Advantech IPC-690 Manuel utilisateur

IPC-6908

Industrial PC Chassis

This document is copyrighted, December 1997, by Advantech Co., Ltd. All rights are reserved. Advan-

tech Co., Ltd. reserves the right to make improvements to the products described in this manual at any

time without notice.

No part of this manual may be reproduced, copied, translated or transmitted in any form or by any

means without the prior written permission of Advantech Co., Ltd. Information provided in this

manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no respon-

sibility for its use, nor for any infringements of the rights of third parties which may result from its use.

Acknowledgments

IPC-6908, IPC-6908P, PCA-6108E and PCA-6108P4 are all trademarks of Advantech Co., Ltd.

NOTE:

The information in this document is provided for reference only. Advantech does not assume any liability arising

out of the application or use of the information or products described herein. This manual is subject to change

without notice.

Part No. 2002908000 1st Edition

Printed in Taiwan January 1998

Contents

Chapter 1 General Information ...................................................................1

1.1 Introduction ...............................................................................................................1

1.2 Specifications............................................................................................................ 1

1.3 Dimensions ............................................................................................................... 3

1.4 Installations ............................................................................................................... 4

Chapter 2 System Setup..............................................................................5

2.1 Removing the cover .................................................................................................. 5

2.2 Installing plug-in cards .............................................................................................. 6

2.3 The hold-down clamp................................................................................................ 6

2.4 Replacing the filter .................................................................................................... 7

2.5 Installing the fan assembly........................................................................................ 7

2.6 Installing the disk drives............................................................................................ 8

2.7 Adjusting speaker volume....................................................................................... 10

2.8 Temperature setting................................................................................................ 10

Appendix A. Passive Backplane ................................................................................... 11

Appendix B. Exploded Diagram .................................................................................... 13

Appendix C. Safety Instructions.................................................................................... 14

IPC-6908 User's Manual 1

Chapter 1 General Information

1.1 Introduction

The IPC-6908 is a high-end PC/AT-compatible desktop/wallmount fault resilient IPC chassis designed

for high-reliability applications. It can be easily installed and maintained for mission critical applica-

tions and harsh environment use. The IPC-6908 includes an 8-slot PC-bus compatible passive back-

plane, and a 260-watt switching power supply with an ultrahigh output rating at -12 V and a

hot-swappable fan cooling system. The IPC-6908 accepts up to 4 disk drives: one 3.5" front accessible

drive, two half-height drives and one 3.5" drive inside.

The IPC-6908 features an advanced fault detection and alarm notification system to monitor its own

hardware status. If your PC system shuts down without any prior warning, it could cause considerable

loss. The IPC-6908, the fault resilient IPC, is designed to prevent this from happening.

1.2 Specifications

General

•Construction: Heavy-duty steel chassis and fireproof plastic front panel

•Slots: Up to 8 full-length cards can be installed in a single chassis

•Disk drive capacity: Two front-accessible half-height and one 3.5" disk drives, and one 3.5" drive

inside the chassis

•Cooling system: Two 49 CFM cooling fans (flow in) in front with an air filter. Dual fans for

hot-swappability and redundancy

•Controls: Power on/off switch in rear panel, CPU reset and alarm reset button in front panel

•Indicators: LEDs for power on/off and HDD activity. Bicolor LEDs (green and red) for fan1/fan2

failure and overheating

•Speaker: One 8 ohm / 0.3 watt speaker, volume control on board

•Dimensions: 7.9" (W) x 11.8" (H) x 18.2" (D)

200 mm (W) x 300 mm (H) x 463 mm (D)

•Weight: 26.4 lb (12 kg)

•Paint color: Pantone 414U (plastic front panel), Pantone 418U (metal chassis)

Passive Backplane (PCA-6108E)

•Slots: 8 ISA-bus, full-size slots

•PC board: 4-layer PCB with ground and power planes for reduced noise and lower power supply

impedance

•Indicators: LEDs for +5 V, -5 V, +12 V and -12 V

2IPC-6908 User's Manual

Passive Backplane (PCA-6108P4)

•Slots: 3 ISA / 4 PCI / 1 PICMG slots

•PC Board: 4-layer PCB with ground and power planes for reduced noise and lower power supply

impedance

•Indicators: LEDs for +5 V, -5 V, +12 V and -12 V

Power Supply (PS-260)

•Output rating: 260 watts (max.)

