Acnodes APS911 Series Manuel utilisateur

APS911X

15” / 19” Panel Mount LCD

S t a i n l e s s S t e e l C h a s s i s

F u l ly I P 65 R a t ed E n c lo s u re

Industrial

Monitors

User Manual

For lastest product information, please visit Acnodes’ website at www.acnodes.com

14628 Central Ave. Chino, CA91710 Tel: 909.597.7588 Fax: 909.597.1939

Warning!

Disclaimer

This information in this document is subject to change without notice. In no event shall Acnodes Corp. be

liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse

of information in this document or in any related materials.

Electric Shock Hazard –Do not operate the machine with its back cover removed. There are

dangerous high voltages inside.

This equipment generates, uses and can radiate radio frequency energy and if not installed and

used in accordance with the instructions manual, it may cause interference to radio communications.

It has been tested and found to comply with the limits for a Class Acomputing device pursuant to

FCC Rules, which are designed to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a residential area is likely

to cause interference in which case the user at his own expense will be required to take whatever

measures may be required to correct the interference.

Table of Contents

Warning!…………………………………………………………………………….……..….2

Disclaimer………………………………………………………………….…………………2

Chapter 1 Getting Started

1.1 Specifications…………………………………………....……………...….5

1.2 Dimensions…………………………………...………………………….…6

1.3 Brief Description. ................................................................................ 8

1.4 Display Mode……………………………………………………………….9

Chapter 2 OSD

2.1 Front Panel Controls……………………………………………….……….10

2.2 OSD Controls…………………..………………………………………….11

2.3 Main Menu…..………..……………………………………………………..12

2.4 AD Board OSD Functions…….………………...………………….………14

Chapter 3 Installation

3.1 Windows 2000/XP Driver Installation…………………………………….15

3.2 Configuring PenMount Windows 2000/XP Driver………………………19

3.3 Uninstall PenMount Windows 2000/XP Driver………………………….29

Chapter 4 Software

4.1 Software Functions………………………………………………………..30

4.2 Software Function Descriptions……………………………………….…31

Appendix A: Board Description & Specifications………………….41

Figures

Figure 1.1: Dimensions of APS9115.….………………………………………..6

Figure 1.2: Dimensions of APS9119.………………………………………….7

Figure 1.3: Front View of the APS911X…..………….……………………….8

Figure 1.4: Rear View of the APS911X.…………….………………………….8

Figure A: VESA-mounting………………………….……………………….….40

Appendix

VESA-mounting…………………………………………………………..40

Chapter 1 Getting Started

1.1 Specifications

Model No.

Specs

APS9115

APS9119

Display Type

15”TFTLCD

19”TFTLCD

Max. Resolution

1024x768

1280x1024

Max. Color

16.7M

Luminance (cd/m²)

300

350

Viewing Angle (H/V)

150/140

170/160

Backlight Lifetime

50,000 Hours

On Screen Display

Control

On the rear side

External I/O Port

Default:

1 x VGA Input

1 x DC

Optional:

Touch I/O

Power Input

DC 11~32V

Touch Screen Type

Resistive Touch

Construction

Stainless Steel Enclosure

IP Rating

IP 65

Mounting

VESA75x75 Mount

VESA100x100 Mount

Dimensions (WxHxD)

399x324x53 mm

470x388.6x60 mm

Net Weight

6.8kgs

9.9kgs

Operating Temperature

0~50℃

Storage Temperature

-20~60℃

Storage Humidity

10~90% @40℃(non-condensing)

Certificate

CE / FCC Class A

1.2 Dimensions

Figure 1.1: Dimensions of APS9115

Figure 1.2: Dimensions of APS9119

1.3 Brief Description of the APS911X

The APS9115/9119 is a total IP65 Stainless Steel Enclosure LCD Display, which comes with a 15 inch

(luminance of 300 cd/m²) / 19 inch (luminance of 350 cd/m²) TFT LCD. APS9115 comes with viewing

angle of 150 (H) degrees and 140 (V) degrees, APS9119 comes with viewing angle of 170 (H)

degrees and 160 (V) degrees, and more outstanding features, thus giving you the best in monitoring

and control applications

The front panel of the display monitor is sealed with gasket for NEMA 4/IP 65 rating when it is

panel-mounted in a NEMA rated cabinet or enclosure. It can also be VESA 100-mounted. It is optional

to be equipped with a resistive touch screen.

Figure 1.3: Front View of APS9119 (Left)/ APS9115 (Right)

Figure 1.4: Rear View of APS911X

1.4 Display Mode

Display Mode

Hori. Sync (KHz)

Vert. Sync. (Hz)

VGA 640 x 480

SVGA 800 x 600

XGA 1024 x 768

SXGA

1152 x 864

1280 x 1024

Chapter 2

2.1 Front Panel OSD Functions

Auto Adjust Up/Left Down/Right Power

Menu/Entry

PowerIndicator

Power switch: To turn ON or OFF the power

Shift the icon to the right side or shift it up

Shift the icon to the left side or shift it down

Menu: To enter OSD menu for related icon and item.

Auto Button: One-touch auto adjustment

1.) Getting into Burn-in Mode

Before setting into a burn-in mode, first disconnect the AC power cord. Then press (don‟t let them go)

the buttons until the AC power cord is connected and the “RGB” appears on the top left corner

of your screen. Now it can be put into the burn-in mode for changing colors.

2.) Getting Out of Burn-in Mode

Before getting out of the burn-in mode, please first disconnect the AC power cord. Then press the

button (If not workable, press the button and don‟t let them go) until the AC power cord is

connected. Please don‟t let your fingers go until the AC power cord is connected again and the

wording of “RGB”appears on the top left corner of your screen, and wait for 3 seconds. Under the

non-signal entry situation, if is seen, exit is thus successfully made.

Cable Not Connected
