Instruction Manual and Quick Start Guide

Exodus Advanced Communications

Solid State RF Amplifier System

AA-20M1G-50

20 - 1000 MHz, 50 Watt Min., 47 dB Min.

2 | Page - Ver. 1. 0

Table of Contents

SAFETY INSTRUCTIONS ........................................................................................................................................... 3

SPECIFICATIONS ...................................................................................................................................................... 4

ELECTRICAL SPECIFICATIONS............................................................................................................................... 4

ENVIRONMENTAL CHARACTERISTICS ................................................................................................................. 4

MECHANICAL SPECIFICATIONS............................................................................................................................ 4

OPERATING INSTRUCTIONS & GENERAL INFORMATION ........................................................................................ 5

INTRODUCTION................................................................................................................................................... 5

INCOMING INSPECTION...................................................................................................................................... 5

RF & AC CABLE CONNECTION ............................................................................................................................. 5

RF TURN ON PROCEDURE ................................................................................................................................... 5

RF TURN OFF PROCEDURE .................................................................................................................................. 5

DECLARATION OF CE CONFORMITY .................................................................................................................... 6

LIMITED WARRANTY ........................................................................................................................................... 6

CONTACT INFORMATION .................................................................................................................................... 6

FRONT & REAR PANEL DESCRIPTIONS .................................................................................................................... 7

FRONT PANEL VIEW ............................................................................................................................................ 7

REAR PANEL VIEW............................................................................................................................................... 8

SYSTEM OUTLINE VIEW .......................................................................................................................................... 9

SYSTEM BLOCK DIAGRAM..................................................................................................................................... 10

SYSTEM VIEW, TOP INTERIOR ............................................................................................................................... 11

SYSTEM VIEW, BOTTOM........................................................................................................................................ 12

SYSTEM PARTS LIST ............................................................................................................................................... 13

SYSTEM WIRING DIAGRAM................................................................................................................................... 14

LOCAL CONTROLLER LCD INTERFACE .................................................................................................................... 15

SCREEN 1........................................................................................................................................................... 15

SCREEN 2........................................................................................................................................................... 16

SCREEN 3........................................................................................................................................................... 17

SCREEN 4: ......................................................................................................................................................... 18

SCREEN 5: ......................................................................................................................................................... 19

REMOTE CONTROLLER INTERFACE SOFTWARE..................................................................................................... 20

PRIMARY (MAIN) WINDOW............................................................................................................................ 20

ALC ON/OFF Window........................................................................................................................................ 21

ALC OFF Window .......................................................................................................................................... 21

ALC ON Window ........................................................................................................................................... 22

FAULT Window.................................................................................................................................................. 23

COMM Window ................................................................................................................................................ 24

IP ADDRESS SETUP ............................................................................................................................................ 25

SYSTEM LOG STATUS ......................................................................................................................................... 25

3 | Page - Ver. 1. 0

OPTIONAL - IEEE-488 COMMAND LIST ................................................................................................................. 26

ETHERNET INITIAL PARAMETER SETUP VIA USB CONNECTION ............................................................................ 27

MONITORING WINDOW ................................................................................................................................... 30

SAFETY INSTRUCTIONS

BEFORE USING THIS EQUIPMENT

Read this manual and become familiar with safety markings and instructions.

Inspect unit for any sign of external damage. Do not use this equipment if there is physical damage or missing

parts.

Verify the input AC voltage to the main power supply

INTENDED USE

This product is intended for general laboratory use in a wide variety of industrial and scientific applications.

RF OUTPUT LOAD & PROPER GROUNDING REQUIRED

The RF output connector must be connected to a load before the AC switch is on.

AC & RF power must be off before disconnecting the output load or other components.

The main power source to the equipment must have an uninterrupted safety ground that has sufficient size to

the power cord.

REPAIR & MAINTENANCE

All repair or maintenance work must be performed by a factory authorized technician in order to extend the

operating life of this equipment and not to void any outstanding warranty.

