Acer Predator Triton 500 Manuel utilisateur

English

Model number: _________________________________________________

Serial number: _________________________________________________

Date of purchase: _____________________________________________

Place of purchase: _____________________________________________

ENVIRONMENT

Temperature:

Operating: 5 °C to 35 °C

Storage: -20 °C to 60 °C

Humidity (non-condensing):

Operating: 20% to 80%

Storage: 20% to 60%

WARNING! To reduce the possibility of heat-related injuries or of overheating the

computer, do not touch the heatsinks behind the computer vents at the rear side of the

computer, and do not place the computer on your lap or obstruct the air vents. Use the

computer on a hard, flat surface. Do not block the air flow with any hard surface, such

as adjoining printer, or with soft surface, such as pillows or rugs. Also, do not allow the

AC adapter to come into contact with the skin or a soft surface, such as pillows or

clothing, during operation.

Predator Triton 500

Covers: PT515-52

This revision: February 2020

This manual contains proprietary information that is protected by copyright

laws. The information contained in this manual is subject to change without

notice. Some features described in this manual may not be supported

depending on the Operating System version. Images provided herein are for

reference only and may contain information or features that do not apply to

your computer. Acer Group shall not be liable for technical or editorial errors

or omissions contained in this manual.

English

First things first

We would like to thank you for making this Predator notebook your

choice for meeting your mobile computing needs.

Your guides

To help you use your Predator notebook, we have designed a set of

guides:

First off, the Setup Guide helps you get started with setting up your

computer.

The Quick Guide introduces you to the basic features and functions of

your new computer.

For more on how your computer can help you to be more productive,

please refer to the Predator Triton 500 User’s Manual. The Predator

Triton 500 User’s Manual contains useful information applying to your

new computer. It covers basic topics such as using the keyboard and

audio, etc.

This guide contains detailed information on such subjects as system

utilities, data recovery, expansion options and troubleshooting. In addition

it contains warranty information and the general regulations and safety

notices for your notebook.

The User’s Manual can be downloaded from the Acer support website by

going to:

http://go.acer.com/?id=17883

Software installation

The first time you turn on your computer, it will automatically install

software and set up for use. This may take some time, please do not turn

off your computer; wait until the installation has finished.

Recovery

You should create recovery backups as soon as you can. The Acer

Recovery Management program allows you to create recovery backups

and then to restore or reinstall applications and drivers provided by Acer.

Having trouble?

Acer provides several options to support your purchase.

English

Acer support

Make sure you write down your computer serial number, date and place

of purchase and model name on the area provided in this guide; save your

proof of purchase. Before you call us, please write down any error

message that accompanies the problem, and have the computer in front of

you and switched on if possible. Having these items to hand when

contacting us will ensure better and quicker service.

Acer website

Remember to visit www.acer.com and refer to the support section for up-

to-date information, help, drivers and downloads.

Warranty and contact information

You can find information about the warranty for your computer and how

to contact technical support in your computer’s Warranty.

Your Predator notebook tour

English

Your Predator notebook tour

After setting up your computer as illustrated in the Setup Guide, let us

show you around your new Predator computer.

Screen view

#Icon Item Description

1 Microphones Internal stereo digital microphones for

sound recording.

2Webcam

Web camera for video communication.

A light next to the webcam indicates that

the webcam is active.

3 Screen Displays computer output.

English

Keyboard view

#Icon Item Description

1TURBO TURBO key Switches overclocking and fan speed level.

2 Backlit keyboard For entering data into your computer.

See "Using the keyboard" on page 9.

3 Touchpad Touch-sensitive pointing device.

4 PredatorSense key Launches PredatorSense application.

5 Power button Turns the computer on and off.

6Ventilation and

cooling fan

Allows the computer to stay cool.

Do not cover or obstruct the openings.

Your Predator notebook tour

English

Left view

USB 3.2 Gen 2 information

• USB 3.2 Gen 2 compatible ports are blue.

• Compatible with USB 3.2 Gen 2 and earlier devices.

• For optimal performance, use USB 3.2 Gen 2-certified devices.

• Defined by the USB 3.2 Gen 2 specification (SuperSpeed USB).

#Icon Item Description

1Ventilation and

cooling fan

Allows the computer to stay cool.

Do not cover or obstruct the openings.

2 DC-in jack Connects to an AC adapter.

3Ethernet (RJ-45)

port

Connects to an Ethernet 10/100/

1000Mbps/2.5Gbps-based network.

4USB port with

power-off charging Connects to USB devices.

5HDMIport

Supports high-definition digital video

connections.

6Mic-injack

Connects to an external microphone for

recording audio.

7Headset/speaker

jack

Connects to audio devices (e.g., speakers,

headphones)

21 3 4 5 6 7

English

Right view

USB Type-C information

• USB 3.2 Gen 2 with transfer speeds up to 10 Gbps.

• Supports DisplayPort™audio/video output.

• Compatible with Thunderbolt™3.

• Delivers up to 3 A at 5 V DC for USB charging.

#Icon Item Description

Battery indicator

Indicates the computer’s battery status.

Amber when the battery is charging.

Blue when fully charged (with the AC

adapter plugged in).

Power indicator Indicates the computer’s power status.

2USB Type-C /

Thunderbolt 3 port

Connects to USB devices with a USB Type-

C connector.

Supports Thunderbolt™3 and displays.

3 Mini DisplayPort Connects to an external display device.

4 USB port Connects to USB devices.

5Ventilation and

cooling fan

Allows the computer to stay cool.

Do not cover or obstruct the openings.

6Kensington lock

slot

Connects to a Kensington-compatible

security lock.

123654

Your Predator notebook tour

English

Rear view

Base view

#Icon Item Description

1Ventilation and

cooling fan

Allows the computer to stay cool.

Do not cover or obstruct the openings.

#Icon Item Description

1Ventilation and

cooling fan

Allows the computer to stay cool.

Do not cover or obstruct the openings.

2Battery reset

pinhole

Simulates removing and reinstalling the

battery.

Insert a paperclip into the hole and press

for four seconds.

English

Using the keyboard

The keyboard has full-sized keys, a numeric keypad, separate cursor, lock,

Windows keys and hotkeys.

Hotkeys

To activate hotkeys, press and hold the Fn key before pressing the other

key in the hotkey combination..

Hotkey Icon Function Description

Fn + F2 Touchpad toggle Turns the built-in touchpad on and off.

Fn + F3 Flight mode Turns on / off the computer's network

devices .

Fn + F4 Sleep Puts the computer in Sleep mode.

Fn + F5 Display toggle

Switches display output between the

display screen, external monitor (if

connected) and both.

Fn + F6 Display off

Turns the display screen backlight off

to save power. Press any key to

return.

Fn + F7

Keyboard

backlight

decrease

Decreases the intensity of the

keyboard backlight.

Fn + F8

Keyboard

backlight

increase

Increases the intensity of the

keyboard backlight.

Fn + F9 End End Scrolls to the end of a document.

Fn + F10 Home Home Scrolls to the beginning of a document.

Fn + F11 NumLk Numeric Lock Turns Numeric Lock on or off.

Fn + F12 Scr Lk Scroll Lock Turns Scroll Lock on or off.

Fn + Play/Pause Plays or pauses a selected media file.

Fn + Previous Returns to the previous media file.

Fn + Next Jumps to the next media file.

Fn + Pg Up Page up Scrolls the page up.

Fn + Pg Dn Page down Scrolls the page down.

Fn + Brightness up Increases the screen brightness.

Fn + Brightness down Decreases the screen brightness.
