Acer AcerView 79g Manuel utilisateur
AcerView 79g
Color Monitor
17” (43.2cm) CRT Size,
16” (40.5cm) Max. Viewable Area
User’s Manual
ii
Copyright
Copyright © 1997 by Acer Peripherals, Incorporated. All rights reserved. No part of
this publication may be reproduced, transmitted, transcribed, stored in a retrieval
system or translated into any language or computer language, in any form or by any
means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise,
without the prior written permission of Acer Peripherals, Incorporated.
Disclaimer
Acer Peripherals, Incorporated makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically disclaims
any warranties, merchantability or fitness for any particular purpose. Further, Acer
Peripherals, Incorporated reserves the right to revise this publication and to make
changes from time to time in the contents hereof without obligation of Acer
Peripherals, Incorporated to notify any person of such revision or changes.
Fill in here!!
For the convenience of service, write following
related information of your monitor in the space
below. The serial number is on the back of the
product.
Monitor Information
Product Name: AcerView 79g
Serial Number:
Date of Purchase:
Dealer Information
Dealer:
Telephone
Number:
Address:
Acer is a registered trademark of Acer Incorporated. Other brands and product names and
trademarks or registered trademarks of their respective companies.
iii
Safety Instructions
The AC plug isolates this equipment from the AC supply.
Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Slots and openings in the cabinet and the back or bottom are provided for
ventilation. They must not be blocked or covered. This product should never be
placed near or over a radiator or heat register, or in a built-in installation unless
proper ventilation is provided.
This product should be operated from the type of power indicated on the
marking label. If you are not sure of the type of power available, consult your
dealer or local power company.
This product should be operated with a 3-wire grounding-type plug, a plug
having a third (grounding) pin. This plug will only fit into a grounding-type power
outlet. This is a safety feature. If you are unable to insert the plug into the
outlet, contact your electrician to make the necessary outlet changes.
Never push objects of any kind, or spill liquid of any kind into this product.
Do not attempt to service this product yourself, as opening or removing covers
may expose you to dangerous voltages or other risks. If any above mentioned
misuse or other accident (dropping, mis-operations) occurs, contact qualified
service personnel for servicing.
Use only the proper type of power supply cord set (provided in your PC box) for
this unit. It should be a detachable type: UL listed/CSA certified, type SVT/SJT,
VDE approved or its equivalent.
The power supply cord serves as a power disconnect device for pluggable
equipment. The socket outlet shall be installed near the equipment and shall be
easily accessible.
iv
FCC Class B
Radio Frequency Interference Statement
Note:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/television technician for help.
Notice:
The changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Caution:
If you find some parts of the monitor display discolored due to magnetic fields
generated by electrical facilities or appliances, turn off the monitor for at least 15
minutes. The degaussing circuit of the monitor will eliminate the discoloration.
Do not remove the monitor from its swivel base while the power is on to prevent
discoloration. If discoloration occurs, follow the above-mentioned procedure for
adjustment.
Shielded power cord and interface cable, if any, must be used in order to comply
with the emission limits of FCC Class B digital device.
v
CE Declaration
This monitor, AcerView 79g, complies with 72/23/EEC and 89/336/EEC modified by
92/31/ECC. These directives refer to EMC.
