Adexa RGR36X Manuel utilisateur
Page 1
GB
Models:
RGR36X RGR24X
GAS RANGES WITH OVEN
Installation and operation manual
Important:
1. You are advised to read these instructions first before installation commences.
2. This manual must be handed to the end user after installation and commissioning.
3. These instructions are only valid if the country code appears on the appliance. If the code does not appear on the appliance, refer to the technical
instructions for adapting the appliance to the conditions for use in that country.
Page 2
Index
Technical specifications………………………………………………………… 4
1. General information ………………………………………………............… 7
2. Safety …………………………………………………………...............………7
Using the appliance safely
Safety instructions in case of malfunction
Additional prohibitions (hazardous procedures)
Disposing of the appliance
3. Functional description……………………………………………............…8
Application of the appliance
Prohibited use
Construction
Construction features
Cooking surfaces
Electric oven
4. Installation…………………………………………………………............… 9
General information
Regulatory installation conditions
Exhausting fumes
Possible environmental interference
Preparing for installation
Storage
Transporting the appliance
Unpacking the appliance
Disposing of packaging materials
Positioning the appliance
Gas supply connection
Electrical connection
Checking gas supply pressure after installation
Gas technical specifications
Checking operation
Staff training
Rating plate
Page 3
5. Adjustment instructions………………………………………..............… 13
Replacing open burner nozzles
Replacing the nozzle of open burner pilot flames
Adjusting minimum output
Functional check
6. Operating instructions…………………………………………….............. 15
Before using the appliance
Preparing the appliance for use
Using the appliance
Operating controls
Turning the open burners on and off
Turning on the electric oven
After-use care
Cleaning
Idle period
Periodic maintenance
7. Failure Analysis & Troubleshooting………………………………………19
Page 4
Technical specifications
a. Installation drawings
RGR36X
b. Technical specifications table
Model Dimension（mm）
Gas Range orifice size & heat input
G30 G20 G25.3
29mbar 37 mbar
50 mbar
20 mbar
25 mbar
RGR36X 914*855*1524
1.3mm 1.2mm
1.1mm
1.9mm
1.9mm
36kW 36kW 39kW 36kW 36kW
RGR24X 609*855*1524
1.3mm 1.2mm
1.1mm
1.9mm
1.9mm
24kW 24kW 26kW 24kW 24kW
Model
Oven Dimension
（mm）
OVEN orifice size & heat input
G30 G20 G25.3
29mbar 37 mbar
50 mbar 20 mbar 25 mbar
RGR36X 670x660x350 1.5mm 1.4mm 1.3mm 2.2mm 2.2mm
8.5kW 8kW 8kW 7.2kW 7kW
RGR24X 520x660x350 1.5mm 1.4mm 1.3mm 2.2mm 2.2mm
8.5kW 8kW 8kW 7.2kW 7kW
Page 5
d. Exploded Drawing
RGR36X
Page 6
Part list
SN Part Name Qty SN Part Name Qty
1 Chimney assy 1 28
￠10 nut 13
2 Guide trough for rear protect plate 2 29 φ10 oval clamp 14
3 rear plate assy 1 30 orifice connector 6
4 grate 6 31 orifice fixation plate 6
5 short burner assy 6 32 orifice 7
6 stove body assy 1 33 orifice connector nut 7
7 left side plate 1 34 ￠8 nut M14X1.25 1
8 oven thermostat knob scale 1 35 ￠8 clamp 4
9 zinc knob with insert 1 36 orifice angle connector 1
10 inspection plug for gas inlet pipe 1 37 pilot rack 1
11 flame knob 6 38 thermocouple rack 1
12 Front control panel 1 39 oven thermocouple 1
13 oven door assy 1 40 pilot 1
14 left door decoration bar 1 41 U burner 1
15 front bottom hinge assy 2 42 1/4 to ￠10 transfer connector 1
16 bottom door decoration bar 1 43 CE11 sabaf valve 6
17 crumb tray assy 1 44 valve prolong connector 6
18 gas inlet pipe 1 45 NPT1/8 to ￠10 transfer connector 6
19 oven chamber assy 1 46 ￠6 nut M10x1 1
20 adjustable foot 4 47 ￠6 clamp 3
21 door hinge assy 2 48 thermostat rack B 1
22 right door decoration bar 1 49 ￠8 nut M13x1 1
23 right side plate 1 50 thermostat rack A 1
24 V baffle plate 1 51 thermostat valve with micro switch 1
25 oven chamber bottom plate 1 52 NPT1/8 to ￠10 transfer angle connector 1
26 wire net in chamber 2 53 stove thermopile 6
27 grill supporter 4
Page 7
1. General information
Read the instructions in this manual carefully, as they contain important information on how to install, use and service the appliance
safely, properly, and effectively.
