Features
• The RAPIDA series feature the latest MOS-FET (SOP) components,
which allow powerful braking as well as a forward function.
• Advanced control circuitry using a 4-layer board that allows
high-density mounting of electronic components.
• Utilizes an MPRS*1 system, which has proved very successful in the
A-01 Series in large-current circuits, for compactness and
high-performance.
• With AGCS*2, Schottky diodes are no longer necessary, and motor
voltage loss during pulse drive is reduced to approximately 1 percent.
This results in a longer run-time and prevents the heat generated by
FETs.
• Smooth frequency control allows settings to be adjusted flexibly.
• AWG14 silicone cables, for flexibility and large currents
• Gold-plating is used for all electrical connectors for extremely low
contact resistance.
• Outstanding energy-saving performance can be achieved by setting
the power limiter function to an appropriate value.
• Includes a high-capacity state-of-the-art low impedance capacitor to
minimize electrical noise.
• Improved throttle output resolution for more stable operation.
RAPIDA
• The ZERO offers 20 high-performance surface-mounted FETs that
give an ON-resistance value of 0.41 mΩ(FET standard value),
amongst the lowest in the world.
• You can choose four settings for brake frequency to adjust the
"braking feel" to just how you like it.
• You can switch neutral brake ON/OFF.
• By setting the power limit to an appropriate value, you can drive very
smoothly.
• The uses trimmer specifications for simple operation.
RAPIDA PRO
• The RAPIDA PRO offers 24 high-performance surface-mounted FETs
, for an ON-resistance of 0.34 mΩ, the lowest in the world.
• With the addition of an indicator function, a variety of settings and
measurement can be made easily using only the body of the ESC.
• Equipped with a variety of measuring functions for visual confirmation
of optimum settings.
• Improved receiver and servo power allow the RAPIDA PRO to handle
high torque servo.
