Advantech MIC-3042A Manuel utilisateur

Advantech CompactPCI™

Modular Industrial Computer

MIC-3042A/B

4U-High 8-slots

CompactPCI Platform

with Standard CPCI

Power Supply

MIC-3042 User Manual --- Page II

This document is copyrighted, 2004. All rights are reserved. The original

manufacturer reserves the right to make improvements to the products described in

this manual at any time without notice. No part of this manual may be reproduced,

copied, translated or transmitted in any form or by any means without the prior

written permission of the original manufacturer. Information provided in this

manual is intended to be accurate and reliable. However, the original manufacturer

assumes no responsibility for its use, nor for any infringements upon the rights of

third parties which may result from its use.

Acknowledgements

PICMG™, CompactPCI™ and the PICMG™, CompactPCI™ logos are trademarks of

the PCI Industrial Computers Manufacturers Group. All other product names or

trademarks are properties of their respective owners.

CE Notification

The MIC-3042 series, developed by Advantech Co., Ltd., has passed the CE test for

environment specifications when shielded cables are used for external wiring. We

recommend the use of shielded cables.

P/N : 2002304200

September 2004

MIC-3042 User Manual --- Page III

Product warranty

Advantech warrants to you, the original purchaser, that each of its products will be

free from defects in materials and workmanship for one year from the date of

purchase.

This warranty does not apply to any products which have been repaired or altered

by persons other than repair personnel authorized by Advantech, or which have

been subject to misuse, abuse, accident or improper installation. Advantech

assumes no liability under the terms of this warranty as a consequence of such

events.

Because of Advantech’s high quality-control standards and rigorous testing, most of

our customers never need to use our repair service. If an Advantech product is

defective, it will be repaired or replaced at no charge during the warranty period. For

out-of-warranty repairs, you will be billed according to the cost of replacement

materials, service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. For example, CPU

speed, Advantech products used, other hardware and software used, etc. Note

anything abnormal and list any on-screen messages you get when the problem

occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandise

authorization) number from your dealer. This allows us to process your return more

quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt) in

a shippable container. A product returned without proof of the purchase date is not

eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid to

your dealer.

MIC-3042 User Manual --- Page IV

Packing List

Before installation, ensure that the following materials have been received:

• One MIC-3042 CompactPCI™ enclosure with backplane

• One box of accessories

• One warranty certificate

• One CD-ROM for user manual (PDF file)

If any of these items are missing or damaged, contact your distributor or sales

representative immediately.

Technical Support and Sales Assistance

If you have any technical questions about the MIC-3042 or any other Advantech

products, please visit our support website at:

• http://www.advantech.com.tw/support

For more information about Advantech's products and sales information, please

visit:

• http://www.advantech.com.

MIC-3042 User Manual --- Page V

Contents

1. General Information............................................ 1

1.1 Introduction ................................................................................. 2

1.2 Features ....................................................................................... 3

1.3 Specifications................................................................................. 3

1.3.1 General.......................................................................................... 3

1.3.2 Hot-swap Fans................................................................................. 3

1.3.3 Power Supply................................................................................... 4

1.4 Dimensions.................................................................................4

2. Installation………............................................... 6

2.1 Initial Inspection............................................................................. 7

2.2 The MIC-3042 Illustration ............................................................... 7

2.3 Installation Procedures ................................................................... 8

2.3.1 Card Installation and Removal........................................................... 8

2.3.2 Before Operating the System...........................................................10

2.3.3 Connecting with rear I/O module......................................................10

2.3.4 Replacing the Hot-swap Fan....................................................... 10

3. Backplane………….................................................. 11

3.1 General Information......................................................................12

3.2 Features......................................................................................12

3.3 Specification.................................................................................12

3.4 Slot Assignments……......................................................................12

3.5 Connector and jumper locations.......................................................15

3.5.1 ATX Power Connector (ATX1) .....................................................16

3.5.2 Power Switch .................................................................17

3.5.3 V I/O Voltage Selection ...............................................17

3.5.4 Fan Module Connector .................................................17

3.5.5 LED Board Connector ....................................................17

3.6 Clock Routing Configuration............................................................17

Appendix A (Pin assignment of connectors in MIC-3042A Backplane)……… 18

Appendix B (Pin assignment of connectors in MIC-3042B Backplane)……… 38

Appendix C (Ordering Information)…………………………………………… 54

MIC-3042 User Manual --- Page VI

Figures

Figure 1-1: MIC-3042 dimensions ........................................................................4