Canadian Department of Communications Regulatory Statement
This digital apparatus does not exceed Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
vi
Table of Contents
Table of Contents.........................................................................................vi
Chapter 1 Introduction.....................................................................................1-1
Unpacking the Package..............................................................................1-1
Features.....................................................................................................1-1
Power Management....................................................................................1-2
Chapter 2 Getting Started...............................................................................2-1
Installing the Swivel Base............................................................................2-1
Installing the Monitor...................................................................................2-2
Connecting the Signal Cable.......................................................................2-2
Connecting through D-SUB signal connector......................................2-2
Connecting through BNC signal connector .........................................2-3
Chapter 3 Adjusting the Monitor.....................................................................3-1
A Look at the Control Panel ........................................................................3-1
Adjusting the Monitor..................................................................................3-1
Panel key introduction:.......................................................................3-1
Selecting page and making adjustments.............................................3-2
Page 1 Display control..............................................................3-2
Page 2 Degaussing and Color Weighting ..................................3-3
Page 3 User Mode Display ......................................................3-4
Page 4 Convergence & Moire Adjustment .................................3-5
Page 5 Input Connector Select..................................................3-7
Timing Setting............................................................................................3-7
Reset to Defaults........................................................................................3-8
Factory Preset Timings...............................................................................3-9
Chapter 4 Troubleshooting and Useful Hints ................................................4-1
Troubleshooting..........................................................................................4-1
Maintenance...............................................................................................4-3
Need More Help? .......................................................................................4-3
Chapter 5 Specifications.................................................................................5-4
1-1Introduction
Introduction
Unpacking the Package
Check following items. If they are
missing or damaged, consult your place
of purchase immediately.
üColor monitor
üSwivel base
üUser’s manual
üPower cord
ü15-pin D-type signal cable
üBNC signal cable (optional)
Locate the model name and the serial
number labeled on the back of your monitor. Write down the related information of
your monitor and dealer in the space on page ii for future reference.
Features
Your AcerView 79g has the following features:
üAperture-grille tube
Applying aperture grille tube with 0.25mm aperture grille pitch and an anti-glare,
anti-static coating, AcerView 79g color monitors offer strikingly sharp and crisp
image quality.
üPlug’n Play Compatibility
With its DDC1and DDC2B, it is compatible with Plug’n Play feature of
Windows95.
1
1-2Introduction
üFlicker-free Image
The monitor supports high refresh rates up to VESA’s best recommendation.
üLarger Viewable Size
With its 16” viewable size, it offers a larger screen than other 17” monitors.
üiScreen (Intelligent Screen) Technology
The On-Screen Display (OSD) allows you to adjust all settings simply with on-
screen menus.
üPower Saving Function
The power management complies with VESA DPMS standard. When the system
is idle (off mode), the monitor automatically cuts its power consumption up to
95%.
üGreen Commitment
Your monitor is packaged in recycled packing materials and no CFCs are used
in the manufacturing process. It is in compliance with the US government’s
Energy Star standards and the rigorous standards of the Scandinavian
countries.
Power Management
The power management of this monitor complies with these VESA power saving
modes:
Mode Power
Consumption Horizontal
Sync Vertical
Sync LED
On Normal On On Green
Stand-by < 15 W Off On Amber
Suspend <15 W On Off Amber
Off <5 W Off Off Amber
Blinking
Override Normal Off Off Green
2-1Getting Started
Getting Started
Installing the Swivel Base
Place the monitor
on its side.
Locate the arrow
and the four slots
at the bottom of
the monitor.
As directed by
the arrow inscribed
on the swivel base,
insert the four pegs
on the base into the
slots at the bottom
of the monitor.
Push the swivel
base gently toward
the front of the
monitor until it is
locked.
Place the monitor
back to its normal
position.
2
2-2Getting Started
Installing the Monitor
This monitor is equipped with an autosensing power supply for voltage ranges
90~264V, AC 47~63Hz.. Please confirm the line voltage designation at the rear panel
of the monitor before connecting the machine.
Make sure that the system power is turned off.
Please refer to the instructions below to
connect the signal cable through D-SUB or
BNC.
Connect the power cord to the monitor and
attach it to power source.
Turn on the computer and the monitor.
Connecting the Signal Cable
Your AcerView 79g provides both D-SUB and BNC signal connectors. The D-SUB or
BNC signals can automatically be detected by its microprocessor.
Connecting through D-SUB signal
connector
Make sure that the system power is turned off.
Connect the computer end of the D-SUB cable to the
15-pin output connector on the video board of your
computer.
Connect the monitor end of the D-SUB cable to the D-
SUB receptacle on the back of the monitor.
