Acer Aspire Notebook Series Manuel utilisateur
Aspire Notebook Series
Quick Guide
Acer recommends...
Productivity Software
Work Great with Microsoft
®
Office 2010
- Express your ideas, solve problems and simplify everyday projects
with Office 2010.
Photo editing
- Easily edit and print your photos with Windows Live Photo Gallery. Then share them on
Facebook, YouTube or Windows Live.
Search & Decide with Bing
-- Find and organize the answers you need using Bing™, so you can make faster,
more informed decisions.
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
© 2011. All Rights Reserved.
Aspire Notebook Series Quick Guide
Original Issue: 03/2011
3
First things first
We would like to thank you for making an Acer notebook your choice for
meeting your mobile computing needs.
Your guides
To help you use your Acer notebook, we have designed a set of guides:
First off, the setup poster helps you get started with setting up your computer.
The Aspire Generic User Guide contains useful information applying to all
models in the Aspire product series. It covers basic topics such as using the
keyboard and audio, etc. Please understand that due to its nature, the Generic
User Guide will occasionally refer to functions or features which are only
contained in certain models of the series, but not necessarily in the model you
purchased. Such instances are marked in the text with language such as "only
for certain models".
The Quick Guide introduces you to the basic features and functions of your new
computer. For more on how your computer can help you to be more productive,
please refer to the Aspire Generic User Guide. This guide contains detailed
information on such subjects as system utilities, data recovery, expansion
options and troubleshooting. In addition it contains warranty information and
the general regulations and safety notices for your notebook. It is available in
Portable Document Format (PDF) and comes preloaded on your notebook.
Follow these steps to access it:
1 Click on Start > All Programs > AcerSystem.
2 Click on Aspire Generic User Guide.
Note: Viewing the file requires Adobe Reader. If Adobe Reader is not
installed on your computer, clicking on Aspire Generic User Guide will run
the Adobe Reader setup program first. Follow the instructions on the screen
to complete the installation. For instructions on how to use Adobe Reader,
access the Help and Support menu.
4
English
Your Acer notebook tour
After setting up your computer as illustrated in the setup poster, let us show
you around your new Acer notebook.
Top view
#Icon Item Description
1 Integrated webcam Web camera for video communication.
2 Display screen Also called Liquid-Crystal Display (LCD),
displays computer output (configuration
may vary by model).
1
3
2
4
5
6
7
8
9
10
5
English
Hotkeys
The computer employs hotkeys or key combinations to access most of the
computer's controls like screen brightness and volume output.
To activate hotkeys, press and hold the <Fn> key before pressing the other key
in the hotkey combination.
3 Power button /
indicator
Turns the computer on and off. Indicates
the computer's power status.
4 Keyboard For entering data into your computer.
5 Touchpad Touch-sensitive pointing device which
functions like a computer mouse.
6 Click buttons (left
and right)
The left and right buttons function like
the left and right mouse buttons.
7 NumLk indicator Lights up when Num Lock is activated.
Caps Lock indicator Lights up when Caps Lock is activated.
8PAcer PowerSmart
button
Puts your computer into power-saving
mode (configuration may vary by model).
P key Programmable key (configuration may
vary by model).
9 Speakers Deliver stereo audio output.
10 Microphone Internal microphone for sound recording.
Hotkey Icon Function Description
<Fn> + <F3> Communication Enables/disables the computer’s
communication devices.
<Fn> + <F4> Sleep Puts the computer in Sleep mode.
<Fn> + <F5> Display toggle Switches display output between
the display screen, external
monitor (if connected) and both.
<Fn> + <F6> Screen blank Turns the display screen backlight
off to save power. Press any key to
return.
<Fn> + <F7> Touchpad
toggle
Turns the internal touchpad on
and off.
#Icon Item Description
6
English
<Fn> + <F8> Speaker toggle Turns the speakers on and off.
<Fn> + < > Brightness up Increases the screen brightness.
<Fn> + < > Brightness down Decreases the screen brightness.
<Fn> + < > Volume up Increases the sound volume.
<Fn> + < > Volume down Decreases the sound volume.
<Fn> +
<Home>
Play/Pause Play or pause a selected media file.
<Fn> +
<Pg Up>
Stop Stop playing the selected media
file.
<Fn> +
<Pg Dn>
Previous Return to the previous media file.
<Fn> + <End> Next Jump to the next media file.
Hotkey Icon Function Description
7
English
Closed front view
#Icon Item Description
1 Battery indicator
button
Press to indicate the computer's battery
status.
Note: Also functions
when the computer
is turned off.
When plugged in:
Blue: Fully charged
Amber: Charging
When on battery power:
Blue: >30% battery charge remaining
Amber: Remaining charge is between
10% and 30%
Red: <10% charge remaining
2 Power indicator Indicates the computer's power status.
HDD indicator Indicates when the hard disk drive is
active.
Communication
indicator
Indicates the computer’s wireless
connectivity device status.
3 SIM card slot Accepts a 3G SIM card (configuration may
vary by model).
4Multi-in-1card
reader
Accepts Secure Digital (SD),
MultiMediaCard (MMC), Memory Stick
PRO (MS PRO), xD-Picture Card (xD).
Note: Push to remove/install the card.
Only one card can operate at any time.
12 34
8
English
Left view
Information on USB 3.0
•Supports power-off USB charging, allowing you to charge supported
mobile devices while the notebook is switched off.
•Defined by the USB 3.0 (SuperSpeed USB) specification.
•Devices without USB 3.0 certification may not be compatible.
#Icon Item Description
1 DC-in jack Connects to an AC adapter.
2 External display
(VGA) port
Connects to a display device (e.g.,
external monitor, LCD projector).
3 HDMI port Supports high-definition digital video
connections.
4 USB 2.0 port Connects to USB 2.0 devices (e.g., USB
mouse, USB camera).
5 USB 3.0 port Connects to USB devices.
A USB 3.0 port can be distinguished by its
blue connector.
23145
9
English
Right view
#Icon Item Description
1 Microphone jack Accepts inputs from external
microphones.
Headphones/speaker
jack
Connects to audio devices (e.g., speakers,
headphones).
2 USB 2.0 port Connects to USB 2.0 devices (e.g., USB
mouse, USB camera).
3 Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-
based network.
4 Kensington lock slot Connects to a Kensington-compatible
computer security lock.
Note: Wrap the computer security lock
cable around an immovable object such
as a table or handle of a locked drawer.
Insert the lock into the notch and turn
the key to secure the lock. Some keyless
models are also available.
2134
10
English
Base view
Environment
#Icon Item Description
1 Battery reset pinhole Insert a paperclip into the hole to reset
the computer (simulates removing and
reinstalling the battery).
2 SIM card slot Accepts a 3G SIM card (configuration may
vary by model).
•Temperature:
•Operating: 5°C to 35°C
•Non-operating: -20°C to 65°C
•Humidity (non-condensing):
•Operating: 20% to 80%
•Non-operating: 20% to 80%
1
2
