Advantech DSA-3300 Manuel utilisateur
DSA-3300
Network Digital Signage
Platform
User Manual
Copyright
This documentation and the software included with this product are copyrighted 2006 by
Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make
improvements in the products described in this manual at any time without notice. No part of
this manual may be reproduced, copied, translated or transmitted in any form or by any
means without the prior written permission of Advantech Co., Ltd. Information provided in this
manual is intended to be accurate and reliable. However, ADVANTECH CO., LTD. assumes
no responsibility for its use, nor for any infringements of the rights of third parties which may
result from its use.
Acknowledgments
IBM and PC are trademarks of International Business Machines Corporation. MS-DOS,
Windows, Microsoft Visual C++ and Visual BASIC are trademarks of Microsoft Corporation.
Intel, Celeron and Pentium are trademarks of Intel Corporation. Delphi and C++ Builder are
trademarks of Inprise Corporation.
CE notification
The DSA-3300, developed by ADVANTECH CO., LTD., has passed the CE test for
environmental specifications when shielded cables are used for external wiring. We
recommend the use of shielded cables. This kind of cable is available from Advantech.
Please contact your local supplier for ordering information
On-line Technical Support
For technical support and service, please visit our support website at:
http://www.advantech.com/support
Part No. 2062330000
October. 2006 1st Edition
Printed in Taiwan
Contents
Chapter 1 Overview .....................................................................................14
1.1 Introduction ........................................................................................15
1.2 Features & Benefits............................................................................15
1.3 Hardware Specification ......................................................................16
Chapter 2 Hardware Functionality..............................................................21
2.1 Introduction of DSA-3300 External I/O Connectors................................21
2.2 DSA-3300 front plate external I/O connectors ........................................22
2.3 DSA-3300 rear plate external I/O connectors .........................................24
Chapter 3 Hardware Installation and Upgrade ..........................................31
3.1 Jumpers and Connectors............................................................................31
3.2 Setting jumpers ............................................................................................31
3.3 COM2 RS-485/232 Jumper setting (JP2) ................................................32
3.4 Installing the DDR SDRAM Memory Module...........................................32
3.5 Installing the 2.5" Hard Disk Drive (HDD) ................................................33
3.6 Inserting and Removing a Compact Flash Card(internal) .....................34
3.7 Connecting Power........................................................................................35
Chapter 4 Award BIOS Setup......................................................................37
4.1 Introduction ...................................................................................................37
4.2 Entering Setup..............................................................................................37
4.3 Standard CMOS Setup................................................................................38
4.4 Advanced BIOS Features ...........................................................................39
4.5 Advanced Chipset Features .......................................................................41
4.6 Integrated Peripherals.................................................................................44
4.7 Power Management Setup.........................................................................49
4.8 PnP/PCI Configurations ..............................................................................51
4.9 Password Setting .........................................................................................52
4.10 Save & Exit Setup......................................................................................52
4.11 Exit Without Saving....................................................................................52
Chapter 5 System Setup..............................................................................53
5.1 Introduction ...................................................................................................54
5.2 Installation of needed driver .......................................................................55
- 4 -
Copyright and Disclaims
The documentation and the software included with this product are copyrighted 2006 by
Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make
improvements in the products described in this manual at any time without notice. No part of
this manual may be reproduced, copied, translated or transmitted in any form or by any
means without the prior written permission of Advantech Co., Ltd.
While Advantech has sought to ensure the accuracy of all information in this manual,
Advantech assumes no liability to any party for any damage caused by any error or omission
contained in this manual, its updates or supplements, whether such errors or omissions result
from negligence, accident, or any other cause. In addition, Advantech assumes no liability
with respect to the application or use of any product or system in accordance with the
descriptions or instructions contained herein; including any liability for incidental or
consequential damages arising therefrom.
ADVANTECH DISCLAIMS ALL WARRANTIES REGARDING THE INFORMATION
CONTAINED HEREIN, WHETHER EXPRESSED, IMPLIED, OR STATUTORY.
Advantech reserves the right to make changes to any products described herein without
further notice and without obligation. The contents of this manual may be revised without prior
notice.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Part No. 2062330000 1st Edition
Printed in Taiwan October. 2006 Rev. 0.1
Product Warranty (2 year)
Advantech warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for one year from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by persons
other than repair personnel authorized by Advantech, or which have been subject to misuse,
abuse, accident or improper installation. Advantech assumes no liability under the terms of
this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of our
customers never need to use our repair service. If an Advantech product is defective, it will be
repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you
will be billed according to the cost of replacement materials, service time and freight. Please
consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU speed,
Advantech products used, other hardware and software used, etc.) Note anything abnormal
and list any onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any
helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize authorization)
number from your dealer. This allows us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement Order
Card and a photocopy proof of purchase date (such as your sales receipt) in a shippable
container. A product returned without proof of the purchase date is not eligible for warranty
service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded cables
are used for external wiring. We recommend the use of shielded cables. This kind of cable is
available from Advantech. Please contact your local supplier for ordering information.
This product has passed the CE test for environmental specifications. Test conditions for
passing included the equipment being operated within an industrial enclosure. In order to
protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage,
we strongly recommend the use of CE-compliant industrial enclosure products.
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Technical Support and Assistance
Step 1. Visit the Advantech web site at http://www.advantech.com/support
where you can find the latest information about the product. Contact your distributor, sales
representative, or Advantech's customer service center for technical support if you need
additional assistance.
Please have the following information ready before you call:
- Product name and serial number
- Description of your peripheral attachments
- Description of your software (operating system, version, application software, etc.)
- A complete description of the problem
- The exact wording of any error messages
DSA-3300 Series Model
There are 4 sub-models in DSA-3300 series listed below:
Part Number CPU RAM Hard Disc Wireless module
DSA-3300-M5E Celeron M 1.5GHz 512 RAM DDR333 40G None
DSA-3300-WM5E Celeron M 1.5GHz 512 RAM DDR333 40G 802.11b/g
DSA-3300-S6E Pentium M 1.6GHz 512 RAM DDR333 40G None
DSA-3300-WS6E Pentium M 1.6GHz 512 RAM DDR333 40G 802.11b/g
Table A. DSA-3300 Model List
The Windows® XP Embedded, TV tuner and Signage software are optional choice.
* Cerelon M 1.5 GHz can support 2 MPEG-4 Video @ D1 resolution under 65 % CPU
utilization rate.
* Pentium M 1.6 GHz approximate to P4 2.8GHz performance
Packing List
Before installing your board, make sure that the following materials have been received:
Part Number Description Qty
2190000902 CARDBOARD-WARRANTY REV. A2 1
2062330000 Utility CD 1
1700060202 Keyboard and mouse Y cable Power adapter 1
1700001394 DC Jack with 2-pin pluggable terminal block 1
1960006001 Mounting Accessory 2
Table B. DSA-3300 Model List
