Acer Aspire Notebook Series Manuel utilisateur

Aspire Notebook Series Quick Guide

Acer recommends...

Productivity software

Work Great with Microsoft

Office 2010

- Express your ideas, solve problems and simplify

everyday projects with Office 2010.

Photo editing

- Easily edit and print your photos with Windows Live Photo Gallery. Then share

them on Facebook, YouTube™ or Windows Live.

Search & Decide with Bing™

- Find and organize the answers you need using Bing™, so you

can make faster, more informed decisions.

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

Aspire Notebook Series Quick Guide

Original Issue: 03/2011

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the setup poster helps you get started with setting up your computer.

The Aspire Series Generic User Guide contains useful information applying to all

models in the Aspire product series. It covers basic topics such as using the

keyboard and audio, etc. Please understand that due to its nature, the Generic

User Guide as well as the AcerSystem User Guide mentioned below will

occasionally refer to functions or features which are only contained in certain

models of the series, but not necessarily in the model you purchased. Such

instances are marked in the text with language such as "only for certain

models".

The Quick Guide introduces you to the basic features and functions of your new

computer. For more on how your computer can help you to be more productive,

please refer to the AcerSystem User Guide. This guide contains detailed

information on such subjects as system utilities, data recovery, expansion

options and troubleshooting. In addition it contains warranty information and

the general regulations and safety notices for your notebook. It is available in

Portable Document Format (PDF) and comes preloaded on your notebook.

Follow these steps to access it:

1 Click on Start > All Programs > AcerSystem.

2 Click on AcerSystem User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not

installed on your computer, clicking on AcerSystem User Guide will run the

Adobe Reader setup program first. Follow the instructions on the screen to

complete the installation. For instructions on how to use Adobe Reader,

access the Help and Support menu.

English

Your Acer notebook tour

After setting up your computer as illustrated in the setup poster, let us show

you around your new Acer notebook.

Top view

#Icon Item Description

1 Acer Crystal Eye

webcam Web camera for video communication.

(only for certain models)

2 Display screen Also called Liquid-Crystal Display (LCD),

displays computer output (configuration

may vary by models).

English

1. The front panel indicators are visible even when the computer cover is closed.

3 P P key / Acer

PowerSmart key Programmable key (configuration may

vary by model). / Puts your computer into

power-saving mode (configuration may

vary by model).

Arcade key Starts InstantOn Arcade without booting.

Starts clear.fi in Windows.

Keyboard

backlight Turns the keyboard backlight on or off.

4 Keyboard For entering data into your computer.

5Acer

MediaRemote

(detachable

touchpad with

media console)

Touch-sensitive pointing device which

functions like a computer mouse*.

Touch sensitive controls for Acer clear.fi,

volume (up, down) and media (play/

pause, previous, next, stop).

* Touchpad becomes inactive when

media console is active.

61Communication

key Enables/disables the computer’s

communication devices (communication

devices may vary by configuration.)

HDD indicator Indicates when the hard disk drive is

active.

Battery indicator Indicates the computer’s battery status.

Charging: The light shows amber when

the battery is charging.

Fully charged: The light shows blue when

in AC mode.

Power indicator1Indicates the computer’s power status.

7 Click buttons (left

and right) The left and right buttons select items or

display menus.

8AcerBio-

Protection

fingerprint reader

Supports Acer FingerNav 4-way control

function (only for certain models).

9 Speakers Deliver stereo audio output.

10 Power button Turns the computer on and off.

11 Microphone Internal microphone for sound recording.

#Icon Item Description

English

Acer MediaRemote

The detachable touchpad features a media console that allows you to control

Acer clear.fi and Windows Media Player.

To detach the touchpad, slide the touchpad release latch and lift the

MediaRemote from the touchpad dock.

Important: The MediaRemote uses magnets to hold it in the

touchpad dock. If the MediaRemote has been removed from the

dock, do not place it on or near the computer, where it may

damage internal components.

Using the MediaRemote as a touchpad

While the MediaRemote is in touchpad mode, the area

indicated with a gray square controls cursor movements.

Slide your finger accross this surface to control cursor

movements and tap the surface twice to make a

selection.

Preparing the MediaRemote for use

Before using the MediaRemote as a detachable device, ensure the battery is

fully charged. The MediaRemote is already paired with your computer.

Status light

The status light (just above the Touchpad Mode button) indicates connection

and battery status.

Light Description

No light The MediaRemote has not been used for 15

minutes and is in sleep mode.

Blue The MediaRemote is active and attached to the

computer.

Blue flash The MediaRemote is active and not attached to

the computer.

English

Touchpad commands

The function of the touchpad varies, depending on the current setting.

Note: The Touchpad mode key is illuminated while the

MediaRemote touchpad surface is active.

clear.fi shortcuts

If the clear.fi shortcuts are active, you can easily open the media sections of

clear.fi. the blank area of the touchpad can still be used as a pointing device.

Slow orange flash Battery power is low (less than 40%).

Quick orange flash Battery power is very low (less than 20%).

Charging The light shows amber when the battery is

charging.

Fully charged The light shows blue.

Icon Item Description

Touchpad mode Change the function of the touchpad

surface:

Press once to activate clear.fi shortcuts.

Press again to activate the media console.

Press and hold to turn the MediaRemote

on or off.

Icon Item Description

Select Press to toggle between clear.fi sections:

Photo, Video and Music.

Main menu Open the main menu in clear.fi.

Video Open the Video section of clear.fi.

Music Open the Music section of clear.fi.

Light Description

English

Media console

Press the Touchpad Mode button again to activate the media console.

Note: If you play a file when using clear.fi, the media console will

turn on automatically. It will turn off when you press the

touchpad mode button.