FORCED AIR COOLING

This equipment requires forced air cooling. All air inlets and outlets must be cleared and free of blocking at all

time. Insufficient air flow will result in damaged equipment.

SAFETY SYMBOLS

This symbol is marked on the equipment when it is necessary for the user to refer to the

manual for important safety information. This symbol is indicated in the Table of Contents to

assist in locating pertinent information.

Dangerous voltages are present. Use extreme care.

CAUTION: The caution symbol denotes a potential hazard. Attention must be given to the statement to

prevent damage, destruction or harm.

This symbol indicates protective earth terminal.

4 | Page - Ver. 1. 0

SPECIFICATIONS

ELECTRICAL SPECIFICATIONS: 50Ω, 25°C

Parameter

Specification

Notes

Operating Frequency Range

20 - 1000 MHz

Power Output @ Psat

50 Watt Min 1

Power Gain

47 dB Min

Power Gain Flatness

3.0 dB p-p Max

Input Return Loss

-10 dB Max

Relative to 50 Ohm

2-Tone Intermodulation (IMD)

<-30 dBc Typ

37dBm/Tone, Δ = 1MHz

Harmonics 2nd / 3rd

<-25 dBc Typ / -15 dBc Typ

At Rated Pout

Spurious

-60 dBc Max

Non-harmonics

Operating Voltage

100 - 240 VAC

Power Consumption

350 Watt Max

At rated Pout

Input Power Protection

+8 dBm Max

<10 Sec without damage

Load VSWR Protection

∞ : 1

<1 minute at rated Pout

ENVIRONMENTAL CHARACTERISTICS

Parameter Specification Notes

Operating Ambient Temperature

0 to +50 °C

Storage Temperature

-40 to +85 °C

Relative Humidity

5 to 95 %

Non-condensing

MECHANICAL SPECIFICATIONS

Parameter

Specification

Notes

Dimensions W x H x D

430 x 88 x 562 mm

2U excluding handles

Weight

10 kg.

RF Connectors In/Out

Type-N Female

Front or rear panel

AC Power / Interface Connector

IEC 60320-C14 / 9-Pin D-Sub

Cooling

Built in Fan Cooling

OPTIONAL: Digital Monitor & Control

FWD, REV, VSWR, GAIN, ALC, V & I, TEMP

Ethernet RJ-45 TCP/IP, RS422/485, USB

Optional GPIB Interface

Remote Bluetooth application

Notes:

1. LCD controller option may reduce output power by up to -0.5dB

5 | Page - Ver. 1. 0

OPERATING INSTRUCTIONS & GENERAL INFORMATION

INTRODUCTION

Advanced Amplifiers is a multinational RF communication equipment and engineering service company serving

both commercial and government entities and their affiliates worldwide.

Headquartered in San Diego, California, the company utilizes its global network of resources to effectively serve

customer requirements.

As a unique original equipment manufacturer of power amplifiers ranging from 500KHz to 51GHz with various

output power levels and noise figure ranges, we fully support custom designs and manufacturing requirements

for both small and large volume levels. We bring decades of combined experience in the RF field for numerous

applications including military jamming, communications, radar, EMI/EMC and various commercial projects with

all designing and manufacturing of our HPA, MPA, and LNA products in-house.

Advanced Amplifiers received its ISO9001:2009 and ISO14001:2009 certification on January 2013 by ITQA which

is an accredited member of JAS-ANZ.

With our in-house engineering capabilities and fully equipped manufacturing facilities, Advanced Amplifiers is

committed to provide the best in RF products with industry leading quality and lead time.

INCOMING INSPECTION

Inspect unit for any sign of external damage. Do not use this equipment if there is physical damage or missing

parts. Inspect all front and rear panel connectors for damage. Inspect fans and their airways for any damage or

blockings. For a unit with a digital controller option, the interface software USB is with the manual.

