sites at www.advantech.com or

www.advantech.com.tw where you can find the latest

information about the product.

2. Contact your distributor, sales representative, or Advantech's

customer service center for technical support if you need

additional assistance. Please have the following information ready

before you call:

• Product name and serial number

• Description of your peripheral attachments

• Description of your software (operating system, version,

application software, etc.)

• A complete description of the problem

• The exact wording of any error messages

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User's Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth.

Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting

it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment from

overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything

over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source

to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be opened

only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service

personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to work according to

the user's manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED

ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW

-20° C (-4° F) OR ABOVE 60° C (140° F). THIS MAY DAMAGE THE

EQUIPMENT.

The sound pressure level at the operator's position according to IEC 704-1:1982 is

no more than 70dB(A).

DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech

disclaims all responsibility for the accuracy of any statements contained herein.

Wichtige Sicherheishinweise

1. Bitte lesen sie Sich diese Hinweise sorgfältig durch.

2. Heben Sie diese Anleitung für den späteren Gebrauch auf.

3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen.

Verwenden Sie Keine Flüssig-oder Aerosolreiniger. Am besten dient

ein angefeuchtetes Tuch zur Reinigung.

4. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und

leicht zugänglich sein.

5. Das Gerät ist vor Feuchtigkeit zu schützen.

6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein

Kippen oder Fallen könnte Verletzungen hervorrufen.

7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät

vor überhitzung schützt. Sorgen Sie dafür, daB diese Öffnungen nicht

abgedeckt werden.

8. Beachten Sie beim. AnschluB an das Stromnetz die AnschluBwerte.

9. Verlegen Sie die NetzanschluBleitung so, daB niemand darüber

fallen kann. Es sollte auch nichts auf der Leitung abgestellt werden.

10. Alle Hinweise und Warnungen die sich am Geräten befinden sind zu

beachten.

11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten

Sie es vom Stromnetz trennen. Somit wird im Falle einer Überspan-

nung eine Beschädigung vermieden.

12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder

Flüssigkeiten in das Gerät gelangen. Dies könnte einen Brand bzw.

elektrischen Schlag auslösen.

13. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der

elektrischen Sicherheit nur von authorisiertem Servicepersonal

geöffnet werden.

14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu

trennen und von einer qualifizierten Servicestelle zu überprüfen:

a - Netzkabel oder Netzstecker sind beschädigt.

b - Flüssigkeit ist in das Gerät eingedrungen.

c - Das Gerät war Feuchtigkeit ausgesetzt.

d - Wenn das Gerät nicht der Bedienungsanleitung entsprechend

funktioniert oder Sie mit Hilfe dieser Anleitung keine Verbesse-

rung erzielen.

e - Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.

f - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.

Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt

70dB(A) oder weiger.

DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech

disclaims all responsibility for the accuracy of any statements contained herein.

Contents

Chapter 1 Introduction..................................... 1

1.1 Introduction............................................................................2

1.2 Specifications..........................................................................3

1.3 Flat Panel Displays ................................................................5

1.4 Connectors..............................................................................6

1.5 Dimensions..............................................................................8

Chapter 2 System Setup.................................. 9

2.1 Wall Mounting .....................................................................10

2.2 Panel Mounting ....................................................................11

2.3 Exploded Diagram ...............................................................12

Appendix A

Touchscreen Driver Installation .................... 13

A.1 Introduction.........................................................................14

A.2 Windows 95..........................................................................15

A.3 Windows 3.1 and DOS........................................................18

A.4 Windows NT ........................................................................21

A.5 OS/2 (MonitorMouse).........................................................23

Introduction

This chapter includes:

• Introduction

• Specifications

• Flat Panel Displays

• Connectors

• Dimensions

CHAPTER

FPM-40T/S User's Manual

1.1 Introduction

Advantech's FPM-40T/S series flat panel monitors are state-of-the-art

alternatives to conventional CRT monitors. They offer the traditional

advantages of flat panel displays - small size, light weight and low

power consumption - with the added security of a rugged NEMA4/12

(IP52/56) compliant design.

