Acer VERITON 7600 Manuel utilisateur

Veriton 7600 series

User’s guide

WU8711tfsjft`FO/cppl!!Qbhf!j!!Uivstebz-!Bqsjm!4-!3114!!5 55!QN

Changes may be made periodically to the information in this publication without obligation

to notify any person of such revision or changes. Such changes will be incorporated in new

editions of this manual or supplementary documents and publications. This company makes

no representations or warranties, either expressed or implied, with respect to the contents

hereof and specifically disclaims the implied warranties of merchantability or fitness for a

particular purpose.

Record the model number, serial number, purchase date, and place of purchase information in

the space provided below. The serial number and model number are recorded on the label

affixed to your computer. All correspondence concerning your unit should include the serial

number, model number, and purchase information.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in

any form or by any means, electronic, mechanical, photocopy, recording, or otherwise,

without the prior written permission of Acer Incorporated.

Model Number : _________________________________

Serial Number: ___________________________________

Purchase Date: ___________________________________

Place of Purchase: ________________________________

Veriton 7600!series

User’s guide

Original Issue April 2003

Acer and the Acer Logo are registered trademarks of Acer Inc. Other company’s product

names or trademarks are used herein for identification purposes only and belong to their

respective companies.

WU8711tfsjft`FO/cppl!!Qbhf!jj!!Uivstebz-!Bqsjm!4-!3114!!5 55!QN

iii

1 First things first 1

System specifications 5

Package contents 6

Accessing the user’s guide 7

2 System tour 9

Features 12

Performance 12

Multimedia 12

Connectivity 12

Front panel 14

Rear panel 16

Keyboard 18

Programmable keys 19

Internet/Suspend keys 20

Multimedia keys 21

Volume control/Mute knob 22

Lock keys 23

Cursor keys 24

Windows keys 25

Function keys 26

Palm rest 26

Optical drive 27

Hard disk 29

3 Setting up your computer 31

Arranging a comfortable work area 34

Adjusting your chair 34

Positioning your PC 34

Positioning your monitor 35

Positioning your keyboard 35

Positioning your mouse 36

Connecting peripherals 37

Connecting your mouse 37

Connecting your keyboard 39

Connecting a monitor 41

Connecting the power cable 42

Turning on your computer 43

Turning off your computer 44

Connecting options 45

WU8711tfsjft`FO/cppl!!Qbhf!jjj!!Uivstebz-!Bqsjm!4-!3114!!5 55!QN

Connecting your printer 45

Connecting the modem (optional) 46

Connecting to the network 47

Connecting multimedia devices 48

Connecting USB devices 51

4 Upgrading your computer 53

Installation precautions 56

ESD precautions 56

Preinstallation instructions 56

Post-installation instructions 57

Opening your computer 58

To remove the side panel 58

To replace the side panel 59

Internal components 61

System boards 62

Mainboard layout 62

Audio board 66

Upgrading your computer 67

Installing additional memory 67

Replacing the hard disk 69

Installing an expansion card 71

5 System utilities 75

Acrobat Reader 79

Acer LANScope (optional) 80

Norton AntiVirus 81

NTI CD-Maker (for models with CD-RW) 83

PowerDVD (for models with DVD) 85

BIOS utility 86

Reinstalling programs 87

Recovering your system 88

Using Backup (Windows XP only) 92

Disk Defragmenter (Windows XP only) 93

6 Frequently asked questions 95

Frequently asked questions 98

WU8711tfsjft`FO/cppl!!Qbhf!jw!!Uivstebz-!Bqsjm!4-!3114!!5 55!QN

Appendix A: Notices 101

Appendix B: Taking care of your computer 107

Important tips 108

Cleaning and servicing 108

Asking for technical assistance 109

Index 111

WU8711tfsjft`FO/cppl!!Qbhf!w!!Uivstebz-!Bqsjm!4-!3114!!5 55!QN

WU8711tfsjft`FO/cppl!!Qbhf!wj!!Uivstebz-!Bqsjm!4-!3114!!5 55!QN

1 First things first

WU8711tfsjft`FO/cppl!!Qbhf!2!!Uivstebz-!Bqsjm!4-!3114!!5 55!QN

WU8711tfsjft`FO/cppl!!Qbhf!3!!Uivstebz-!Bqsjm!4-!3114!!5 55!QN

This chapter describes the system specifications

and the contents of your computer package .

WU8711tfsjft`FO/cppl!!Qbhf!4!!Uivstebz-!Bqsjm!4-!3114!!5 55!QN

1 First things first4

System specifications

Component Specification

Processor • Intel Pentium®4 1.8 - 3.6 GHz

• Intel Celeron®2.0 - 2.6 GHz

System memory Four SDRAM slots support a maximum of 4 GB dual-

channel DDR memory

Chipset • Intel MCH 865G

• Intel MCH 865PE

Graphics Intel MCH 865G on-die VGA card supporting:

• DVMT technology

•DualView

• 1 optional VGA port on rear

Intel MCH 865PE supporting:

• Add-on VGA card

Audio AC97 Codec

LAN Broadcom 5705 supporting 10/100/1000 MB

connectivity

IDE 40 pin parallel ATA IDE slot

FDD 1.44 MB 3.5 inch floppy drive

PS2 • PS2 keyboard port

• PS2 mouse port

USB Six external USB 2.0 ports

Serial port One serial port

Printer port One parallel printer port

Debug One 4 LED port

Thermal Dynamic fan speed control

WU8711tfsjft`FO/cppl!!Qbhf!5!!Uivstebz-!Bqsjm!4-!3114!!5 55!QN