RF & AC CABLE CONNECTION

RF Input and Output connectors are Type-N female connectors. Use the standard AC cable that was supplied by

the manufacturer or higher power rating cables than the manual specifies. Refer to the front and rear panel

description page for the location of RF and AC connectors.

RF TURN ON PROCEDURE

Connect RF input to an RF generator. Connect a suitable load for the power rated and continuous operation to

the output connector. Turn on the AC switch, display will show STANDBY. Optionally, connect the unit to a digital

control Software or Ethernet connection. Set the RF generator to nominal 0dBm and set the desired frequency

in the specified range. Select Gain or ALC and set to the desirable output power level then press the ONLINE

button. Use the front panel LCD gain adjust or the remote function to adjust the output power on the power

meter and the LCD screen to desired levels.

Refer to Appendix 1 for detailed operating instructions of the local and remote controller.

RF TURN OFF PROCEDURE

Decrease the RF drive from the RF generator to below -20dBm and press STANDBY on the LCD or via the control

software. Turn off AC switch on the front panel. Disconnect any unnecessary cable connections.

6 | Page - Ver. 1. 0

DECLARATION OF CE CONFORMITY

We, Advanced Amplifiers, declare under our sole responsibility that the product to which this declaration relates

is in conformity with the following standard(s) or other normative document(s):

Council Directive 98/37/EC on the Safety of Machinery Directive

Council Directive 2006/95/EC on Low Voltage Equipment Safety

LIMITED WARRANTY

Advanced Amplifiers warrants that goods delivered hereunder, at the time of delivery, will be free from defects

in workmanship and material and will conform to the requirements of the purchase order. Seller’s liability

hereunder shall be limited to the repair or replacement of defective goods F.O.B. factory of which Seller is

modified in writing by Buyer within three (3) years following delivery thereof to Buyer, and in no event will

Seller be liable for incidental, special or consequential damages. (Note: One (1) year warranty for moving parts

such as fans and power supplies). The foregoing warranty is in lieu of all other warranties express or implied

(except as to title), including any implied warranty of merchantability or suitability for purpose or against

infringement.

CONTACT INFORMATION

Please send all inquiries to:

Advanced Amplifiers

10401 Roselle Street

San Diego, CA 92121

WEB: WWW.ADVANCEDAMPLIFIERS.COM

EMAIL: SALES@ADVANECDAMPLIFIERS.COM

property of their respective proprietors.

7 | Page - Ver. 1. 0

FRONT & REAR PANEL DESCRIPTIONS

FRONT PANEL VIEW

No. Title Function

RF FOWARD

SAMPLE

System RF Forward Signal Sample Port, N type Female Connector.

2 RF INPUT System RF Input Connector, N type Female Connector.

3 FAULT LED

System Fault LED: Turn ON an LED when System Fault.

- Over Input, Over Temp, Over Current, Voltage Alarm, VSWR Alarm

4 LCD DISPLAY 4” Touch screen LCD Display, System Control LCD Panel.

5 POWER SWITCH AC Power Switch.

AA-20M1G-50

POWER

ONOFF

FAULT

31 24

0dBm InputRF Sample

8 | Page - Ver. 1. 0

REAR PANEL VIEW

No. Title Function

1 RF OUTPUT System RF Output Connector, N type Female Connector.

2 USB USB Communication Connector, Type A Female.

3 ETHERNET Ethernet Communication Female Connector, RJ-45.

AC POWER

CONNECTOR

AC Power Input 100 ~ 240 VAC, 50/60Hz, IEC60320-14 Connector.

5 DEBUG

System Controller Debugging Female Connector.

Port access requires factory authorization

6 GPIB GPIB Communication Female Connector.

7 RS-422

RS-422 Communication Female 9pin D-Sub Connector.

P1 Rx-, P2 Rx+, P3 Tx+, P4 Tx-, P5 GND.

