Active Online D-A1 Manuel utilisateur
Remark
Please follow the user manual for correct installation and testing, if
there is any doubt please call our tech-supporting and customer
center.
Our company applies ourselves to reformation and innovation of our
products. No extra informing for any change. The illustration shown
here only used for reference, if there is any difference please take the
actual product as standard product.
Commercial in Confidence
WWW.ACTIVEONLINE.COM.AU
+61 (0)7 5551 0306
CATALOG
Pictures. .....................................................................1
Basic Function ...........................................................3
Technology Parameters .............................................3
Basic Settings ............................................................3
Web Settings ............................................................12
Basic Operation .......................................................18
System Configuration ..............................................19
System Diagram.......................................................20
Installation................................................................21
Notes..... ...................................................................23
Commercial in Confidence
WWW.ACTIVEONLINE.COM.AU
+61 (0)7 5551 0306
-1-
Model: D-A1
Infrared LEDs
Swiping card area
Speaker
Camera
Display screen
Microphone
Digital keyboard
Model: D-A3
Infrared LEDs
Camera
Speaker
Display screen
Digital keyboard
Swiping card area
Microphone
Pictures
Commercial in Confidence
WWW.ACTIVEONLINE.COM.AU
+61 (0)7 5551 0306
Model: D-X1 (with touch screen)
6 5
4
3
2
#
0
9
8
7
Model: D-X5 (with keyboard)
Camera
Digital keyboard
Swiping card area
Microphone
Infrared LEDs
Display screen
-2-
Speaker
Camera
Display(3.5"LCD)
Digital keyboard
Card reader area
Infrared light
Microphone
Speaker
Commercial in Confidence
WWW.ACTIVEONLINE.COM.AU
+61 (0)7 5551 0306
1. Working voltage：DC12V
2. Standby power: without heating film: 3W;
with heating film: 9W
3. Rated power: without heating film: 6W;
with heating film: 12W
4. Working temperature: without heating film: -10℃～+55℃;
with heating film: -40℃～+55℃
5. Relative humidity: 20%～93%
6. Storage temperature: -20℃～+70℃
-3-
Basic Function
Technology Parameters
1. Intercom with indoor monitor and management center.
2. Support IC/ID card.
3. Register IC/ ID card and backup the card information, store ten thousand IC/ID
cards at most.
4. Unlock by password, exit button, with door magnetic inspection.
5. Support standard SIP protocol.
Power on the outdoor panel, it will enter into the following interface:
Basic Settings
User Manual
Center: 0000 + #
Call: RoomNo + #
Unlock : #+ PSW + #
Press # button twice, the system will enter into the following interface:
Password:
[ ]
#OK *Cancel 2Up 8Down
Commercial in Confidence
WWW.ACTIVEONLINE.COM.AU
+61 (0)7 5551 0306
#OK *Cancel 2Up 8Down
1. Application
-4-
Press “2” button to page up, press “8” button to page down; press “#” button to
confirm; press “*” button to go back.
Input 6 digits password (the default password is 123456) to enter the following outdoor
panel settings:
Main interface includes the following contents:
Application—— system application parameters settings
System setup—— system configuration parameters settings
System information—— system parameters information
About us—— developer and version information
Select the content you want to set, then press “#” button to enter setting or press “*”
button to cancel settings.
1. Application
Select “ Application”, then press “#” button to enter into the following interface:
1. Reg. card
2. Unlock
3. Delay
#OK *Cancel 2Up 8Down
4. Password
5. Unlock PSW
6. Ring tone
#OK *Cancel 2Up 8Down
7. Language
8. Elevator
9. Panel mode
#OK *Cancel 2Up 8Down
Press “2” or “8” button to page up and down.
Commercial in Confidence
WWW.ACTIVEONLINE.COM.AU
+61 (0)7 5551 0306
1.1 Reg. card
Select this item, then press “#” button to enter into the following interface:
Register card
#OK *Cancel
Room No.-[ ]
Press room No. firstly, then get the access card closed to swiping card area, the
system will display “ Success”, now this card registration is successful.
