SR506n

Quick Start Guide

Installation

For DSL connections, connect one end of the supplied DSL cable to the

DSL port on the gateway and the other end to the DSL wall jack

installed by your provider.

For all other devices, connect an Ethernet cable from the device to

any of the LAN ports on the gateway.

Connect the power adapter to a wall outlet and to the Power port on

the gateway. For additional protection, connect the power cord to a

surge protector. Press the ON/OFF button on the gateway to turn it

on.

Your gateway is setting up to connect to the Internet. This process may take a

few minutes. If you are unable to connect to the Internet, verify that all cable

connections are in place and that the gateway’s power is turned on.

3

1 2 3

LED Indicators

The LEDs on the SR506n can help you

understand the current state of your gateway.

LED Action Meaning

Power Connected

DSL Connected

Syncing

Internet Connected

Authentication failed

LAN4 – LAN1 Connected

Data is being transferred

USB Connected

Logging in to Your Gateway

To change the settings on your gateway, you must log in to the gateway's

interface. Make sure that you have completed the steps in "INSTALLATION"

before you begin.

Open your Internet browser application, type 192.168.1.1 into the address

line and press Enter. The Login dialog box appears.

5

Enter the username and password and click OK. The default credentials

are admin and admin.

Note: Your service provider may use other settings. Please contact your

provider for login information.

The Device Info summary page appears.

Configuring the WAN Manually

If the automatic connection process is unsuccessful, refer to the Advanced

Setup > Layer 2 Interface and WAN Services sections of the Gateway User

Manual to manually establish a connection.

WiFi Setup

Two methods, WPS and Manual, are available for WiFi setup.

Perform the steps on this page for both methods, and then follow the

instructions for the method you desire.

In the left navigation bar, click Wireless. The Wireless > Basic page

appears. Wireless is enabled by default.

7

If desired, in the SSID field, enter the network name to which you

want your client devices connected.

Continue with the steps in the method you prefer.

WPS Method

If the device you wish to connect to the Internet via your SmartRG gateway

supports the WPS secure WiFi connection method, you may follow these steps.

1. In the left menu, click Wireless >Security.

2. In the Enable WPS field, select Enabled and click Apply/Save.

3. On the top of the gateway, press the button labeled WPS.

4. Within 2 minutes, activate WPS on the 3rd party device to which you

wish to connect. It may have a pushbutton on its exterior or a software

interface where you can initiate WPS connection. To learn how to use

the WPS feature on your client device, refer to its documentation.

Your device should now be connected to your router wirelessly using WPS. If

you encounter problems with the WPS setup such as connection failure, refer

to your client device for further instructions.

9

Manual Method

Set up your gateway’s parameters first, then:

1. In the left menu, select Wireless >Security and scroll down to the

Manual Setup AP section.

2. Select the SSID of the network you wish to configure. You will need this

ID for step 7.

3. Select the desired Network Authentication. Make sure that the host

devices you intend to use support the selected authentication type.

4. Choose a WPA passphrase and type it in this field. You will need this

passphrase for step 7.

5. Select any desired encryption preferences in the lower three fields.

6. Click Apply / Save.

7. Follow the WiFi connection instructions provided with your client device

to connect to the router. Use the SSID name you selected in Step 2.

Then, in the network setup screen of your WiFi client device, enter the

Passphrase that you entered in step 4 above.
