Adam Equipment IHS Series Manuel utilisateur

Adam Equipment

IHS/IHSa SERIES

Software version 1.0

99 Washington Street

Melrose, MA 02176

Phone 781-665-1400

Toll Free 1-800-517-8431

Visit us at www.TestEquipmentDepot.com

Easy Reference:

Model name of the scale:

Serial number of the unit:

Software revision number

(Displa ed when power is first turned on):

Date of Purchase:

Name of the supplier and place:

1.0 ONTENTS

P.N. 700660189, Revision D3, November 2017

1.0

CONTENT 3

2.0

INTRODUCTION 4

2.1 INTRODUCTION 4

2.2 TECHNICAL SPECIFICATION 5

2.3 SAFETY NOTICE 6

2.4 KEY DESCRIPTION (IHS/IHSa) 6

2.5 DISPLAY (IHS/IHSa) 7

3.0

OPERATION 8

3.1 SAFETY INSTRUCTION 8

3.2 BATTERY OPERATION 9

3.3 CHARGING BATTERY 9

3.4 BASIC OPERATION 10

3.5 REMOTE CONTROLLER 10

4.0

CALIBRATION 11

5.0

PARAMETER 11

5.1 ENTER SETTING MODE 11

5.2 PARAMETER SETTING TABLE 12

2.0 INTRODU TION

2.1 INTRODUCTION

The IHS/IHSa Series is a range of heav -dut crane scales used to weigh ver large

masses.

The main features include:

•Eas Operation & Rugged construction

•30mm super big & bright red LED displa with view angle.

•360 degree rotar safet hook design, eas to use

•Hold feature

•Overload safet up to 125%

•One charge can last 150 hours

•Auto power off after 30 minutes of non use

•7.2Vdc 2 amp batter charger

•Aluminum die-casting housing

•Large remote control handset

2.2 TECHNICAL SPECIFICATIONS

Model No apacity Division Model No. apacity Division

IHS

1000kg

0.2kg/0.5kg

IHS

2000lb/

1000kg

0.5lb/

0.2kg

IHS

3000kg

0.5kg/1kg

IHS 6a

6000l

3000kg

1lb/

0.5kg

IHS 5

5000kg

1kg/2kg

IHS 10a

10000lb/

5000kg

2lb/

1kg

IHS

10000kg

2kg/5kg

IHS 20a

20000lb/

10000kg

5lb/

2kg

Model

Weight

IHS 1/2a 260 203 47 30 628 76 214 12kg

IHS 3/6a 260 203 47 30 628 76 214 14kg

IHS 5/10a 260 203 60 40 723 80 214 19kg

HIS 10/20a 260 203 70 50 837 90 214 31kg

2.3 SAFETY NOTICE

The limit stated below is the Ultimate Overload Limits of the scales.

Adam Equipment Co. Ltd. Its directors, owners and affiliated companies and organisations cannot

be held liable for an resulting damage or injur sustained as a result of the machines being used

in excess of their stated capacities or ultimate overload limits.

Model

NO.

IHS 1

/IHS 2a

IHS 3

/IHS 6a

IHS 5

/IHS 10a

IHS 10

/IHS 20a

Max

capacity

1000kg/2000lb

3000kg/6000lb

5000kg/10000lb

10000kg/20000lb

Overload capacity 1250kg/2500lb 3750kg/7500lb 6250kg/1250lb 12500kg/25000lb

NOTI E:

Do not use the scales if an parts are bent or loose or show signs of damage or wear. Refer to the

user manual.

2.4 KEY DESCRIPTION IHS VERSION

[On/Off]

Power switch

use this ke to turn on and turn off the scale.

[

hange

]

Division change ke

use this ke to change division.

When in setting

mode, use this ke to change parameter.

[Hold]

Hold

function;

use this ke to lock the displa .

There is a LED indication

light on the bottom of the displa . Press the [Hold] ke again, to cancel

HOLD function.

