Acer Aspire 9800 Manuel utilisateur

Aspire 9800 Series

Service Guide

PRINTED IN TAIWAN

Service guide files and updates are available

on the ACER/CSD web; for more information,

please refer to http://csd.acer.com.tw

Revision History

Please refer to the table below for the updates made on Aspire 9800 service guide.

Date Chapter Updates

III

transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in

any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without

the prior written permission of Acer Incorporated.

Disclaimer

The information in this guide is subject to change without notice.

Acer Incorporated makes no representations or warranties, either expressed or implied, with respect to the

contents hereof and specifically disclaims any warranties of merchantability or fitness for any particular

purpose. Any Acer Incorporated software described in this manual is sold or licensed "as is". Should the

programs prove defective following their purchase, the buyer (and not Acer Incorporated, its distributor, or its

dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential

damages resulting from any defect in the software.

Acer is a registered trademark of Acer Corporation.

Intel is a registered trademark of Intel Corporation.

Pentium and Pentium II/III are trademarks of Intel Corporation.

Other brand and product names are trademarks and/or registered trademarks of their respective holders.

Conventions

The following conventions are used in this manual:

SCREEN MESSAGES Denotes actual messages that appear

on screen.

NOTE Gives bits and pieces of additional

information related to the current

topic.

WARNING Alerts you to any damage that might

result from doing or not doing specific

actions.

CAUTION Gives precautionary measures to

avoid possible hardware or software

problems.

IMPORTANT Reminds you to do specific actions

relevant to the accomplishment of

procedures.

Preface

Before using this information and the product it supports, please read the following general information.

1. This Service Guide provides you with all technical information relating to the BASIC CONFIGURATION

decided for Acer's "global" product offering. To better fit local market requirements and enhance product

competitiveness, your regional office MAY have decided to extend the functionality of a machine (e.g.

add-on card, modem, or extra memory capability). These LOCALIZED FEATURES will NOT be covered

in this generic service guide. In such cases, please contact your regional offices or the responsible

personnel/channel to provide you with further technical details.

2. Please note WHEN ORDERING FRU PARTS, that you should check the most up-to-date information

available on your regional web or channel. If, for whatever reason, a part number change is made, it will

not be noted in the printed Service Guide. For ACER-AUTHORIZED SERVICE PROVIDERS, your Acer

office may have a DIFFERENT part number code to those given in the FRU list of this printed Service

Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and

service of customer machines.

Chapter 1 1

Features

Below is a brief summary of the computer’s many feature:

Operating system

TGenuine Windowsl®VistaTM Capable

TGenuine Windowsl®XP Home Edition (Service Pack 2)

TGenuine Windowsl®XP Media Center Edition 2005 (Rollup 2)

NOTE: Windowsl®VistaTM Capable PCs come with Windows®XP installed, and can be upgraded to

Windows®VistaTM. For more information on Windows®VistaTM and how to upgrade, go to:

Microsoft.com/windowsvista.

Platform and memroy

TIntel®Centrino®Duo mobile technology, featuring:

tIntel®CoreTM Duo processor T2300/T2400/T2500/T2600 (2 MB L2 cache, 1.66/1.83/2/2.16 GHz, 667 MHz

FSB) or higher

tIntel®945PM Express chipset

TIntegrated Intel®PRO/Wireless 3945ABG network connection (dual-band tri-mode 802.11a/b/g)

Wi-Fi CERTIFIEDTM solution, supporting Acer SignalUpTM wireless technology

TCore logic: Intel®945PM+ICH7M (north bridge+ south bridge)

TUp to 2GB of DDR2 677 MHz memory, upgradeable to 4GB using two soDIMM moules (dual-

channel support)

Display and graphics

T20.1” WSXGA+ high-brightness Acer CrystalBriteTM TFT LCD, 1680 x 1050 pixel resolution, 6

lamps

T19” WXGA+ high-brightness Acer CrystalBriteTM TFT LCD, 1440 x 900 pixel resolution, 4 lamps

T16 ms typical of/off and 8 ms average gray-to-gray response time

TSimultaneous multi-window viewing via Acer VistaTM supported

TNVIDIA®GeForce®Go 7600 with up to 512MB TurboCacheTM (256 MB of dedicated GDDR2

VRAM and up to 256 MB of shared system memory) or,

TNVIDIA®GeForce®Go 7300 with up to 256MB TurboCacheTM (128 MB of dedicated GDDR2

VRAM and up to 128 MB of shared system memory)

TSupporting NVIDIA®PureVideoTM technology (WMV HD, High-Definition MPEG-2 Hardware

Acceleration, integrated HDTV encoder) dual-link DVI, Microsoft®DirectX®9.0, Shader Model 3.0,

OpenEXR Hight Dynamic Range (HDR) technology, NVIDIA®PowerMizerTM 6.0 and PCI

Express®

TDual independent display

T16.7 million colors (20.1” LCD model)

