WELCOME GUIDE
Copyright © Acorn Computers Limited 1989
Designed and written by Acorn Computers Technical Publications Department
Neither the whole nor any part of the information contained in, nor the product
described in this Guide may be adapted or reproduced in any material form except
with the prior written approval of Acorn Computers Limited.
The products described in this manual are subject to continuous development and
improvement. All information of a technical nature and particulars of the products
and their use (including the information and particulars in this Guide) are given by
Acorn Computers Limited in good faith. However, Acorn Computers Limited cannot
accept any liability for any loss or damage arising from the use of any information or
particulars in this manual, or any incorrect use of the products. All maintenance and
service on the products must be carried out by Acorn Computers' authorised dealers.
Acorn Computers Limited can accept no liability whatsoever for any loss or damage
caused by service, maintenance or repair by unauthorised personnel.
If you have any comments on this Guide, please complete and return the form on the
last page to the address given there. All other correspondence should be addressed to:
Customer Support and Service
Acorn Computers Limited
Fulbourn Road
Cherry Hinton
Cambridge CB1 4JN
Information can also be obtained from the Acorn Support Information Database (SID)
. This is a direct dial viewdata system available to registered SID users. Initially,
access SID on Cambridge (0223) 243642: this will allow you to inspect the system
and use a response frame for registration.
ACORN and ECONET are trademarks of Acorn Computers Limited.
Centronics is a trademark of Centronics Data Computer Corporation.
Within this publication, the term 'BBC' is used as an abbreviation for 'British
Broadcasting Corporation'.
First published 1989
Published by Acorn Computers Limited
ISBN 1 85250 064 6
Part number 0480,051
Issue 2
Guidelines for safe operation
The equipment described in this guide is designed and manufactured to comply with
international safety standards IEC380 (BS5850), and is intended for use only as a
desktop computer. It must not be used for other purposes. It is most important that
unpacking and installation is carried out in accordance with the instructions given in
this Guide.
In the interests of continued safe and reliable operation, observe the following
guidelines:
• Keep the machine at a room temperature of 5-35° C (41-95° Fahrenheit) and a
relative humidity of 15-90% (non-condensing).
• Avoid sudden extremes in temperature, exposure to direct sunlight, heat sources (
such as an electric fan heater) or rain.
• Make sure that the equipment is standing on a suitable rigid horizontal flat surface,
allowing enough space for air to circulate when it is in use.
• Ensure that wires and cables are routed sensibly so that they cannot be snagged or
tripped over. Don't tug or twist any wires or cables, or use them to hang or lift any
of the units.
• Keep the original packaging in case you need to transport the computer, and avoid
bumping or jarring it in transit.
• DON'T attempt to open any display or monitor unit, whether supplied with the
equipment or not.
• DON'T spill liquids on the machine. If liquid does spill, turn the machine off
immediately and take it to your supplier for assessment.
• DON'T drop the equipment or subject it to excessive bumping and jarring.
• DON'T obstruct or poke objects through the ventilation openings in the computer
casing, or cover them with anything.
• DON'T exceed a maximum power consumption of 5 watts from the expansion
port supply.
• DON'T balance any objects, or stand equipment on top of the computer, except
when using an Acorn-approved monitor stand, available from your Acorn
supplier.
For United Kingdom
users
For all users
Warning: this computer must be earthed.
Important: The wires in the mains lead for the computer are coloured in accordance
with the following code:
Green and yellow: Earth
Blue: Neutral
Brown: Live
The moulded plug must be used with the fuse and fuse carrier firmly in place. The
fuse carrier is the same basic colour (though not necessarily the same shade of that
colour) as the insert in the base of the plug. Different manufacturers' plugs and fuse
carriers are not interchangeable. In the event of loss of the fuse carrier, the moulded
plug MUST NOT be used. Either replace the moulded plug with another conventional
plug wired as described below, or obtain a replacement fuse carrier from an Acorn
Computers authorised dealer. In the event of the fuse blowing, it should be replaced,
after clearing any faults, with a 3-amp fuse that is ASTA approved to BS1362.
If the socket outlet available is not suitable for the plug supplied, first check that the
outlet is not of a different mains voltage or frequency from the computer. Provided it
is the same, either a different lead should be obtained or the plug should be cut off
and the appropriate plug fitted and wired as noted below. The moulded plug which
was cut off must be disposed of as it would be a potential shock hazard if it were to be
plugged in with the cut off end of the mains cord exposed.
As the colours of the wires may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured green and yellow must be connected to the terminal in the
plug which is marked by one of the following: the letter E, the safety earth symbol,
the colour green, or the colour green and yellow.
The wire which is coloured blue must be connected to the terminal which is marked
with the letter N, or coloured black.
The wire which is coloured brown must be connected to the terminal which is
marked with the letter L, or coloured red.
III
Welcome to the A3000 computer
The first part of this Guide introduces your new A3000 computer; it
explains how to connect it together and how to start using it.
It doesn't matter if you've never used a computer before — the A3000
system is easy to use, and you need learn only a few simple techniques
and terms to get going. You can pick up the details as you go along.
Once you've set everything up and mastered the techniques described in
this guide, the User Guide will help you to get the best out of your
A3000 system and answer many other questions you may have about
the software side of things — the operating system and the applications
supplied with your computer.
The second part of the Guide gives you some advice about looking after
your computer. It also contains some more detailed information about
the A3000 computer, which you may need to refer to when you want to
use equipment such as printers.
At the end of the Guide there is a Glossary to help you with computer
terminology that you may find unfamiliar. Terms explained in the
glossary are printed in italics the first time they appear in the Guide.
Welcome to the A3000 computer 1
Contents
Unpacking
Setting up the computer
Getting started
Using the mouse
Discs and the disc drive
Windows
Menus
Using the keyboard
Files and directories
Outside the desktop
If things go wrong
Describes what you should find when you open the box containing 5
your A3000 computer. Check the contents to make sure you have
everything.
Explains how to connect everything together. 7
Tells you how to turn the computer on and describes the display 9
on the screen.
Describes what the
mouse
does and how to use it. 13
Tells you about the floppy discs used with the A3000 computer. 19
Explains the special features of the screen display. 23
Explains how to select items from menus displayed on the screen. 33
Introduces the keyboard and some of its features. 37
Explains how to save your work in an organised way, make copies 41
of it, and delete work you no longer need.
Tells you how to enter *Commands direct to the operating
system
47
(this chapter will be of interest to computer users with some experience).
Offers solutions to some common problems you might encounter. 49
2 Contents
A3000 hardware
reference section
Maintaining your
computer
Plugs and sockets
Pin connections
Glossary
The next
three chapters contain some advice on looking after
your computer,
along with some more technical reference information. They
are
marked with a
grey block on the edge of the paper.
Tells you how to clean the computer and mouse, and how to 51
ensure that the internal cell stays charged.
Identifies the main hardware parts that you can see on the 55
outside of the computer, especially the sockets on the back.
Describes in detail how the pins in the sockets are wired. 59
Brief explanations
of
the terminology used in this Guide. 63
Contents 3
4 Contents
