Control for Fire and Comfort Ventilation Type SVM 24V-5A / SVM 24V-8A Control for Fire and Comfort Ventilation Type SVM 24V-5A / SVM 24V-8A
Connection of more controls to one re group (bus connection)
By means of a bus communication it is possible to make 2 – 35 control panels to work as a complete
system. The control panels communicate with each other via a 3 wire bus connection. This could e.g. be a
3x0.5 mm² reproof cable.
Terminal no. A1, A2, A3 are for the incoming connection and B1, B2, B3 for the outgoing connection.
In the rst control panel start Bus J4 has to be on. This control is Master and J5 must therefore also be on.
The bus cable is connected on the output terminals B1, B2, B3 and lead to the next control panel which
is a slave, J6 must therefore be on. The cable is connected to the input terminals A1, A2, A3 of the next
control panel and further to the next slave control panel from terminal B1, B2, B3. In the last slave control
panel J7 and J6 must be on in order to terminate the bus connection.
ALARM: Alarms from Manuel Control Point smoke-/heat detectors are controlled locally. When DIP11 is
set the panel will go into alarm state if another control panel connected on the BUS enters alarm state
RESET: If the reset button on one control or in one re switch is activated, the reset function on all
connected controls is activated and starts the closing function on all motor output in approx. 180 sec.
COMFORT: The comfort control can work locally on each control panel. When DIP 10 is set the control
panel will react on any comfort signal send on the bus from another control panel.
If a wind- and rain sensor is connected, it will work on all control panels on the bus no matter dip settings.
Function description for control panels connected with bus connection
If more control panels are connected by means of a bus connection, the following are monitored/
communicated between the control panels:
- A detected bus error makes the LED LD7 on the main board light/ash.
- A detected bus error brings all controls on the bus connection in error condition (line error).
- If one of the control panels in the network goes into alarm condition, all go into alarm condition.
- If one of the control panels goes into a certain error condition (line error, AC error, battery error or
bus error), the other control panels also go into error condition – the type of the error is indicated
on the board of the front plate of all control panels – on the control panel(s) which have not caused
the error, the ok LED on the board of the front plate ashes at the same time as the error. On the
control panel(s) which have caused the error, the OK LED is switched off.
A4
REV:
SIZE:
www.actulux.com
DATE: 26-09-17
TITLE:
SCALE:
Denmark
1:1
DRAWN BY: PSP
DK 9560 Hadsund
Haandvaerkervej 2
2 OF 3
SHEET:
DWG NO.:
211704_06
Actulux A/S Phone int.: +45 98 57 40 90
Fax int.: +45 96 15 28 00
e-mail: info@actulux.com
ENGELSK/TYSK
BUS Master
MASTER
J6
Fireproof
J4
START termination
Slave
BUS connection
Fireproof
Serial InSerial In
Serial Out
Serial Out
B1A3 B2
A1
A3A2
B2B1
A3A2
B2
B1
B3B2B1A3A2
BUS connection
BUS Slave
A1
Last Control Panel on BUS
3x0,5mm²
Serial Out
Serial In
3x0,5mm²
First Control Panel on BUS
Master
START TERM.
J4
MASTER
J5
SLAVE
J6
END TERM.
J7
START TERM.
J4
MASTER
J5
SLAVE
J6
END TERM.
J7
END TERM.
J7
SLAVE
J5
START TERM.
START termination
BUS Master
BUS Slave
END termination
START termination
BUS Master
BUS Slave
END termination
END termination
Please notice
mounted jumpers
Slaver
0-33 Control Panels on BUS
Connection of weather sensor / Close all function
A weather sensor can be connected to the control panel.
The weather sensor is adjusted according to the instructions.
Actuators should be closed when the wind is above 6 m/s.
LED LD3 on the main board indicates active weather sensor - lights
as long as input is active.
As long as the weather sensor is active, motor inputs cannot be opened with
comfort switches.
The weather sensor closes on all controls which are connected through bus
connection.
On the input to weather station a weekly timer can be connected which makes
sure that everything is closed, e.g. by end of a working day.
Power Supply to terminal 22 and 23 is only AC supplied as standard.
If battery backup is needed, then mount J11 .
This is only possible at PCB V5 and following versions.
NOTE: Be aware of standby time due to current consumption.