T16.2 million colors (19” LCD model)

TMPEG-2/DVD hardware-assisted capability

TS-video/TV-out (NTSC/PAL) support

System Specifications

Chapter 1

2Chapter 1

TDVI-D (ture digital video interface) with HDCP (High-bandwidth Digital Content Protection) support

TAcer ArcadeTM featuring Acer CinemaVisionTM and Acer ClearVision technologies

TV-tuner

TAcer TV-tunver options:

tAnalog TV-tuner supporting hardware MPEG-2 stream encding

tDigital and analog hybrid TV-tuner supporting hardware MPEG-2 stream encoding

tDigital and analog hybrid TV-tuner supporting software MPEG-2 stream encoding

TAnalog TV-tuner supporting international analog TV standards (NTSC/PAL/SECAM)

TDigital TV-tuner supporting DVB-T (Digital Video Broadcasting Terrestrial) standard (6 MHz to

8MHz)

TTV-tuner I/O:

tRF jack for digital/analog TV antenna cable input

tAV-in port for composite/S-video/line-in audio/video input

TTV-tuner cables:

tPAL cable for digital/analog TV input, PAL/SECAM to NTSC port converter

tMini DIN cable: RCA jack and S-video port for audio/video input

TAcer DVB-T antenna (UHF/VHF reception) supporting Acer SignaUpTM wireless technology

Audio

TAudio system with two built-in Acer 3DSonic (1.5W) stereo speakers and one Acer BasSonic

Subwoofer

TDolby®Digital Live and DTS Neo: PC support

TIntel®High Definition audio support

TS/PDIF (Sony/Philips Digital Interface) support for digital speakers (1.5W)

TSound Blaster ProTM and MS Sound compatible

TTwo built-in stereo microphone

Storage subsystem

TOne or two 80/100/120 GB Serial ATA hard disk drive, supporting software RAID 0/1

TOptical drive options: DVD-Super Mulit double-layer drive (slot-load)

T5-in-1 card reader, supporting Secure Digital (SD), MultiMediaCard (MMC), Memory Stick®(MS),

Memory Stick PROTM (MS PRO), xD-Picture CardTM (xD)

Input devices

T88/89-key Acer FineTouchTM keyboard with 5-degree curve

TTouchpad with 4-way scroll button

TFour easy-launch buttons

TTwo front-access switches: WLAN LED and Bluetooth®LED-switches (for selected models)

Communication

TAcer Video Conference, featuring Voice and Video over Internet Protocol (VVoIP) support via Acer

OrbiCamTM and optional Acer Bluetooth®VoIP phone

TAcer OrbiCamTM 1.3 megapixel CMOS camera, featuring:

t30 degree ergonomic rotation

tAcer VisageOnTM technology

Chapter 1 3

tAcer PrimaLiteTM technology

TModem: 56K ITU V.92 modem with PTT approval; wake-on ring ready

TLAN: gigabit Ethernet; wake-on-LAN ready

TWPAN: Bluetooth®2.0+EDR (Enhanced Data Rate)

TWLAN: Intel®PRO/Wireless 3945ABG network connection (dual-band tri-mode 802.11a/b/g) Wi-

Fi®CERTIFIEDTM solution, supporting Acer SignalUpTM wireless technology

I/O Ports

TExpressCardTM/54 slot

TPC Card slot (one Type II)

T5-in-1 card reader (SD/MMC/MS/MS PRO/xD)

TFour USB 2.0 ports

TDVI-D port with HDCP support

TIEEE 1394 port

TConsumer infrared (CIR) port

TFast infrared (FIR) port

TExternal display (VGA) port

TS-video/TV-out (NTSC/PAL) port

TAV-in port

TTV-tuner antenna-in port

THeadphones/speaker/line-out port with S/PDIF support

TMicrophone-in jack

TLine-in jack

TParallel port

TSerial port

TEthernet (RJ-45) port

TModem (RJ-11) port

TDC-in jack for AC adaptor

NOTE: HDCP is acronym for High-bandwidth Digital Content Protection. An encryption system for enforcing

digital rights management (DRM) over DVI and HDMI interfaces

Environment

TTemperature:

toperating: 5 C to 35 C

tNon-operating: -20 C to 65 C

THumidity (non-condensing):