G-sensor

While the MediaRemote is detached, you may rotate it from the

usual landscape orientation and use the touchpad in portrait

mode.

An internal g-sensor will change the orientation of the touchpad

controls.

If the touchpad controls do not match the orientation of the

MediaRemote, tilt the MediaRemote towards you (at least 30º)

for a couple of seconds.

Pairing the MediaRemote

If the MediaRemote is fully charged but does not work correctly with your

computer, you should pair the devices.

•Turn off the MediaRemote (press the mode button for three seconds).

•Press and hold the left and right click buttons for at least three seconds.

•Press the left click button key once.

•Press the mode button on the touchpad.

•The status light will flash to confirm the pairing was successful.

Icon Item Description

Previous Return to the previous media file.

Play/pause Play or pause a selected media file.

Next Jump to the next media file.

Reduce volume Reduce the media playback volume.

Increase volume Increase the media playback volume.

Stop Stop playback of the selected media file.

English

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the other key

in the hotkey combination.

Hotkey Icon Function Description

<Fn> + <F3> Communication

key Enables/disables the computer’s

communication devices (devices may

vary by configuration.)

<Fn> + <F4> Sleep Puts the computer in Sleep mode.

<Fn> + <F5> Display toggle Switches display output between the

display screen, external monitor (if

connected) and both.

<Fn> + <F6> Screen blank Turns the display screen backlight off

to save power. Press any key to

return.

<Fn> + <F7> Touchpad

toggle Turns the internal touchpad on and

off.

<Fn> + <F8> Speaker toggle Turns the speakers on or off.

<Fn> + <F9> Keyboard

backlight Turns the keyboard backlight on and

off.

<Fn> + < > Brightness up Increases the screen brightness.

<Fn> + < > Brightness

down Decreases the screen brightness.

<Fn> + < > Volume up Increases the volume.

<Fn> + < > Volume down Decreases the volume.

<Fn> +

<Home> Play/Pause Play or pause a selected media file.

<Fn> +

<Pg Up> Stop Stop playing the selected media file.

<Fn> +

<Pg Dn> Previous Return to the previous media file.

<Fn> +

<End> Next Jump to the next media file.

English

Closed front view

Left view

#Icon Item Description

1 Communication key Enables/disables the computer’s

communication devices.

(Communication devices may vary by

configuration.)

2 Multi-in-1 card reader Accepts Secure Digital (SD),

MultiMediaCard (MMC), Memory

Stick (MS), Memory Stick PRO (MS

PRO), xD-Picture Card (xD).

Note: Push to remove/install the

card. Only one card can operate at

any given time.

3 Touchpad release latch Lifts the touchpad and allows it to

be removed.

#Icon Item Description

1 DC-in jack Connects to an AC adapter.

2 Ventilation slots Enable the computer to stay cool,

even after prolonged use.

3 External display

(VGA) port Connects to a display device (e.g.,

external monitor, LCD projector).

4 HDMI port Supports high definition digital

video connections.

5 USB 2.0 / 3.0 port Connects to USB devices.

A USB 3.0 port can be distinguished

by its blue connector.

12 3

4512 3 678

Autres manuels pour Aspire Notebook Series

Table des matières

Autres manuels Acer Ordinateur portable

Acer

Acer 5710 6013 - TravelMate Guide de configuration

Acer

Acer Aspire V5-551 Manuel utilisateur

Acer

Acer TravelMate 2310 Guide de configuration

Acer

Acer ConceptD 7 Pro Manuel utilisateur

Acer

Acer TravelMate 4530 Series Manuel utilisateur

Acer

Acer ASPIRE 5251 Manuel utilisateur

Acer

Acer Aspire 1710 Series Guide de configuration

Acer

Acer TravelMate 220 series Manuel utilisateur

Acer

Acer TravelMate 3280 Manuel utilisateur

Acer

Acer A515-56-36UT Manuel utilisateur

Acer

Acer TravelMate -550 Manuel utilisateur

Acer

Acer Aspire 4315 Manuel utilisateur

Acer

Acer TravelMate 2420 Guide de configuration

Acer

Acer TravelMate 2000 Manuel utilisateur

Acer

Acer TravelMate 6594 Guide de démarrage rapide

Acer

Acer Extensa 710 Manuel utilisateur

Acer

Acer TravelMate 3010 Manuel utilisateur

Acer

Acer A315-59-59XB Manuel utilisateur

Acer

Acer Extensa 5630 Series Manuel utilisateur

Acer

Acer Aspire 7551 Manuel utilisateur

Acer

Acer TravelMate 4400 Manuel utilisateur

Acer

Acer Aspire 9920G Series Manuel utilisateur

Acer

Acer Aspire 1650 Series Manuel utilisateur

Acer

Acer Aspire 2010 Manuel utilisateur

Manuels Ordinateur portable populaires d'autres marques

HP ze2401xt - Pavilion Notebook PC Manuel utilisateur

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Dell

Dell Alienware 17 R2 Manuel utilisateur

Toshiba

Toshiba A105-S2236 Manuel utilisateur

HP ENVY 17 Manuel

Winbook

Winbook LM Manuel utilisateur

Dell

Dell Inspiron 1464 Manuel utilisateur

Dell

Dell Inspiron 15R 5537 Manuel utilisateur

HP PROBOOK 4520S Manuel

Dell

Dell Latitude ATG D620 Manuel utilisateur

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Dell

Dell Latitude 7310 Manuel utilisateur

Dell

Dell Precision GU806 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

HP Compaq tc4200 Guide de démarrage rapide

Toshiba

Toshiba mini NB300 Manuel utilisateur

Lenovo

Lenovo ThinkPad X201 Tablet Manuel
