Antennas for
MTC 6 Series,
Catalog V1.00
The software and hardware designations as wellasthe brand names used in this catalog are in most cases also registered
trademarks and are subject to the international law (trademark, brand and protection laws).
We recognize all national and international trademarks and product names.
We reserve the right to modify the contents of this catalog at any time and without prior notice.
DLoG GmbH assumes no liability for technical inaccuracies, typographic errors or faults in this catalog.
DLoG GmbH also assumes no liability for damages caused directly or indirectly by the delivery, performance or usage of this
material.
This catalog is protected by copyright. Duplication, in whole or in part, is not permitted without prior written approval of DLoG
GmbH.
Catalog title: Antennas for MTC 6 Series
Catalog completed on: 07/10/2014
Katalog version: V1.00
Copyright 2014
DLoG GmbH
Industriestraße 15
D-82110 Germering
GERMANY
All rights reserved
Phone: (+49) 89 / 41 11 91 0
E-Mail: [email protected]
Internet: www.advantech-dlog.com
Content
1. Antennas for challenging industrial environments...................................................................................................4
1.1. Integrated WLAN antenna.....................................................................................................................................................4
1.2. External WLAN antenna........................................................................................................................................................4
2. Integrated WLAN antenna with diversity....................................................................................................................5
3. External WLAN antenna kit, remote............................................................................................................................6
4. Connecting external antennas via RSMA...................................................................................................................7
Advantech-DLoG Antennas for MTC 6 Series, V1.00 Page 4 of 7
1. Antennas for challenging industrial environments
1.1. Integrated WLAN antenna
The antenna is a critical technical component for ensuring a stable radio link.
Especially in challenging industrial environments such as warehouses and production facilities, there are no easy solutions
with regard to wave propagation.
No off-the-rack solution will work here and this is why Advantech-DLoG offers custom solutions.
Our integrated antennas are matched as perfectly as possible to the respective vehicle terminal and achieve an optimal
circular radiation characteristic.
The protective cap ensures high mechanical stability and protects the antenna from damage.
1.2. External WLAN antenna
Solid driver cabs can significantly interfere with the radio link. For this application, we recommend so-called remote
antennas, which are not attached directly to the vehicle terminal but rather on the vehicle roof, for example. They have better
reception at this location.
To facilitate these types of configurations, Advantech-DLoG offers remote antennas from selected manufacturers.
When selecting the remote antennas, we take a range of factors into account to ensure that they are optimallymatched to
our terminals and to the respective customer application. This includes technical data such as radiation characteristics and
performance.
Advantech-DLoG Antennas for MTC 6 Series, V1.00 Page 5 of 7
2. Integrated WLAN antenna with diversity
−Dual Band Diversity antenna for
WLAN frequency band IEEE 802.11 a/b/g
and IEEE 802.11 n
−2 WLAN antennas integrated into antenna cap
−Order number antenna red: DL-CWFAK79396400
−Order number antenna grey: DL-CWFAK79396300
Technical data
Application Dual Band Diversity antenna for WLAN frequency band
IEEE 802.11 a/b/g and IEEE 802.11 n
Number of antennas 2
Type Omnidirectional antenna
Directionality Optimized for the MTC 6 housing
Frequency range Band 1: 2400 to 2485 MHz
Band 2: 5150 to 5875 MHz
Antenna gain Max. 3 dBi (without loss through the cable)
Impedance 50 Ω
Polarization Vertical
Advantech-DLoG Antennas for MTC 6 Series, V1.00 Page 6 of 7
3. External WLAN antenna kit, remote
−Dual Band antenna for
WLAN frequency band IEEE 802.11
a/b/g and IEEE 802.11 n
−For remote installation, e.g. on the roof
of the forklift
−3 m antenna cable plus mounting set
included in the scope of delivery
−Order number: DL-BWFAK79396500
Technical data
Application Dual Band antenna for WLAN frequency band IEEE 802.11 a/b/g
and IEEE 802.11 n
Mounting location For remote installation, e.g. on the roof of the forklift
Number of antennas 1 (no diversity)
Type Omnidirectional antenna
Frequency range Band 1: 2400 to 2485 MHz
Band 2: 5150 to 5875 MHz
Antenna gain Band 1: Max. 4 dBi (without loss through the cable)
Band 2: Max. 6,5 dBi (without loss through the cable)
Impedance 50 Ω
Polarization Vertical
Dimensions Ø 86 x 43 mm (Ø 3,39” x 1,69”)
Weight 0,3 kg (0,66 lbs)
Connector labeling N type or TNC
N, jack, female, bottom
RSMA plug for RSMA socket on the terminal
Advantech-DLoG Antennas for MTC 6 Series, V1.00 Page 7 of 7
4. Connecting external antennas via RSMA
External antennas are attached to the roofs of forklifts, for example.
They are connected to the underside of the MTC 6 via antenna cable with RSMA plug.
The following connection on the MTC 6 is available for this:
RSMA socket for WLAN
