Acer Aspire M5-583P Manuel utilisateur

Aspire M5-583P

Quick Guide

Product registration

When using your product for the first time, it is recommended that you immediately

•Faster service from our trained representatives.

•Membership in the Acer community: receive promotions and participate in customer

surveys.

•The latest news from Acer.

Hurry and register, as other advantages await you!

How to register

To register your Acer product, please visit www.acer.com. Select your country, click

PRODUCT REGISTRATION and follow the simple instructions.

You will also be asked to register your product during the setup process, or you can

double-click the Registration icon on the desktop.

After we receive your product registration, you will be sent a confirmation email with

important data that you should keep in a safe place.

Obtaining Acer accessories

We are happy to inform you that Acer's warranty extension program and Notebook

accessories are available online. Come and visit our online shop and find what you need

at store.acer.com.

The Acer store is being progressively rolled out, and, unfortunately may not be available

in some regions. Please check back regularly to see when it will be available in your

country.

Aspire M5-583P

Quick Guide

This revision: 29 April 2013

Model number:

Serial number:

Date of purchase:

Place of purchase:

ENVIRONMENT

Temperature:

- Operating: 5 °C to 35 °C

- Non-operating: -20 °C to 65 °C

Humidity (non-condensing):

- Operating: 20% to 80%

- Non-operating: 20% to 80%

_________________________________

________________________________

____________________________

__________________________

English

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the Setup Guide helps you get started with setting up your computer.

The Quick Guide introduces you to the basic features and functions of your

new computer.

For more on how your computer can help you to be more productive, please

refer to the Aspire M5-583P User’s Manual. The Aspire M5-583P User’s

Manual contains useful information applying to your new computer. It covers

basic topics such as using the keyboard and audio, etc.

This guide contains detailed information on such subjects as system utilities,

data recovery, expansion options and troubleshooting. In addition it contains

warranty information and the general regulations and safety notices for your

notebook.

Follow these steps to access it:

1 Type ‘User’ from Start.

2 Click on Acer User’s Manual.

Your Acer notebook tour

English

Your Acer notebook tour

After setting up your computer as illustrated in the Setup Guide, let us show

you around your new Acer computer.

Screen view

#Icon Item Description

1 Webcam

Web camera for video communication.

A light next to the webcam indicates that the

webcam is active.

2 Touchscreen Displays computer output, supports multi-

touch input.

3 Microphones Internal stereo microphones for sound

recording.

Keyboard view

#Icon Item Description

Power indicator Indicates the computer’s power status.

Battery indicator

Indicates battery status.

Charging: The light is amber when the battery

is charging.

Fully charged: The light is blue.

2 Keyboard

For entering data into your computer.

See "Using the keyboard" on page 8.

Caution: Do not use a keyboard protector or

similar cover as the keyboard includes

ventilation intakes for cooling.

3 Touchpad

Touch-sensitive pointing device.

The touchpad and selection buttons form a

single surface.

Press down firmly on the touchpad surface to

perform a left click.

Press down firmly on the lower right corner to

perform a right click.

English

Your Acer notebook tour

English

Left view

#Icon Item Description

1USB port Connects to USB devices.

2Power button Turns the computer on and off.

Right view

#Icon Item Description

1Headset/speaker jack

Connects to audio devices (e.g.,

speakers, headphones) or a headset with

microphone.

2SD card reader

Accepts one Secure Digital card (SD or

SDHC).

Note: To remove the card, simply pull it

from the slot.

Warning: The card sticks out from the

side of the computer. Ensure you don’t

damage your card.

3USB port Connects to USB devices.

Rear view

#Icon Item Description

1Ventilation and cooling

fan

Allows the computer to stay cool.

Do not cover or obstruct the openings.

2Ethernet (RJ-45) port

Connects to an Ethernet 10/100/1000-

based network.

Note: Pull the lip down to open the port

fully.

3USB port with power-

off charging Connects to USB devices.

4Acer Converter Port

Connects to the Acer Converter cable,

allowing for easy connection to a LAN, an

external display or an additional USB

device.

Note: There are different cables available.

Please check with your retailer to see

which are compatible with your computer.

5HDMI port Supports high-definition digital video

connections.

Kensington lock slot Connects to a Kensington-compatible

computer security lock.

Wrap the computer security lock cable

around an immovable object such as a

table or handle of a locked drawer.