•Input voltage: 85 to 130 VAC or 180 to 260 VAC @ 47 ~ 63 Hz, switchable

•Output voltages: +5 V @ 25 A, +12 V @ 9 A, -5 V @ 0.5 A, -12 V @ 2 A

•Minimum load: +5 V @ 1 A, +12 V @ 0.1 A

•MTBF: 200,000 hours at 70% load

•Safety: UL/CSA/TUV approved

•EMI: Meets FCC/VDE Class B

Environmental Specifications

•Operating temperature: 32 to 122° F (0 to 50° C)

•Relative humidity: 10 to 95% @ 40° C, non-condensing

•Safety: UL / C-UL approved

•EMI: Meets FCC/VDE Class A

•CE compliant

Fault Detection and Alarm Notification

•Fan failure: If either of the two cooling fans fails, the dedicated LED (Fan 1 or Fan 2) changes color

from green to red and an audio alarm sounds. The dedicated LED remains red for the failed fan unit

until it is fixed

The fan assembly can be hot-swapped if either fan fails. Dual fans provide redundant application

•High Temperature: If the chassis' interior temperature exceeds 65° C (149° F) (standard setting),

the LED changes color from green to red and an audio alarm sounds. The LED remains red until the

temperature falls below 63° C

Temperature select: The temperature can be set to four status levels by adjusting the switch on the

alarm board:

65° C (default setting), 55° C , 70° C and 75° C

•Audible Alarm: Speaker is activated (continous beep) as soon as a malfunction is detected and

sounds until the alarm reset button is pressed. The alarm reset button is on the front panel. However,

the alarm indicator will stay red until the fault condition is resolved.

•Self-test: Press the Alarm Reset button for 8 seconds. The alarm board will self-test automatically for

all functions. The alarm board can also monitor the temperature sensor IC. If the sensor has failed or

there is no connection, the speaker will sound off as "Beep x Beep x ...".

IPC-6908 User's Manual 3

1.3 Dimensions

Unit = mm

CPU

RESET ALARM

RESET

Power

on/off HDD Fan 1 Fan 2 Temperature

LED Indicator

4IPC-6908 User's Manual

1.4 Installations

Unit = mm

Wallmount Desktop

IPC-6908 User's Manual 5

Chapter 2 System Setup

Setting up your IPC-6908 requires only a screwdriver and a small amount of time. Before you begin,

you should also gather together all of the cards you plan to install, as well as the disk drives you plan

to use.

The doors are located on the chassis front cover, providing access to the control panel. This offers the

disk drive and air filter protection against damage, and allows for easy accessibility. The control panel

functions include: CPU reset switch and alarm reset switch on front, power on/off switch on back and

five LED indicators to assist in monitoring system status. On the rear panel, there is a ground point

(earthing point) located on the bottom right hand corner. This provides a ground for the whole system

and is attached via a screw.

WARNING:Disconnect all power from the chassis before you install the CPU

cards. Unplug the power cord from the wall, do not just turn off

the power switch. If you are not sure what to do, take the job to

an experienced professional.

2.1 Removing the cover

Unscrew the two thumbscrews on the rear, and then slide the cover toward the rear chassis. See

figure 2.1 below:

2.4 Removing the cover

6IPC-6908 User's Manual

2.2 Installing plug-in cards

After removing the cover, you can easily install plug-in cards. Please see figure 2.2 below:

2.2 Installing plug-in cards

2.3 The hold-down clamp

The IPC-6908 uses a hold-down clamp to ensure the plug-in cards are located securely. It also offers

protection against shock and vibration. The hold-down clamp is built-in on the upper cover. Insert the

rubber buffers provided with your kit into the hold-down clamp. These buffers offer the plug-in cards

two levels of protection against vibration.

2.3 Inserting the rubber buffers

IPC-6908 User's Manual 7

2.4 Replacing the filter

The filter is located on the front upper door. Under continuous use, the filter should be replaced about

once a month. To replace the filter, refer to figure 2.4 below and do the following:

1. Open the door by pressing the latch on the top of the door.

2. Remove the filter and replace it with a new filter.

3. Close the door.

2.4 Replacing the filter

2.5 Installing the fan assembly

Remove the cover and slide it towards the rear side. The fan assembly can be hot-swapped, so there is

no need to turn off the power. Remove/insert the fan by using your fingers to unscrew the screw

fasteners on the top of the fan assembly. Please refer to figure 2.5 below:

2.5 Hot-swappable fan assembly