1.2 Unlock
Select this item, then press “#” button to enter into the following interface:
Unlock Timeout
#OK *Cancel
Value-[ ]
Param-[ 1-9 ]
Press any digit from 1～9.
For example, if press 8, it indicates that the setting unlocking time is 8 seconds.
When the user unlock the door, it will be auto-closed after 8 seconds.
Press “#” button to confirm after setting, the system will display “ Success”, now
the setting is successful.
1.3 Delay
Delay Unlock
#OK *Cancel
Value-[ ]
Param-[ 0-9 ]
Select this item, then press “#” button to enter into the following interface:
Press any digit from 0～9.
For example, if press 5, it indicates that the setting delay unlocking time is 5
seconds. When the user press “Unlock” button on the indoor monitor, the door will be
open after 5 seconds.
Press “#” button to confirm after setting, the system will display “ Success”, now
the setting is successful.
-5-
Commercial in Confidence
WWW.ACTIVEONLINE.COM.AU
+61 (0)7 5551 0306
-6-
1.4 Password
Select this item, then press “#” button to enter into the following interface:
New Password
#OK *Cancel
[ ]
Input the password you want to change, the password has 6 digits at most.
Press “#” button to confirm after setting, the system will display “ Success”, now
the setting is successful.
Warning: If you forget the password, you will not enter into the system and the
password cannot be recovered, now the outdoor panel will be sent back to the factory.
So kindly note that keep the password well.
1.5 Unlock PSW
Select this item, then press “#” button to enter into the following interface:
New Unlock PSW
#OK *Cancel
[ ]
Input the password you want to change, the password has 6 digits at most.
Press “#” button to confirm after setting, the system will display “ Success”, now
the setting is successful.
Remark: every outdoor panel has one unlock password only.
1.6 Ring tone
Select this item, then press “#” button to enter into the following interface:
Ring Tone
#OK *Cancel
Value-[ ]
Param-[1-4 ]
Commercial in Confidence
WWW.ACTIVEONLINE.COM.AU
+61 (0)7 5551 0306
-7-
Press any digit from 1～4, different digit refers to different ring tone.
Press “#” button to confirm after setting, the system will display “ Success”, now
the setting is successful.
Language
1: CN 2: EN 3: RUS
4. TW
Value-[ ]
Select this item, press “#” button to enter into the following interface:
Press any digit from 1～4, different digit refers to different language.
1 is refer to Chinese, 2 is refer to English, 3 is refer to Russian, 4 is refer to
Taiwanese.
Press “#” button to confirm after setting, the system will display “ Success”. Now
the system will restart and switch into the language you change.
1.7 Language
1.8 Elevator
Select this item, then press “#” button to enter into the following interface:
Elevator Setting
#OK *Cancel
Refer To:[ ]
Set the referential floor, the parameters is 01～99. The referential floor is refer to
the floor that outdoor panel exits.
Press “#” button to confirm after setting, the system will display “ Success”, now
the setting is successful.
When you unlock the door after setting, the elevator will fall to the floor that
outdoor panel exits.
Remark: when elevator control device connected with the outdoor panel, this
setting will be valid.
Commercial in Confidence
WWW.ACTIVEONLINE.COM.AU
+61 (0)7 5551 0306
-8-
Panel Mode
#OK *Cancel
Value-[ ]
Unit-[ 0 ] Wall-[ 1 ]
1.9 Panel Mode
Select this item, then press “#” button to enter into the following interface:
This device is used as the outdoor panel and wall station. The panel mode can be
set through this item.
Press “0", this device is used as outdoor panel, and input “1”, it is used as wall
station. If choose unit, it only can call indoor monitors which connect with this outdoor
panel; if choose wall, it will call all indoor monitors in the whole community.
Press “#” button to confirm after setting, the system will display “ Success”, now
the setting is successful.
2. System Setup
2.1 Device No.
Select this item, then press “#” button to enter into the following interface:
Device No.
#OK *Cancel
No. -[ ]
Param-[ 1-9 ]
Press any digit from 1～9, there are 9 outdoor panels can be connected in one unit
at most.
Press “#” button to confirm after setting, the system will display “ Success”, now
the setting is successful.
2.2 Address No.
Select this item, then press “#” button to enter into the following interface:
