USER MANUAL
AIR PUMP
HYDROPONIC AERATION SYSTEM
3
WELCOME
Thank you for choosing AC Infinity. We are committed to product quality and friendly
customer service. If you have any questions or suggestions, please don’t hesitate to
contact us. Visit www.acinfinity.com and click contact for our contact information.
EMAIL
support@acinfinity.com
WEB
www.acinfinity.com
LOCATION
Los Angeles, CA
4
PRODUCT
HYDROPONIC AIR PUMP 1
HYDROPONIC AIR PUMP 2
HYDROPONIC AIR PUMP 4
MODEL
AC-AUS21
AC-AUS42
AC-AUS44
UPC-A
819137023697
819137023703
819137023758
MANUAL CODE AP2207X1
5
MANUAL INDEX
Manual Index .................................................................................
Product Warning ............................................................................
Product Contents ...........................................................................
Key Features .................................................................................
Installation .....................................................................................
Maintenance ..................................................................................
Programming .................................................................................
Other AC Infinity Products .............................................................
Warranty ........................................................................................
Page 5
Page 6
Page 7
Page 8
Page 9
Page 11
Page 12
Page 13
Page 14
6
PRODUCT WARNING
DO NOT SUBMERGE IN WATER. Do not use the air pump if it gets wet in
areas not intended to be wet.
DO NOT block the intake air vent below the control knob.
DO NOT place the air pump near flammable or other dangerous materials
or objects.
Place the air pump horizontally and at water surface height to prevent
water siphoning.
DO NOT allow water to run along the power cord and enter the outlet. See
page 10 to learn how to create a drip loop.
1.
2.
3.
4.
5.
7
PRODUCT CONTENTS
AIR
PUMP
(x1)
AC-AUS21
AC-AUS42
AIR
STONE
(x1)
CHECK
VALVE
(x1)
AIR
TUBE
(x1)
AIR
PUMP
(x1)
AIR
STONE
(x2)
CHECK
VALVE
(x2)
AIR
TUBE
(x2)
8
KEY FEATURES
TOTAL CONTROL
Fully adjustable turn dial
maintains optimal airflow
levels for many applications.
ONE WAY AIRFLOW
Check valve ensures one direction
air pumping to prevent water from
siphoning back into the pump.
VERSATILE
Flexible air tube provides
precise air routing and enables
flexible installation options.
ENERGY-EFFICIENT
Cutting-edge design conserves
power and cuts costs for
hydroponic and irrigation systems.
ULTRA-QUIET
High-powered motor can
continuously run while
maintaining low-noise operation.
HIGH AIRFLOW
Tubing and airstone boost
aeration and increase dissolved
oxygen levels to improve growth.
9
INSTALLATION
STEP 2
Cut the air tube at about 6 inches in length
from the nozzle.
STEP 1
Connect the air tube to the nozzle at the
back of your air pump.
6 IN.
10
INSTALLATION
STEP 4
Connect the air stone to the air tube, then
submerge it in your water container. Make
sure to place the air stone lower than your
air pump. Create a drip loop to ensure no
risk of electrical shock.
Larger air stones will require a higher liters-
per-minute output for optimal performance.
STEP 3
Insert the check valve in between the cut air
tubes. Check that its arrow is pointing away
from the pump to prevent water backflow.
DRIP LOOP