Keep this manual in a safe place so that it can be used as reference by other operators of the appliance.
This appliance should be installed following the instructions provided by the manufacturer and in compliance with all applicable
local regulations. This appliance should be connected to the gas supply by qualified personnel only.
All personnel in charge of using this appliance should be specifically trained in its operation.
In the event of failure or malfunction, switch off the appliance. The periodic functional checks requested in this manual should be
carried out according to the instructions. Have the appliance serviced by a technically qualified person duly authorized by the
manufacturer that uses genuine spare parts.
Failure to comply with the above may jeopardize the appliance’s safety.
2. Safety
2.1 Using the appliance safely
The appliance is designed only for professional use, it should be operated by qualified personnel exclusively.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Never leave the appliance unattended while it is operating.
Do not move the appliance while it is hot.
2.2 Safety instructions in case of malfunction
If the appliance will remain idle for some time or in the event of a failure, abnormal operation, etc., please switch off the control valve of
the appliance and shut off the main gas valve on the pipeline. Call the service center if the appliance cannot work properly.
2.3 Additional prohibitions (hazardous procedures)
Never tamper with the seals of the adjusting screws located on the gas valves.
2.4 Disposing of the appliance
This appliance has been manufactured using recyclable raw materials and does not contain any hazardous or toxic substances. To
dispose of the appliance or its packaging materials, strictly follow the local regulations in force in the place where it is installed.
Packaging materials should be divided according to the material type and delivered to a specific collection site. Ensure it is in compliance
with the environmental protection regulations.
3. Functional description
3.1 Application of the appliance
The appliance is designed for use in the gastronomy and confectionery industries only.
Page 8
3.1.1 Prohibited use
The manufacturer cannot be held liable for any faults caused by defective installation or inappropriate use of the appliance. In such
cases, the warranty shall be null and void.
3.2 Construction
3.2.1 Construction features
Supporting structure is made of SUS stainless steel.
Exterior finish and height-adjustable legs are SUS stainless steel.
Control panels are conveniently shaped and have controls slanted towards the operator.
3.2.2 Cooking surfaces
1. Unit RGR24X with 4 stabilized-flame gas burners made of cast iron and controlled by pilot flames;
Unit RGR36X with 6 stabilized-flame gas burners made of cast iron and controlled by pilot flames;
High-to-low output control;
Safety valves fitted with thermocouple ensure that gas flow will be immediately shut off in the event that a burner is extinguished
accidentally or a failure occurs;
Two-burner acid-resistant black enameled cast-iron grates;
Stainless steel drip pans.
3.2.3 Bottom oven
The temperature of the bottom oven can be adjusted by rotating the thermostat to the desired scale.
Page 9
The user can set the temperature according to different food. It is recommended that the normal working temperature should be
180--250℃. It would take approximately 22~26 minutes for the oven temperature to reach 250℃.
When the temperature reached the pre-set temperature, the thermostat would cut-off the power supply automatically.
When the temperature is lower than the pre-set value, the thermostat would restart working.
After finishing a day’s work, rotate the controlling knob to the OFF position.
4. Installation
4.1 General information
The manufacturer cannot be held liable for any damage to property or injury to persons deriving from installation errors or from
inappropriate use of the appliance and is not responsible for any faults caused by defective installation. In such cases, the warranty shall
be null and void.
The appliance should be installed, serviced, and started up only by an authorized installer, who must comply with the safety regulations
in force in the plac8
e where the appliance is being installed.
4.1.1 Regulatory installation conditions
For your information, we remind you that all appliances installed in public assembly buildings must meet all the requirements listed below.
The appliance should be both installed and serviced in accordance with all applicable regulations and standards in force, namely:
Safety regulations on fire hazard and panic in public assembly buildings.
General regulations applicable to all appliances;
Systems burning combustible gas and liquefied hydrocarbons.
Then, follow the specific regulations according to the type of gas being used.
Heating, ventilation, refrigeration, air conditioning, and generation of steam and hot water for sanitary use;
Installation of foodservice cooking appliances;
Specific regulations applicable to each type of public assembly building (hospitals, shops, etc.).
4.2 Exhausting fumes
The appliance should be installed in a well-ventilated area, if possible under a vent hood, in compliance with all applicable regulations in
force. This will ensure that the flue gas can be completely exhausted.
4.3 Possible environmental interference
If the appliance is installed with its sides next to flammable walls (made of wood or similar materials) or to heat-sensitive walls (made of
plasterboard or similar materials), suitable protective measures should be taken to keep such walls undamaged. Therefore, apply a
coating to insulate the walls from radiative heat or keep a minimum clearance of 200 mm (8") from the side and back panels of the
appliance.
