ACU-RITE 13022 Manuel utilisateur

Instruction Manual

SAVE THIS MANUAL FOR FUTURE REFERENCE.

Questions? Contact Customer Support at

(877) 221-1252 or visit www.AcuRite.com.

CONTENTS

Unpacking Instructions ........... 2

Package Contents .................. 2

Product Registration ............... 2

Features & Benets: Sensor..... 2

Features & Benets: Clock ...... 3

Setup .................................... 5

Outdoor Sensor Setup............ 5

Clock Setup ........................... 6

Atomic Clock ......................... 7

Set the Time & Date ............... 7

Placement Guidelines ............. 8

Using the Clock...................... 9

USB Charging........................ 9

Troubleshooting ....................10

Care & Maintenance.............11

Specications........................11

FCC Information ...................11

Customer Support .................12

Warranty..............................12

Atomic Dual Alarm Clock

models 13022 / 13035

Congratulations on your new AcuRite product. To ensure the best

possible product performance, please read this manual in its entirety

and retain it for future reference.

Unpacking Instructions

Remove the protective lm that is applied to the LCD screen prior to using this

product. Locate the tab and peel off to remove.

Package Contents

1. Alarm clock

2. Outdoor sensor

3. Power adapter

4. Instruction Manual

PRODUCT REGISTRATION

to receive 1 year

warranty protection

www.AcuRite.com

IMPORTANT PRODUCT MUST BE REGISTERED

TO RECEIVE WARRANTY SERVICE

►

Features & Benets

OUTDOOR SENSOR

1. Integrated Hanger

for easy placement.

2. Wireless Signal Indicator

Flashes when data is being

sent to the clock.

3. Battery Compartment

4. A-B-C Switch

ID code that must match clock’s

A-B-C switch to ensure units

synchronize.

5. Battery Compartment Cover

DIMMER

VOLUME

ALARM

DC 4.5 v

CHARGE

USB DEVICE

DIMMER

VOLUME

ALARM

DC 4.5 v

CHARGE

USB DEVICE

Features & Benets

BACK OF CLOCK

8. + Brightness Button

Increases display brightness.

9. +/— Alarm Volume

Adjusts alarm volume.

10. — Brightness Button

Decreases display brightness.

11. USB Charging

for compatible smartphones.

12. DC 5v Power Input

BOTTOM OF CLOCK

(inside battery compartment)

13. A-B-C Switch

ID code that must match

sensor’s A-B-C switch to

ensure units synchronize.

14. RCC ON/OFF Switch

Controls synchronization with

the atomic signal.

15. ºF/ºC Temperature Units

16. Reset Button

Full reset to factory defaults.

FRONT OF CLOCK

1. Snooze Button/Night Light

2. Alarm #1 ON/OFF Switch

3. Alarm #1 Setup Button

4. DOWN & SET Buttons

for setup preferences.

5. UP Button

Toggles between displaying

indoor & outdoor temperature

and used for setup

preferences.

6. Alarm #2 Setup Button

7. Alarm #2 ON/OFF Switch

273 65

11 1210

8 9

13 14 15 16

Features & Benets

1. Date

2. Atomic Clock

Sets itself to the correct time and

automatically updates for Daylight

Saving Time.

3. Atomic Signal Strength

4. Outdoor Sensor Low Battery Icon

5. Outdoor Sensor Signal Strength

6. Alarm #1 Time

7. Alarm #1 Days Active

Indicates weekday, weekend or every

day alarm.

8. Alarm #2 Time

9. Alarm #2 Days Active

Indicates weekday, weekend or every

day alarm.

10. Alarm Volume

11. Indoor or Outdoor Temperature

1 2 3 4 5

6 7 89 10

SETUP

Set the A-B-C Switch

The A-B-C switch is located inside

the battery compartment. It can

be set to A, B or C. However,

you must select the same letter

choices for both the sensor and

the clock in order for the units to

synchronize.