[Zero]

zero ke

use this ke to return

zero reading.

2.5 DISPLAY

ower

Power on mode

harge

har

ging mode

ow batter

old

old mode

ero

Zero indicator

2.4 KEY DESCRIPTION IHSA VERSION

[On/Off]

Power switch

use this ke to turn on and turn off the scale.

[lb/kg]

Unit

change ke

use this ke to

select the weighing unit of lb or kg

When in setting mode, use this ke to change parameter.

[Hold]

Hold function, use this ke to lock the displa .

There is a LED indication

light on the bottom of the displa . Press the [Hold] ke again, to cancel

HOLD function.

[Zero]

zero ke

use this

ke to return to zero reading.

2.5 DISPLAY

ero

Zero indicator

harge

harging mode

Low batter

old

old mode

LB weighing mode

KG weighing mode

3.0 OPERATION

3.1 SAFETY INSTRUCTIONS

Read this manual carefull before ou operate the IHS Crane Scale.

•Unpack the Crane Scale carefull from the packing.

•Attach it to our hoist or equivalent existing equipment securel at the ground

level, in the upright position. Make sure that the equipment to which the scale is

attached is in proper condition. The operator should be trained for its safe

operation.

• Carr out regular visual inspection for an damage or wear and teat on parts.

Particularl the split pins at the hook and e ebolts and the inner wall of the hook

and all joints should be checked regularl . If an damage or wear has taken place,

replace the parts.

•Do all inspection and maintenance work when the scale is not in use.

•Do not expose the scale to extreme temperatures. The operating temperature

range is 0° C to 40° C.

•Secure the sample to be weighed in the hook of the scale. Ensure that the sprung

Safet Lever returns to its resting position which prevents the sample from slipping

out of the hook.

•Do not exceed the maximum capacit of the Scale.

•Clean and protect our scale after use.

3.2 BATTERY OPERATION

•The batter will operate continuousl for 150 hours before requiring recharging.

The scale will alert ou when the batter is within 10 hours of requiring recharging

b the indicator lamp above the low batter s mbol to indicate that the batter is

low voltage.

•When the batter requires charging, the scale will turn off to prevent batter

damage. If the button is depressed at this point, the indicator lamp will reappear

and then the scale will again deactivate automaticall .

•Charging time for a completel discharged batter is approximatel 16 hours. A full

batter pack is recommended to keep the scale continuousl operational.

•The scale will automaticall power down after 30 minutes of non use to further

protect the batter .

Note: More frequent charging of the batter prolongs its life.

3.3 CHARGING BATTERY

•Plug the power suppl into the mains power, then into the back of the IHS scale.

•The red indicator lamp will illuminate to indicate that the batter charger is

functioning properl .

•The green indicator lamp will illuminate to indicate that the batter full charged.

3.4 BASIC OPERATIONS

Power on and off- Press [On/Off] ke to turn on the scale. Then the displa on the scale will

show [88888]. Press again to turn off the scale.

Zero the scale-Depress the [Zero] to re-zero the reading.

Change division- ou can use the [ hange/lb/kg] ke to change division.

Lb/kg- ou use this to select either lb or kg weighing units

Hold -when required, such as when the reading is not stable or ou cannot pause to record a

reading, ou can use the [Hold] ke to lock the reading, so that ou can read it easil later,

after ou finish reading, press [Hold] again to return to normal weighing mode.

Note: The [Hold] ke has no affect if the Hold parameter has been disabled. See section 5.1

Overload Warning-: please do not add an item that exceeds the maximum capacit of the scale.

When the buzzer is sounded and the displa shows”-----”, remove the item to avoid damage to the

load cell and scale.

3.5 REMOTE CONTROLLER

A: Determine increments in which the weight displa

B: Hold the settled values

C: Zero the scale

D: Backlight (onl used on scales with LCD displa )
