Acer AS3750/AS3750G

SERVICEGUIDE

Revision History

Refer to the table below for the updates made to this AS3750/AS3750G service guide.

Service guide files and updates are available on the ACER/CSD Website. For more

information, go to http://csd.acer.com.tw.

Disclaimer

The information in this guide is subject to change without notice.

There are no representations or warranties, either expressed or implied, with respect to the

contents hereof and specifically disclaims any warranties of merchantability or fitness for any

particular purpose. The software described in this manual is sold or licensed "as is". Should

the programs prove defective following their purchase, the buyer (not the manufacturer,

distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any

incidental or consequential damages resulting from any defect in the software.

reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any

language or computer language, in any form or by any means, electronic, mechanical,

magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer

Incorporated.

Conventions

The following conventions are used in this manual:

WARNING:

Indicates a potential for personal injury.

CAUTION:

Indicates a potential loss of data or damage to equipment.

IMPORTANT:

Indicates information that is important to know for the proper completion of a

procedure, choice of an option, or completing a task.

The following typographical conventions are used in this document:

Book titles, directory names, file names, path names, and program/process names are shown in

italics.

Example:

the DRS5 User's Guide

/usr/local/bin/fd

Date Chapter Updates

iii

the /TPH15spool_M program

Computer output (text that represents information displayed on a computer screen, such as

menus, prompts, responses to input, and error messages) are shown in constant width.

Example:

[01] The server has been stopped

User input (text that represents information entered by a computer user, such as command

names, option letters, and words) are shown in constant width bold.

Variables contained within user input are shown in angle brackets (< >).

Example:

At the prompt, type run <file name> -m

Keyboard keys are shown in bold italics.

Example:

After entering the data, press Enter.

General information 0

Before using this information and the product it supports, read the following general

information.

This service guide provides you with all technical information relating to the basic configuration

for Acer’s global product offering. To better fit local market requirements and enhance product

competitiveness, your regional office may have decided to extend the functionality of a

machine (such as add-on cards, modems, or extra memory capabilities). These localized

features are not covered in this generic service guide. In such cases, contact your regional

offices or the responsible personnel/channel to provide you with further technical details.

When ordering FRU parts: Check the most up-to-date information available on your regional

Web or channel. If, for whatever reason, a part number change is made, it may not be noted

in this printed service guide.

Acer-authorized Service Providers: Your Acer office may have a different part number code

than those given in the FRU list in this service guide. You must use the list provided by your

regional Acer office to order FRU parts for repair and service of customer machines.

Hardware Specifications and Configurations 1-1

Hardware Specifications and Configurations

Features 0

The following is a brief summary of the computer’s many features:

Operating System 0

Windows 7 Home Premium 64bit

Windows 7 Home Basic 64bit

Platform 0

Intel®Core i5-2410M/Core i3-2310M (3 MB L2 cache, supporting Intel®64

architecture, Intel®Smart Cache)

Mobile Intel®HM65 Express Chipset

System Memory 0

Dual-channel DDR3 SDRAM support:

Up to 4 GB of DDR3 system memory, upgradable to 8 GB using four soDIMM

modules

Display 0

13.3" HD 1366 x 768 resolution, LED-backlit TFT LCD

16:9 aspect ratio

Graphics 0

Core i3 integrated

Intel HD Graphics with Dynamic Frequency

Intel Quick Sync Video

Intel InTRU 3D Technology

Intel Wireless Display

Intel Flexible Display Interface (Intel FDI)

Intel Clear Video HD Technology

Dual Display Capable

NVDIA GT520M

NVIDIA Optimus Technology

Hardware Video Decode Acceleration

NVIDIA Verde Drivers

NVIDIA PhysX-ready

NVIDIA CUDA? Technology

1-2 Hardware Specifications and Configurations

Microsoft DirectX 11

Storage Subsystem 0

Hard disk drive 0

250/320/500/640/750 GB at 6.0Gb/s data transfer rate

Multi-in-1 card reader(Realtek-RTS5209-GR), supporting: 0

SD™, MMC, MMCplus™, MS, MS PRO, xD

Audio Subsystem 0

Realtek ALC271X-VB3-GR

Optical Media Drive 0

DVD-Super Multi double-layer drive:

Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X

DVD+R, 8X DVD-ROM DL, 8X DVD-R DL, 8X DVD+R DL, 8X DVD-RW, 8X

DVD+RW, 5X DVD-RAM

Write: 24X CD-R, 24X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-R DL, 6X DVD+R

DL, 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM

Communication 0

Webcam 0

1.3M pixs UVC CAM

Wireless and networking 0

WLAN:

802.11b/g/n Wi-Fi CERTIFIED™

WPAN:

Bluetooth®3.0

LAN:

Atheros/ AR8151 PCI-E Gigabit Ethernet, Wake-on-LAN ready

Privacy Control 0

BIOS user, supervisor, HDD passwords

Kensington lock slot

Hardware Specifications and Configurations 1-3

Dimensions and Weight 0

Dimensions 0

383 (W) x 321(D) x 81(H) mm (15.07 x 12.64x3.12 inches)

Weight 0

3.6356 kg (8.00 lbs.) with 8-cell battery

Power Adapter and Battery 0

ACPI 3.0 CPU power management standard: supports Standby and Hibernation

power-saving modes

Power adapter 0

3-pin 65 W (for UMA)/90 W (for DIS) AC Adapter

Battery 0

3S2P 5800 mAh 6-cell Li-ion standard battery pack

Battery life: 5.1 hours

Special Keys and Controls 0

Keyboard 0

86-/87-/91-key international language support

Touchpad 0

Multi-gesture function, supporting two-finger scroll, pinch, rotate, flip

I/O Ports 0

Multi-in-1 card reader (SD™, MMC, MMCplus™, MS, MS PRO, xD)

2 USB 2.0 ports

1 USB 3.0 port

HDMI®port with HDCP support

External display (VGA) port

Headphone support combo jack

Line-in jack/MIC in jack

Ethernet (RJ-45) port

DC-in jack for AC adapter

1-4 Hardware Specifications and Configurations

Optional Items 0

6 cell Li-ion battery pack

3-pin 65W (for UMA)/90W (for DIS) AC adapter

Power Cord

Software 0

Productivity 0

Acer Backup Manager (V3.0.0)

Adobe Reader v9.1

Adobe Flash Player

AUPEO

Bing Bar

BingSetup

NOOK for PC

KOBO

Office 2010

Silverlight

NY Times Reader

Norton Online Backup

eSobi (Acer v2.0.4)

Security 0

MyWinLocker Suite v4

McAfee Internet Security Suite WW

McAfee Virus Definitions

Multimedia 0

clear.fi v1.0 Client

Acer Crystal Eye Webcam

clear.fi v1.0

NTI Media Maker v9.0

Gaming 0

Oberon Game Zone Acer Edition

Wild Tangent Acer Edition

WildTangent_Remove_Zuma

Hardware Specifications and Configurations 1-5

Communication and ISP 0

Skype™

Windows Live™ Essentials

Web links and utilities 0

Acer Accessory Store

Netflix Shortcut

eBay®shortcut

Environment 0

Temperature:

Operating: 0 °C to 40 °C

Non-operating: -20 °C to 60°C

Humidity (non-condensing):

Operating: 20% to 80%

Non-operating: 20% to 80%

1-6 Hardware Specifications and Configurations

Notebook Tour 0

This section provides an overview of the features and functions of the notebook.

Top View 0

Figure 1-1. Top View

Table 1-1. Top View

No Icon Item Description

1 1.3M pixs UVC CAM Web camera for video communication. (only for

certain models)

2 Microphone Internal microphone for recording sound.

3 Display screen Also called Liquid-Crystal Display (LCD),

displays computer output (configuration may

vary by model).

4 Power button Turns the computer On and Off.

5 Keyboard For entering data into computer

6 Touchpad Touch-sensitive pointing device which functions

like a computer mouse.