The flat panel monitor package includes a PCI-bus video display card

and your choice of flat panel displays: color TFT or DSTN LCD. The

display card supports simultaneous use of LCD panels and analog

CRT monitors. A shielded 1.8 meter cable connects the FPM-40T/S

and the video display card, allowing remote operation. Add an

optional touchscreen to create the ultimate user interface. The

FPM-40T/S's compact size and extended range allow easy placement

in almost any location.

Chapter 1 Introduction

1.2 Specifications

General

• Construction: Plastic panel and steel chassis

• Front panel: NEMA 4/12 (IP 52/56)

• Control: One contrast adjustment knob on rear side (FPM-40S

only)

• I/O port keyboard connector

• Mounting: Panelmount or wallmount

• Dimensions (W x H x D): 342 x 265 x 32 mm (13.5" x 10.4" x 1.3")

• Weight: 2.6 kg (5.6 lb)

Video Display Card

• Model: PCA-6654

• Board: 32-bit PCI-bus, half-size

• Video chip: CHIPS 65550

• Memory: 2 MB on board, frame buffer 512 KB (optional)

• Max. resolution: 1024 x 768 for both flat panel and CRT displays

• Connectors: One MDR-26 connector for flat panel display

One DB-15 connector for CRT

• Simultaneous CRT/LCD display

• Power consumption: +5 V @ 1 A, max.

Touchscreen (Optional)

• Type: Analog resistive

• Resolution: Transmission @ 75%

• Controller: RS-232 interface

• Power consumption: +5 V @ 200 mA

• Software drivers: DOS, Windows 3.1/95/NT, and OS/2

• Life cycle: 35 million touches

• Surface: Meets ASTM-D-1044 standard (Taber Abrasion Test)

FPM-40T/S User's Manual

1.3 Flat Panel Displays

FPM-40T FPM-40S

Display Type TFT color LCD DSTN LCD

Size (Diagonal) 10.4" 10.4"

Max. Resolution 640 x 480 640 x 480

Max. Colors 256 K colors 4096 colors

Viewing Angle 90° 90°

Dot Size (mm) 0.33 x 0.33 0.33 x 0.33

Luminance (cd/m2)250 130

LCD Model Toshiba

LTM10C029A

or compatibles

Kyocera

KCB6448BSTT-X5

or compatibles

Temperature 0 ~ 50° C 0 ~ 45° C

VR Controls N/A Contrast

Simultaneous Mode Yes Yes

LCD MTBF 50,000 hours 50,000 hours

Backlight MTBF 20,000 hours 25,000 hours

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Advantech Moniteur

Advantech

Advantech POC-W181 Manuel d'instructions

Advantech

Advantech IDK-1107WR-50WVB1 Manuel utilisateur

Advantech

Advantech IDS-3206 Series Manuel utilisateur

Advantech

Advantech PAX-332 Series Manuel utilisateur

Advantech

Advantech IDK-2112 Series Manuel utilisateur

Advantech

Advantech LEO-D Series Manuel utilisateur

Advantech

Advantech IDK-1110WR-50WSA1 Manuel utilisateur

Advantech

Advantech KT-E240FEE Manuel d'instructions

Advantech

Advantech USC-M6 Series Manuel d'installation et d'exploitation

Advantech

Advantech RMD-1150F-8 Manuel utilisateur

Advantech

Advantech IDS-3121W Series Manuel utilisateur

Advantech

Advantech FPM1150GRVA1801-T Manuel utilisateur

Advantech

Advantech FPM-3121 Series Manuel utilisateur

Advantech

Advantech IDK-2108 Series Manuel utilisateur

Advantech

Advantech FPM-3100H Series Manuel utilisateur

Advantech

Advantech IDS-3121 Series Manuel utilisateur

Advantech

Advantech IDK-1115WP-45FHA2 Manuel utilisateur

Advantech

Advantech FPM-2150G Series Manuel utilisateur

Advantech

Advantech TREK-306DH Manuel utilisateur

Advantech

Advantech IDK-1110P Series Manuel utilisateur

Advantech

Advantech FPM-5151G Series Manuel utilisateur

Advantech

Advantech CRV-430WP Series Manuel utilisateur

Advantech

Advantech IDS-3212 Series Manuel utilisateur

Advantech

Advantech IDS-3210 Series Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
