Acer Aspire V5-123 Manuel utilisateur
Aspire V5-123
Quick Guide
Product registration
When using your product for the first time, it is recommended that you immediately
register it. This will give you access to some useful benefits, such as:
•Faster service from our trained representatives.
•Membership in the Acer community: receive promotions and participate in customer
surveys.
•The latest news from Acer.
Hurry and register, as other advantages await you!
How to register
To register your Acer product, please visit www.acer.com. Select your country, click
PRODUCT REGISTRATION and follow the simple instructions.
You will also be asked to register your product during the setup process, or you can
double-click the Registration icon on the desktop.
After we receive your product registration, you will be sent a confirmation email with
important data that you should keep in a safe place.
Obtaining Acer accessories
We are happy to inform you that Acer's warranty extension program and Notebook
accessories are available online. Come and visit our online shop and find what you need
at store.acer.com.
The Acer store is being progressively rolled out, and, unfortunately may not be available
in some regions. Please check back regularly to see when it will be available in your
country.
© 07/2013. All Rights Reserved.
Aspire V5-123
Quick Guide
This revision: July 2013
Model number:
Serial number:
Date of purchase:
Place of purchase:
ENVIRONMENT
Temperature:
- Operating: 5 °C to 35 °C
- Non-operating: -20 °C to 65 °C
Humidity (non-condensing):
- Operating: 20% to 80%
- Non-operating: 20% to 80%
3
English
First things first
We would like to thank you for making an Acer notebook your choice for
meeting your mobile computing needs.
Your guides
To help you use your Acer notebook, we have designed a set of guides:
First off, the Setup Poster helps you get started with setting up your
computer.
The Quick Guide introduces you to the basic features and functions of your
new computer.
For more on how your computer can help you to be more productive, please
refer to the User’s Manual. The User’s Manual contains useful information
applying to your new computer. It covers basic topics such as using the
keyboard and audio, etc.
This guide contains detailed information on such subjects as system utilities,
data recovery, expansion options and troubleshooting. In addition it contains
warranty information and the general regulations and safety notices for your
notebook.
Follow these steps to access it:
1 Type ‘User’ from Start.
2 Click on Acer User’s Manual.
Your Acer notebook tour
4
English
Your Acer notebook tour
After setting up your computer as illustrated in the setup poster, let us show
you around your new Acer computer.
Screen view
#Icon Item Description
1Webcam
Web camera for video communication.
A light next to the webcam indicates that the
webcam is active.
2Screen Displays computer output.
3
Power indicator Indicates the computer's power status.
Battery indicator
Indicates the computer's battery status.
Charging: The light is amber when the battery
is charging.
Fully charged: The light is blue when plugged
in.
Communication
indicator
Indicates the computer’s wireless connectivity
device status.
1
2
3
5
English
Keyboard view
Left view
#Icon Item Description
1Power button Turns the computer on and off.
2Keyboard For entering data into your computer.
See "Using the keyboard" on page 7.
3Touchpad Touch-sensitive pointing device which
functions like a computer mouse.
4Click buttons (left
and right)
The left and right side of the button function as
left and right selection buttons.
5Palmrest Comfortable support area for your hands when
you use the computer.
6Microphone Internal microphone for sound recording.
#Icon Item Description
1External display (VGA)
port
Connects to a display device (e.g., external
monitor, LCD projector).
2
1
3
4
5
6
2431
Your Acer notebook tour
6
English
Information on USB 3.0
• USB 3.0 compatible ports are blue.
• Compatible with USB 3.0 and earlier devices.
• For optimal performance, use USB 3.0-certified devices.
• Defined by the USB 3.0 specification (SuperSpeed USB).
Right view
2Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-based
network.
3HDMI port Supports high-definition digital video
connections.
4USB port Connects to USB devices.
#Icon Item Description
1SD card reader
Accepts one Secure Digital (SD or SDHC)
card.
Note: Push to remove/install the card.
2Headset/speaker jack
Connects to audio devices (e.g.,
speakers, headphones) or a headset with
microphone.
3USB ports Connect to USB devices.
4DC-in jack Connects to an AC adapter.
5
Kensington lock slot Connects to a Kensington-compatible
computer security lock.
Wrap the computer security lock cable
around an immovable object such as a
table or handle of a locked drawer.
Insert the lock into the notch and turn the
key to secure the lock.
Keyless models are also available.
#Icon Item Description
312 45
7
English
Information on USB 3.0
• USB 3.0 compatible ports are blue.
• Compatible with USB 3.0 and earlier devices.
• For optimal performance, use USB 3.0-certified devices.
• Defined by the USB 3.0 specification (SuperSpeed USB).
Base view
Note: For models with an AMD processor and a single memory module:
If you replace the memory module, the new module must go into the same
slot occupied by the module that was removed.
Using the keyboard
Your computer has a compact keyboard with an embedded numeric keypad.
The embedded numeric keypad functions like a desktop numeric keypad. It is
indicated by small characters located on the upper right corner of the keycaps.
#Icon Item Description
1Battery bay Houses the computer's battery pack.
2Speakers Deliver stereo audio output.
3Ventilation and cooling
fan
Allows the computer to stay cool.
Do not cover or obstruct the openings.
4Battery release latch Releases the battery for removal. Insert a
suitable tool and slide to release.
1
2
3
4
Using the keyboard
8
English
To simplify the keyboard legend, cursor-control key symbols are not printed on
the keys.
Hotkeys
The computer employs hotkeys or key combinations to access most of the
computer's controls like screen brightness and volume output.
To activate hotkeys, press and hold the <Fn> key before pressing the
other key in the hotkey combination.
Desired access Num Lock on Num Lock off
Number keys on
embedded keypad
Type numbers in a normal
manner.
Cursor-control keys on
embedded keypad
Hold <Shift>while using cursor-
control keys.
Hold <Fn> while using
cursor-control keys.
Main keyboard keys Hold <Fn> while typing letters
on embedded keypad.
Type the letters in a
normal manner.
Hotkey Icon Function Description
<Fn> + <F3> Airplane mode
Turns on / off the computer's network
devices.
(Network devices vary by
configuration.)
<Fn> + <F4> Sleep Puts the computer in Sleep mode.
<Fn> + <F5> Display toggle
Switches display output between the
display screen, external monitor (if
connected) and both.
<Fn> + <F6> Display off
Turns the display screen backlight
off to save power. Press any key to
return.
<Fn> + <F7> Touchpad toggle Turns the built-in touchpad on and
off.
<Fn> + <F8> Speaker toggle Turns the speakers on and off.
<Fn> + <F11> NumLk Number Lock Turns the embedded numeric
keypad on or off.
<Fn> + <F12> Scr Lk Scroll Lock Turns Scroll Lock on or off.
<Fn> + < > Brightness up Increases the screen brightness.
<Fn> + < > Brightness down Decreases the screen brightness.
9
English
<Fn> + < > Volume up Increases the sound volume.
<Fn> + < > Volume down Decreases the sound volume.
Hotkey Icon Function Description
Ver.: 01.01.03