Figure 1-2: Appearance of MIC-3042......................................................................... 5

Figure 2-1: Front view of MIC-3042 ....................................................................7

Figure 2-2: Removable parts of MIC-3042....................................................................8

Figure 2-3: Installing a card into the chassis.....................................................9

Figure 3-1: MIC-3042A Backplane slot numbering ...................................................... 15

Figure 3-2: MIC-3042B Backplane slot numbering ...................................................... 15

Figure 3-3: The connector and jumper locations on the rear side (MIC-3042A)…........ 16

Figure 3-4: The connector and jumper locations on the rear side (MIC-3042B)…........ 16

Figure 3-5: V I/O voltage selection...................................................................... 19

MIC-3042 User Manual --- Page 1

General Information

MIC-3042 User Manual --- Page 2

1.1 Introduction

The MIC-3042 series are a 4U-high enclosure designed for standard CPCI power

supplies which means an extremely low mean-time-to-repair (MTTR) since each

power supply can be hot-swapped. It equips with a 6U 8-slot CompactPCI H.110 CT

bus backplane and a 500W 2+1 redundant AC/DC power supply. It is suitable for

telecommunication, computer telephony integration, and industrial automation. The

built-in high quality backplane with 64 bit / 66MHz bus speed offers best impedance

control, meets open architecture standards and is compatible with all Advantech

CompactPCI boards.

The MIC-3042 series support IEEE 1101.11 rear I/O transition board. Users can

route I/O signals to the rear transition board to simplify system cabling. Front boards

pop in and out without any hardwiring. Efficient hot swappable fan module gives easy

self-maintenance capability. The system slots can support CPU boards featuring

desktop Intel®Pentium®IV Processor-M up to 2.2GHz with MIC-3358 series and

Intel®Pentium®M processors up to 1.8GHz with MIC-3369 series. With the chassis

management module (MIC-3924L-A), the chassis temperature and fan speed can be

monitored and the MIC-3924L-A will issue sound to alarm while any abnormal.

The MIC-3042A supports PICMG 2.16 and can be used as blade servers. Moreover,

the MIC-3042B supports slim CD-ROM or FDD using MIC-3960 media carrier board.

With redundant industry standard CompactPCI power supply plus Advantech’s

renowned reliability, the MIC-3042 4U enclosure is a rock solid choice for

communications and telephony applications.

There are four models of MIC-3042 series :

• MIC-3042A-A: MIC-3042A enclosure, w/ 8-slot CompactPCI™ 6U backplane

(MIC-3042A) supporting CT bus application and PICMG 2.16, and 500W 2+1

redundant AC CPCI power supplies.

• MIC-3042A-D: MIC-3042A enclosure, w/ 8-slot CompactPCI™ 6U backplane

(MIC-3042A) supporting CT bus application and PICMG 2.16, and 500W 2+1

redundant DC CPCI power supplies.

• MIC-3042B-A: MIC-3042B enclosure, w/ 8-slot CompactPCI™ 6U backplane

(MIC-3042B) supporting CT bus application and 500W 2+1 redundant AC CPCI

power supplies.

• MIC-3042B-D: MIC-3042B enclosure, w/ 8-slot CompactPCI™ 6U backplane

MIC-3042 User Manual --- Page 3

(MIC-3042B) supporting CT bus application and 500W 2+1 redundant DC CPCI

power supplies.

1.2 Features

• Eight 6U card slots

• Supports front and rear I/O

• Supports H.110 CT application

• 500W 2+1 redundant AC/DC power supply

• Hot-swap compliant backplane

• A hot-swap fan module

• Integrated intelligent management module,MIC-3924L, which can monitor the

chassis temperature and fan speed and issue alarm while any abnormal.