AA-20M1G-50

100 ~ 240 VAC

50/60Hz

ETHERNET

DEBUG RS-422

USB

GPIB

112

1324

50Ω Output

9 | Page - Ver. 1. 0

SYSTEM OUTLINE VIEW

AA-20M1G-50 SYSTEM OUTLINE

POWER

ONOFF

FAULT

0dBm Inp utRF Sample

100 ~ 240 VAC

50/60Hz

ETHERNET

DEBUG RS-422

USB

GPIB

112

1324

50Ω Output

AA-20M1G- 50

10 | Page - Ver. 1.0

SYSTEM BLOCK DIAGRAM

AA-20M1G-50 BLOCK DIAGRAM

TEMP MONITOR

CURR MONITOR

ENABLE

ATTEN C ONTROL

+5VDC

POWER

LAMP

(GREEN)

LCD

DISPLAY

FAULT

LAMP

(RED)

+5VDC

LCD CONTROL

ENABLE

PS+

CURR MONITOR

INPUT DETECT

FWD DETECT

TEMP ALARM

+5VDC

ETHERNET

USB

RS-422

LCD CONTROL

SYSTEM

CONTROLLER

USB

ETHERNET

BLUETOOTH

RJ45

FEMALE

DEBUG

DUBEG

USB TYPE A

FEMALE

MINI USB

TYPE FEMALE

INPUT MODULE

HPA MODULE COUPLER

MODULE 1

R471-2

FRONT PANEL

REAR PANEL

TEMP MONITOR

ATTEN C ONTROL

PS+

FAN+

FAN 1~5

GPIB

TEMP

SENSOR

TEMP SENSE

+5VDC

RS-232

IEEE-488

CONTROLLER

IEEE-488

FEMALE

INPUT DETECT

+5VDC

RS-422

9PIN D-SUB

FEMALE

REF DETECT

R471-1

C: N WHITE

B: L BLACK

A: GND GREEN

GND POWER SUPPLY

750W V+

V-

PS+

GND

AC 100~240V

50/60Hz

AC INPUT

DEBUG

TEMP SENSE

FAN+

TEMP ALARM

TEMP SENSE

PS+

FAN

CONTROLLER

COUPLER

MODULE 2

FWD DETECT

+5VDC

RF DETECT

MODULE 1

REF DETECT

RF DETECT

MODUEL2

+5VDC

FAULT

FAN+

Table des matières

Autres manuels Advanced Amplifiers Amplificateur

Advanced Amplifiers

Advanced Amplifiers AA-28G-2KW-PT Manuel utilisateur

Advanced Amplifiers

Advanced Amplifiers AA-10K250M-150 Manuel utilisateur

Advanced Amplifiers

Advanced Amplifiers AMP2103P-LC Manuel utilisateur

Advanced Amplifiers

Advanced Amplifiers AA-1218G-3.5KW-PT Manuel utilisateur

Advanced Amplifiers

Advanced Amplifiers AA-1M6G-30 Manuel utilisateur

Manuels Amplificateur populaires d'autres marques

ASTRO

ASTRO HVO V40 P Manuel utilisateur

Marantz

Marantz SUPERSCOPE BLA-545 Instructions de montage

NAD

NAD CI980 Manuel utilisateur

Technics

Technics SE-CH770 Manuel utilisateur

Harman Kardon

Harman Kardon HK6300 Manuel utilisateur

NAD

NAD T975 Manuel utilisateur

McIntosh

McIntosh MA6850 Manuel utilisateur

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manuel utilisateur

Viatron

Viatron Autrix Manuel utilisateur

GME

GME GA9800 Manuel utilisateur

Atlas

Atlas CP700 Manuel utilisateur

Roland

Roland KC-1000 Manuel utilisateur

Pyle

Pyle PFMRA350BW Manuel utilisateur

Advantage

Advantage S-250 Manuel utilisateur

IRT Electronics

IRT Electronics DVA-3007 Manuel utilisateur

Dimavery

Dimavery BA-100 Series Manuel utilisateur

Sony

Sony XM-S400D Manuel utilisateur

Schertler

Schertler ROY X Manuel utilisateur
