Acer View 54e Manuel utilisateur
User’s Guide 1
AcerView 54e (15” monitor, 13.6” viewable
image)
1. Installing the Monitor
Product Package
Open the shipping carton and check the contents. If any item are missing or
damaged, contact your dealer immediately.
The package should include the following items:
ŸColor monitor
ŸSwivel base
ŸUser‘s guide
ŸPower cord
ŸSignal cable
Installing the Swivel Base
Follow these steps to install the swivel base:
2User’s Guide
1.
2.
Turn the monitor on its
side or upside-down.
Insert the pegs on the
swivel base into the
cavities at the bottom of
the monitor. Push on
the swivel base until the
latch clicks shut.
Installing the Monitor
This monitor is equipped with an autosensing power supply for voltage
ranges 100-120VAC/200-240VAC, 60/50 Hz. Confirm the line voltage
designation on the rear panel of the monitor.
Follow these steps to install the monitor:
1.
2.
Before you connect the
cables, make sure that
the monitor and the
system unit power
switches are Off.
Plug one end of the 15-
pin signal cable to the
monitor and the other
end to the video signal
connector at the rear of
the system. Tighten the
two screws on the cable
User’s Guide 3
3.
.
connector.
Connect the power
cable.
4User’s Guide
2. Control Functions
The monitor digital control functions are located on the front panel. They
are shown in the figure below and described in the following paragraphs.
1. Power Switch 7. Vertical Size
2. Adjust 8. Horizontal Phase
3. Select 9. Horizontal Size
4. Trapezoid 10. Contrast
5. Pincushion 11. Brightness
6. Vertical Center
User’s Guide 5
LED indicators
Each LED represents a different display adjustment. Use the Select button
to choose the item to be adjusted and the Adjust button to change the
setting.
.Brightness: Adjusts the brightness of the display.
.Contrast: Adjusts the contrast, the difference between
the light and dark areas on the screen.
.H-Size: Adjusts the display width (horizontal size).
.H-Phase: Adjusts the horizontal position of the display
(left or right).
.V-Size: Adjusts the vertical display height (vertical
size).
.V-Center: Adjusts the vertical position of the display
(up or down).
.Pincushion: Controls the concave and convex curve at
the vertical edges of the display.
.Trapezoid: Controls the trapezoidal distortion on the top
6User’s Guide
or bottom of the display
The LED indicator goes off after 20 seconds of inactivity. If any settings
have changed, the monitor automatically saves the new settings.
Select
Press the or button to cycle through the adjustment options to
choose H-Phase, H-Size, V-Center, V-Size, Contrast, Brightness,
Trapezoid, and Pincushion. The corresponding LED indicator lights up
when selected. Use the Adjust buttons to change the settings.
Adjust
Adjusts the settings for H-Phase, H-Size, V-Center, V-Size, Contrast,
Brightness, Trapezoid, and Pincushion. Use the Select button to choose the
item to be adjusted and press or to change the setting.
Power Switch
Turns the monitor on (I) or off (O). The power switch is located at the base
of the monitor. The LED indicates the ON/OFF status of the unit.
Reset
Adjusts all settings to factory defaults.
User’s Guide 7
3. How To Adjust the Monitor
Press the Select key ( or ) to choose the item to be adjusted.
Press the Adjust key ( or ) to change the setting.
Repeat the above procedure to change other items.
The monitor automatically saves the new settings after 20 seconds of
inactivity.
In the event that display distortion is incurred due
to magnetic field interference, face the monitor to
the east for the best display quality.
4. Microcontroller Features
The microcontroller automatically detects the video board installed in your
system. When you turn on the monitor, the microcontroller first checks the
display mode memory stored in the user setting area of the video board, and
then the factory presetting area. It then adjusts to the proper display mode.
Display Modes Memory
The microcontroller has the memory capacity to store 32 different display
modes, including timing formats and display settings. This memory
capacity is divided into two parts: the user setting area and the factory
presetting area. The former can store 20 display modes. The latter can store
12 display modes and has already stored 9 display modes.
8User’s Guide
User Setting Area
The user setting area on the microcontroller maintains in its memory the last
20 display modes set by the user. You can change the settings, or add a
nonstandard mode. The microcontroller always detects and displays the last
mode stored in the user setting area first when the monitor is turned on.
Factory Presetting Area
There are 9 preferred display modes preset in the microcontroller. These
display modes are preset at the factory and include the most popular display
modes currently available (see the Specifications section). The
microcontroller searches for a proper display mode in this area if it fails to
find a proper display mode in the user setting area.
User’s Guide 9
5. Signal Connector Pinouts
To connect VGA, 8514A or IBM-compatible graphics adapters, use a 15-
pin mini D-type male connector.
15-Pin Mini D-Type Male Connector
Pin Assignment
1Red Video
2Green Video
3Blue Video
4Ground
5Ground
6Red Ground
7Green Ground
8Blue Ground
9No Connection
10 Sync Ground
11 Ground
12 Serial Data I/O
13 H. Sync
14 V. Sync
15 Serial Clock Input
10 User’s Guide
6. Power Saving Feature
This monitor’s power saving feature complies with these VESA power
saving modes:
Mode H.Sync V.Sync LED Power Consumption
Normal On On Green 90 w
Stand-by Off On Amber <15 w
Suspend On Off Amber <15 w
Off Off Off Amber
Blinking <5 w
The monitor uses the H.Sync and V.Sync signals to determine the operation
mode to enter.
The monitor power-saving feature automatically turns off H.Sync and
V.Sync if there is no input from the system for a certain period of time. To
use this feature, you need a green PC that is compliant with the VESA
power saving feature or a software utility to detect system input such as the
keyboard or mouse.
Time Settings
Time settings are adjusted from the system unit by software. To fulfill the
requirements in the NUTEK specification 803299/94 the total time from
indicated inactivity to Power Saving Position A2 (VESA Off) must not be
set to more than 70 minutes. We recommend you switch off the monitor
when you do not intend to use it for awhile.
