Adaptec AUA-2000 Manuel utilisateur

R

Adaptec AUA-2000/3100LP/

4000A/5100

USB2connect Adapter

Installation Guide

1

Introduction

This Guide describes how to install Adaptec AUA-2000, AUA-3100LP,

AUA-4000A and AUA-5100 adapters in Windows®and Macintosh®

computers. These USB (Universal Serial Bus) adapters are compatible

with USB 1.1 and USB 2.0 devices and work in virtually any PCI slot.

Note: Refer to the Readme file on the CD for operating system

support.

The AUA-2000 and AUA-3100LP adapters are shown below.

AUA-2000 AUA-3100LP

Internal connector

External

connectors

2

The AUA-4000A and AUA-5100 adapters are shown below.

Note: The AUA-5100 has an internal USB connector (in addition to

five external connectors). For details on enabling the internal

connector, refer to the USB2connect User’s Guide on the CD.

External

connectors

Internal

connector

AUA-5100

AUA-4000A

3

Kit Contents

If you purchased your USB2connect adapter from a retail distributor,

your kit contains the following items:

■One Adaptec USB2connect adapter

■Printed USB2connect Installation Guide

■USB2connect CD containing:

■USB2connect User’s Guide in Acrobat Reader format

■Acrobat Reader software

■Drivers

■Readme file

■Low-profile bracket (AUA-3100LP kits only)

The User’s Guide on the CD provides detailed driver installation

instructions and troubleshooting tips. In addition, the User’s Guide

provides Technical Support, and Warranty information for your adapter.

4

Installing the USB2connect Adapter

1Discharge any static electricity from your body by touching a

grounded metal object (such as the exposed metal parts on the back

of your computer) before handling the USB2connect adapter.

2Turn off power to the computer and disconnect the power cord.

3Open the computer cabinet. See your computer documentation for

specific instructions, if needed.

4Locate an unused 32- or 64-bit PCI expansion slot and remove the

expansion slot cover. Save the slot cover screw for use in Step 6.

64-bit PCI slot

32-bit PCI slot

Expansion

slot cover

Slot cover

screw

5

5Low-profile computers only– To install the AUA-3100LP adapter in a

low-profile computer, replace the existing full-height bracket with

the low-profile bracket included in your kit. Remove and replace the

bracket attachment screws on the adapter as shown below.

6

6Insert the USB2connect adapter in the PCI expansion slot. Press the

adapter firmly into the slot until it clicks into place. Replace the slot

cover screw. When installed properly, the adapter should be level

with the expansion slot, as shown below.

7Close the computer cabinet and reattach the power cord.

8Restart your computer and install drivers for your USB2connect

adapter.

USB2connect card

Slot cover screw

R

Adaptec, Inc.

691 South Milpitas Boulevard

Milpitas, CA 95035 USA

© 2002 Adaptec, Inc.

All rights reserved. Adaptec and the Adaptec logo

are trademarks of Adaptec, Inc. which may be

registered in some jurisdictions.

Part Number: 513288-06, Ver.AALB07/02