Insert the lock into the notch and turn the

key to secure the lock.

Keyless models are also available.

7DC-in jack Connects to an AC adapter.

Information on USB 3.0

• USB 3.0 compatible ports are blue.

• Compatible with USB 3.0 and earlier devices.

• For optimal performance, use USB 3.0-certified devices.

• Defined by the USB 3.0 specification (SuperSpeed USB).

English

Using the keyboard

Base view

#Icon Item Description

1Ventilation and cooling

fan

Allows the computer to stay cool.

Do not cover or obstruct the openings.

2Battery reset pinhole

Insert a paperclip into the hole and press for

four seconds to reset the computer (simulates

removing and reinstalling the battery).

3 Speakers Deliver stereo audio output.

Using the keyboard

The keyboard has full-sized keys and an embedded numeric keypad, separate

cursor, lock, Windows, function and special keys.

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

English

To activate hotkeys, press and hold the <Fn> key before pressing the other

key in the hotkey combination.

Hotkey Icon Function Description

<Fn> + <F3> Airplane mode

Enables / disables the computer's

communication devices.

(Communication devices may vary

by configuration.)

<Fn> + <F4> Sleep Puts the computer in Sleep mode.

<Fn> + <F5> Display toggle

Switches display output between the

display screen, external monitor (if

connected) and both.

<Fn> + <F6> Display off

Turns the display screen backlight off

to save power. Press any key to

return.

<Fn> + <F7> Touchpad toggle Turns the built-in touchpad on and

off.

<Fn> + <F8> Speaker toggle Turns the speakers on and off.

<Fn> + <F9> Keyboard backlight

Turns the keyboard backlight on and

off.

Note: This feature is only available

on certain models.

<Fn> + < > Brightness up Increases the screen brightness.

<Fn> + < > Brightness down Decreases the screen brightness.

<Fn> + < > Volume up Increases the sound volume.

<Fn> + < > Volume down Decreases the sound volume.

<Fn> + <Home> Play/Pause Play or pause a selected media file.

<Fn> +

<Pg Up>Stop Stop playing the selected

media file.

<Fn> +

<Pg Dn>Previous Return to the previous media file.

<Fn> + <End> Next Jump to the next media file.

English

Ver.: 01.01.03

Declaration of Conformity

We,

Acer Incorporated

8F, 88, Sec. 1, Xintai 5th Rd., Xizhi, New Taipei City 221, Taiwan

Contact Person: Mr. RU Jan, e-mail:[email protected]

And,

Acer Italy s.r.l

Via Lepetit, 40, 20020 Lainate (MI) Italy

Tel: +39-02-939-921 ,Fax: +39-02 9399-2913

www.acer.it

Declare under our own responsibility that the product:

Product: Notebook Computer

Trade Name: Acer

Model Number: ZRQ

SKU Number: Aspire M5********;

(* is “0-9”, “a-z”, “A-Z”, “-“, or blank)

To which this declaration refers conforms to the relevant standard or other standardizing documents:

•EN55022:2006/A1:2007 Class B; EN55024:2010

•EN301 489-1 V1.9.2; EN301 489-3 V1.4.1; EN301 489-17 V2.1.1

•EN300 328 V1.7.1

•EN301 893 V1.6.1

•EN62311:2008; EN62209-2:2010

•EN50371:2002

•EN61000-3-2:2006+A1:2009+A2:2009, Class D

•EN61000-3-3:2008

•EN60950-1:2006/A11:2009/A1:2010+A12:2011

•Regulation (EC) No. 1275/ 2008; EN 62301:2005

•EN50581:2012

We hereby declare above product is in compliance with the essential requirements and other

relevant provisions of EMC Directive 2004/108/EC, Low Voltage Directive 2006/95/EC, R&TTE

Directive 1999/5/EC and RoHS Directive 2011/65/EU and Directive 2009/125/EC with regard to

establishing a framework for the setting of ecodesign requirements for energy-related product.

Year to begin affixing CE marking 2013.

Apr. 29, 2013

Acer Incorporated

8F, 88, Sec. 1, Xintai 5th Rd., Xizhi

New Taipei City 221, Taiwan

Acer Incorporated

8F, 88, Sec. 1, Xintai 5th Rd., Xizhi

New Taipei City 221, Taiwan

RU Jan / Sr. Manager Date

Regulation, Acer Inc.
