1-2
CONTENTS
- Outline And Dimensions page i – ii
- Safety Precautions page 2
- Installation Diagram page 3
- Installation of Indoor Unit page 3
- Electrical Wiring Connection page 6
SAFETY PRECAUTIONS
Before installing the air conditioner unit, please read the following safety precautions carefully.
!Caution
Please take note of the following important points when installing.
• Do not install the unit where leakage of flammable gas may occur.
If water leaks and accumulates around the unit, it may cause fire ignition.
• Ensure that the drainage piping is connected properly.
If the drainage piping is not connected properly, it may cause water leakage which will dampen the
furniture.
• Ensure that the units panel is closed after service or installation.
Unsecured panels will cause the unit to operate noisily.
- Indicator Lights page 9
- Overall Checking page 9
- Auto Random Re-Start Function page 9
- Service and Maintenance page 10
- Troubleshooting page 10
IMPORTANT
DO NOT INSTALL OR USE THE FAN COIL UNIT IN A LAUNDRY ROOM.
!Warning
• Installation and maintenance should be performed by qualified persons who are familiar with local code and
regulation, and experienced with this type of appliance.
• All field wiring must be installed in accordance with the national wiring regulation.
• Ensure that the rated voltage of the unit corresponds to that of the name plate before commencing wiring work
according to the wiring diagram.
• The unit must be GROUNDED to prevent possible hazard due to insulation failure.
• All electrical wiring must not touch the refrigerant piping or any moving parts of the fan motors.
• Confirm that the unit has been switched OFF before installing or servicing the unit.