Install or Replace Batteries

AcuRite recommends high quality

alkaline or lithium batteries for

the best product performance.

Heavy duty or rechargeable

batteries are not recommended.

The sensor requires lithium

batteries in low temperature

conditions. Cold temperatures

can cause alkaline batteries

to function improperly. Use

lithium batteries in the sensor for

temperatures below -4ºF / -20ºC.

1. Slide off the battery

compartment cover. Take

note of the A-B-C switch

setting inside the battery

compartment for clock setup.

2. Insert 2 x AA batteries into

the battery compartment, as

shown. Follow the polarity

(+/-) diagram in the battery

compartment.

3. Replace the battery cover.

Sensor Setup

1A-B-C Switch

set to match

clock

2Install Batteries

2 AA batteries

A B C

PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE

WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.

BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to be

used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used

batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in ﬁre,

as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge

non-rechargeable batteries. DO NOT short-circuit the supply terminals.

Clock Setup

Set the A-B-C Switch

Locate the A-B-C switch inside

the battery compartment. Set

the A-B-C switch to A, B or C.

You must select the same letter

choices for both the clock and

the sensor in order for the units

to synchronize.

Plug in Power Adapter

For the best performance, plug

in the power adapter as the main

power source for this product.

Install or Replace Backup

Batteries

1. Remove the battery

compartment cover.

2. Insert 3 x AA alkaline

batteries into the battery

compartment, as shown.

Follow the polarity

(+/-) diagram in the battery

compartment.

3. Replace the battery cover.

A B C

IMPORTANT: Batteries are a backup power source to preserve records in the event of a

power outage. Power adapter recommended as the primary power source to enjoy the full

functionality of the product.

Install or

Replace Backup

Batteries

3 AA alkaline

batteries

2Plug in Power

Adapter

(on back of unit)

1A-B-C Switch

set to match

sensor

Atomic Clock (RCC)

AcuRite atomic clocks use a radio-controlled signal (RCC) to synchronize to the

correct time broadcast by the National Institute of Standards and Technology

(NIST) Radio Station WWVB, located near Fort Collins, Colorado. WWVB

broadcasts the current time and date with split-second accuracy.

The atomic clock and calendar will maintain the correct time and date, and

automatically update for daylight saving time to provide the most accurate

timekeeping standard possible.

When the RCC button, located under the battery compartment cover, is set to

ON, the clock will automatically search for the atomic clock signal.

To manually search for the atomic signal, make sure the RCC button is set to

ON, then press AND HOLD the “ “ button.

Please note: Signal reception is normally better at night and when the weather

is clear. The atomic signal generally takes a few hours to synchronize, so it is

important to manually set the time and date after powering on the clock.

Set the Time & Date

Press and hold the “ ” button, located on the front of the clock, to enter SET

MODE. Once in SET MODE the preference you are currently setting will blink

on the clock.

To adjust the currently selected (ashing) item, press and release the “ ” or

“ “ buttons (press and HOLD to fast adjust).

To save your adjustments, press and release the “ ” button to adjust the next

preference. The preference set order is as follows:

TIME ZONE (PST MST CST EST AST HAST AKST)

AUTO DST ON/OFF*

CLOCK HOUR

CLOCK MINUTE

CALENDAR MONTH

CALENDAR DATE

CALENDAR YEAR

You will automatically exit SET MODE if no buttons are pressed for 5 seconds.

Enter SET MODE at any time by pressing the “ ” button.

*If you live in an area that observes daylight saving time, DST should be set to

ON.

Alarm Clock Placement

Place alarm clock in a dry area free of dirt and dust. To help ensure

an accurate indoor temperature measurement, be sure to place the

clock away from heat sources or vents.

Outdoor Sensor Placement

Sensor must be placed outside to observe outdoor conditions.

Sensor is water resistant and is designed for general outdoor use,

however, to extend its life place the sensor in an area protected

from direct weather elements.

Hang the sensor using the integrated hang holes or hanger, or by

using string (not included) to hang it from a suitable location, like a

well covered tree branch. The best location is 4 to 8 feet above the

ground with permanent shade and plenty of fresh air to circulate

around the sensor.

Placement for Maximum Accuracy

AcuRite sensors are sensitive to surrounding environmental conditions. Proper

placement of both the clock and outdoor sensor are critical to the accuracy

and performance of this product.

Important Placement Guidelines

• To ensure accurate temperature measurement, place units out of direct

sunlight and away from any heat sources or vents.

• Clock and outdoor sensor must be within 330 ft (100 m) of each other.

• To maximize wireless range, place units away from large metallic items, thick

walls, metal surfaces, or other objects that may limit wireless communication.

• To prevent wireless interference, place both units at least 3 ft (.9 m) away

from electronic devices (TV, computer, microwave, radio, etc.).

Setup is Complete

The sensor will now synchronize with the clock. It may take a few minutes for

synchronization to complete.

(100 meters)

(330 feet maximum)

(.91 m)

LEAST

APART

DIMMER

VOLUME

ALARM

DC4.5 v

CHARGE

USBDEVICE

Using the Clock

Set the Alarm Time

Slide Alarm #1 and/or Alarm #2 switch ON (alarm time cannot be adjusted if

the alarm is OFF).

Press and release the “ ” or the “ ” button to enter ALARM SET

MODE.

To adjust the currently selected (ashing) item, press and release the “ ” or

“ “ buttons (press and HOLD to fast adjust).

To save your adjustments, press and release the “ ” or “ “ button to

adjust the next preference. The preference set order is as follows:

ALARM CLOCK HOUR

ALARM CLOCK MINUTE

ALARM EVERY DAY or WEEKDAY ONLY or WEEKEND ONLY

You will automatically exit ALARM SET MODE if no buttons are pressed for 5

seconds. Enter ALARM SET MODE at any time by pressing the “ ” or

“ “ button.

Backlight

During power adapter use, press the Snooze button for momentary backlight

at 100% brightness. During battery-powered use, press any button for

momentary backlight.

The backlight MAY turn off at 2:00AM and 3:00 AM to acquire the atomic

clock (RCC) signal.

USB Charging

Charge your mobile device by plugging your device’s USB

power cord (not included) into the USB charging port on

the back of the clock.

USB charging is only available during power adapter use;

USB charging is not active when operating on battery power

only.

Note: Follow the manufacturer’s instructions for your mobile

device(s) to determine compatibility with the USB charging

feature on this product. Some devices may not support USB charging or

may require a higher power rating than this product provides. Observe the

charging status on your device. Ensure your device is working properly before

attempting to charge.

DIMMER

VOLUME

ALARM

DC 4.5 v

CHARGE

USB DEVICE

OPERATION

Troubleshooting

No outdoor sensor

reception

no bars

If the wireless signal indicator shows no bars:

• Relocate the clock and/or the outdoor sensor. The units

must be within 330 ft (100 m) of each other.

• Make sure both units are placed at least 3 feet

(.9 m) away from electronics that may interfere with

the wireless communication (such as TVs, microwaves,

computers, etc).

• Use standard alkaline batteries (or lithium batteries in

sensor when temperature is below -4ºF/-20ºC). Do not

use heavy duty or rechargeable batteries. NOTE: It may

take up to 20 minutes for clock and sensor to synchronize

after batteries are replaced.

Clock is too dark,

hard to read or

doesn’t work

• The backlight may automatically turn off for 10 minutes at

2:00am and 3:00am to acquire the atomic clock signal.

• Verify power adapter is plugged in.

• Check that the batteries are installed correctly. Batteries

may need to be replaced.

• Increase brightness using +/– buttons, located on the

back of the clock.

• The optimum viewing angle for this product is from slightly

above it.

• Reset the unit by pressing the reset button, located on the

bottom of the clock.

Inaccurate

temperature

• Make sure both the clock and sensor are placed out of

direct sunlight and away from any heat sources or vents

(see page 8).

Outdoor

temperature

is ashing or

showing dashes

Flashing of the outdoor temperature is generally an

indication of wireless interference.

1. Bring both the sensor and clock indoors, side by side

and remove batteries from each.

2. Make sure the A-B-C switch on both units match.

3. Reinstall batteries in outdoor sensor.

4. Reinstall batteries in clock.

5. Let the units sit within a couple feet of each other for

about 20 minutes to gain a strong connection.

Atomic signal or time

syncing problems

For additional troubleshooting, please visit:

http://www.nist.gov/pml/div688/grp40/radioclocks.cfm

If your AcuRite product does not operate properly after trying

the troubleshooting steps, visit www.AcuRite.com or call

(877) 221-1252 for assistance.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ACU-RITE Réveil

ACU-RITE

ACU-RITE 13239CC Manuel utilisateur

ACU-RITE

ACU-RITE 13131A3 Manuel utilisateur

ACU-RITE

ACU-RITE 15607 Manuel utilisateur

ACU-RITE

ACU-RITE Intelli-Time 13001 Mode d'emploi

ACU-RITE

ACU-RITE Intelli-Time 13019W2 Manuel utilisateur

ACU-RITE

ACU-RITE Set and Forget Manuel utilisateur

ACU-RITE

ACU-RITE 13239CCDI Manuel utilisateur

ACU-RITE

ACU-RITE 15606 Manuel utilisateur

ACU-RITE

ACU-RITE 13024 Manuel utilisateur

ACU-RITE

ACU-RITE 15607 Manuel utilisateur

ACU-RITE

ACU-RITE 13131A3 Manuel utilisateur

ACU-RITE

ACU-RITE 13041CAUDI Manuel utilisateur

ACU-RITE

ACU-RITE Intelli-Time 13003 Manuel utilisateur

ACU-RITE

ACU-RITE 13131A3 Manuel utilisateur

ACU-RITE

ACU-RITE Intelli-Time 13041RM Manuel utilisateur

ACU-RITE

ACU-RITE 15605 Manuel utilisateur

ACU-RITE

ACU-RITE Intelli-Time 13030 Manuel utilisateur

ACU-RITE

ACU-RITE 13020 Manuel utilisateur

ACU-RITE

ACU-RITE 13239CCDI Manuel utilisateur

ACU-RITE

ACU-RITE Atomic Clock Manuel utilisateur

ACU-RITE

ACU-RITE Intelli-Time 13027 Manuel utilisateur

ACU-RITE

ACU-RITE Set & Forget 19956 Manuel utilisateur

ACU-RITE

ACU-RITE 13024A1 Manuel utilisateur

ACU-RITE

ACU-RITE 13021 Manuel utilisateur

Manuels Réveil populaires d'autres marques

Steren

Steren CLK-210 Manuel utilisateur

COP-USA

COP-USA ALCDVR32-SL Manuel utilisateur

Philips

Philips HF3505/70 Manuel technique

Casio

Casio PQ-70 Manuel utilisateur

iHome

iHome IA63 Manuel utilisateur

Coopers

Coopers 9765 Manuel utilisateur

ANJANK

ANJANK AC-190 Mode d’emploi

TFA

TFA 98.1075 Manuel utilisateur

Sharper Image

Sharper Image 204050 Manuel utilisateur

Lumie

Lumie Zest Manuel utilisateur

Dexford

Dexford RCT200 Manuel utilisateur

Philips

Philips AJL303/37B Manuel utilisateur

RST

RST Q754 Manuel utilisateur

iHome

iHome iKT50 Manuel utilisateur

Sony

Sony dash HID-B7 Manuel utilisateur

SVINZ

SVINZ SCC009 Manuel utilisateur

Clas Ohlson

Clas Ohlson 918863 Manuel utilisateur

IKEA

IKEA FNURRA Manuel utilisateur