1.3 Specifications

1.3.1 General

• Construction: Aluminum frame and galvanized sheet steel

• 8-slot space (32 TE), including one system slot and seven peripheral slots for

MIC-3042A and six peripheral slots and one media slot for MIC-3042B

• "Hot swappable” platform complies with PICMG 2.1 R 2.0 Hot Swap

Specification

• Dimensions (W x H x D, mounting flanges not included):

4U: 440 x 177 x 320 mm (17.3" x 7" x 12.6")

• Weight: 18 kg (39.7 lb)

• Operating temperature: 0 ~ 45° C

• Storage temperature: -20° C ~ 60° C

• Relative humidity: 10 ~ 95% @ 40° C, non-condensing

• Operating altitude: 0 ~ 3,048 meters (0 ~ 10,000 feet)

• Storage/transit altitude: 0 ~ 12,190 meters (40,000 feet)

• Shock: 10 G (operating); 30 G (storage/transit)

• Random vibration: 1.0 Grms (operating); 2.0 Grms (operating)

1.3.2 Hot-swap Fans

• Air flow: One 193-CFM front fan and one 61.3-CFM rear fan

• Rated fan speed: 3,000 rpm (front fan); 3,400 rpm (rear fran)

MIC-3042 User Manual --- Page 4

• Life expectancy: 80,000 hours @ 40° C (front fan); 50,000 hours @ 25° C (rear

fan)

1.3.3 Power Supply

• Input:

AC: 100~240 V @ 47~63 Hz, full range (for MIC-3042X-A models)

DC: -48V (TYP), -36~-72V range (for MIC-3042X-D models)

• Output: 500W+250W 2+1 hot swappable and redundant AC or DC w/PFC

• Maximum load: +3.3V @ 36A, +5V @ 50A, +12V @ 10A, -12V @ 1A

• Minimum load: +3.3 V @ 0A, + 5V @ 2A, +12 V @ 0A, -12V @ 0A

• MTBF: AC: 266,241 hours @ 25° C; DC: 92,859 hours @ 30° C

• Safety: UL/CE/TUV

1.4 Dimensions

Figure 1-1: MIC-3042 dimensions.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Advantech Ordinateur de bureau

Advantech

Advantech ARK-1550 Manuel utilisateur

Advantech

Advantech EPC-T1228 Series Manuel utilisateur

Advantech

Advantech PPC-179T Manuel utilisateur

Advantech

Advantech AIM-35AT Series Manuel d'installation et d'exploitation

Advantech

Advantech MIC-1810 Manuel d'installation et d'exploitation

Advantech

Advantech ARK-3530L-00A1E Manuel utilisateur

Advantech

Advantech DS-563SQ-S6A1E Manuel utilisateur

Advantech

Advantech ARK-3400 Manuel utilisateur

Advantech

Advantech ARK-VH200 Manuel utilisateur

Advantech

Advantech POC-W181 Manuel d'instructions

Advantech

Advantech UNO-4678 Manuel utilisateur

Advantech

Advantech POC-S198-25F-ACE Manuel utilisateur

Advantech

Advantech UNO247J1N12502-T Manuel utilisateur

Advantech

Advantech ARK-3533 Manuel utilisateur

Advantech

Advantech EPC-T2286 Series Manuel utilisateur

Advantech

Advantech MIOS-5250 Manuel d'installation et d'exploitation

Advantech

Advantech ECU-4674 Series Manuel utilisateur

Advantech

Advantech ES-200-77 Manuel utilisateur

Advantech

Advantech ARES-5221B Manuel utilisateur

Advantech

Advantech ARK-2230 Manuel utilisateur

Advantech

Advantech MIC-1816 Series Manuel d'installation et d'exploitation

Advantech

Advantech UNO-1170E Manuel utilisateur

Advantech

Advantech UTC-520 Manuel utilisateur

Advantech

Advantech USC-160 Series Manuel d'installation et d'exploitation

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