toperating: 20%~80%

tNon-operating: 20%~80%

°°

4Chapter 1

System Block Diagram

M P.59

A P.2

T P.1

I P.3 I P.3

HDD

PATA

M P.53

LPC47N217

OPTION

M P.38

M P.39

M P.38

M P.37

M P.38

M P.50

M P.60

M P.13

M P.25

M P.26

M P.52

M P.18

M P.49

M P.47

M P.53

M P.39M P54 & I P.1 M P.55 M P.46 M P.51

M P.56

A P.1

M P.60

M P.46

M P40-44

M P.62

I P.2

M P.57

M P.58

M P.59

SATA

USB2.0 PORT

MDC

MAX_9713

LPC 3.3V 33MHZ

AV IN

M P.28-31

PORT

652 BGA

LINE OUT

North Bridge

1466 uFCBGA

SUPER I/O & KBC

ANT

Jack

Two

M P.30

HDD

CardBus

OPTION

M P.53

HD Codec

HP Jack

M P.53

M P.51

PRINTER

SIZE

PCI Bus

TITLE

Audio Board

Controller

M P32-36

HDD

Controller

ANT

8 Cell

SIL3512E

USB 2.0

RAID

I/O BOARD

KB / LED

MAX_MAX9714

88E8055

MINI PCI

MIC IN

Batt Charger

HDCP

ROM

M P.48

M P.45

MDC 1.5

M P.57

I P.3

CPU

YONAH/MEROM

(No USB)

PORT

M P19-24

M P.14-17

BIOS

\SPDIF\

INTEL PRO

Jack

DSC

COM

CONN

PCIE

LOM

PCI_Express Bus

2 PICK BUTTON/

4 WAY

DVI

Azalia

VRAM

CODE

DDR2 533/667

CD-ROM

DDR2_SODIMM0

DDR2_SODIMM1

MS,MS-P,SD.SD-IO,XD,MMC

BLUETOOTH

MIC

ADM1032

HDMI

Sub

NVG73M/G72MV

CLK GEN

Express Card

* 8(4) PCS

MAX

ICS9LPR316

Woofer

SATA

WIRELESS 3945ABG

KBC1122

REAL_ALC883DD-GR

31W/34W

Ultra ATA-100

6 IN 1 SLOT

VGA

South Bridge

ANT

PSB

SATA

9722

S-Video

LPC 3.3V 33MHZ

CIR / FIR

TOUCH PAD

LINE IN

Internal Array

LCM

MARVELL

Controller

DOC. NUMBER

DDR2 533/667

RJ45

RJ11 CNTR

MAIN BATT

CRT

THERMAL SENSOR

1394 CONN X 1

& FAN

Speakers

TV TUNER

Calistoga

1.5*3A TAPE

ICH7-M

Azalia

SMSC

TI PCI7412

Aspire 9800

A3 Model_No 000

AMP

Mini Card

VER 2.0

PCMCIA

TYPE II

Mini Card

HDD

DMI

PWR Board

SUPPORT 0,1

Autres manuels pour Aspire 9800

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Acer Ordinateur portable

Acer

Acer Aspire 5517 Manuel utilisateur

Acer

Acer TravelMate 350 Manuel utilisateur

Acer

Acer Aspire 7740 Series Manuel utilisateur

Acer

Acer Aspire 9800 Manuel utilisateur

Acer

Acer Aspire 5670 Guide de configuration

Acer

Acer TravelMate P4 Manuel utilisateur

Acer

Acer Aspire 3000 Series Guide de configuration

Acer

Acer TravelMate 520 Series Manuel utilisateur

Acer

Acer Aspire 7551 Manuel utilisateur

Acer

Acer Aspire 3650 Manuel utilisateur

Acer

Acer Aspire E1 Series Manuel utilisateur

Acer

Acer TravelMate 220 series Manuel utilisateur

Acer

Acer Aspire V7-582 Manuel utilisateur

Acer

Acer TravelMate 8210 Guide de configuration

Acer

Acer TravelMate 3040 Series Guide de démarrage rapide

Acer

Acer Extensa 5420 Manuel utilisateur

Acer

Acer TravelMate 660 series Guide de configuration

Acer

Acer TravelMate C100-Series Instructions d'utilisation

Acer

Acer TravelMate 4230 Series Manuel utilisateur

Acer

Acer ASPIRE 5741 series Manuel utilisateur

Acer

Acer TravelMate 620 Series Manuel utilisateur

Acer

Acer TravelMate 7750G Manuel utilisateur

Acer

Acer SF314-43 Manuel utilisateur

Acer

Acer A315-59-51BL Manuel utilisateur

Manuels Ordinateur portable populaires d'autres marques

HP ze2401xt - Pavilion Notebook PC Manuel utilisateur

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Dell

Dell Alienware 17 R2 Manuel utilisateur

Toshiba

Toshiba A105-S2236 Manuel utilisateur

HP ENVY 17 Manuel

Winbook

Winbook LM Manuel utilisateur

Dell

Dell Inspiron 1464 Manuel utilisateur

Dell

Dell Inspiron 15R 5537 Manuel utilisateur

HP PROBOOK 4520S Manuel

Dell

Dell Latitude ATG D620 Manuel utilisateur

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Dell

Dell Latitude 7310 Manuel utilisateur

Dell

Dell Precision GU806 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

HP Compaq tc4200 Guide de démarrage rapide

Toshiba

Toshiba mini NB300 Manuel utilisateur

Lenovo

Lenovo ThinkPad X201 Tablet Manuel
