Abode AECRD2002 Manuel utilisateur

Model number(s):

AECRD2002

Electric Clothes Airer

Instruction Manual

IMPORTANT:

RETAIN FOR FUTURE REFERENCE

For Customer Services & Spare Parts please call 0345 209 7461

Contents

Safety Instructions ………………………………………. 3-4

Product Overview ………………………………………. 5

Usage ………………………………………. 6-7

Cleaning & Maintenance ………………………………………. 8

Trouble shooting ………………………………………. 8

Guarantee ………………………………………. 9

Technical specification ………………………………………. 10

Connections to the Mains ………………………………………. 11

Safety Instructions

Important note:

Please read this booklet before installing and switching on this appliance.

The manufacturer assumes no responsibility for incorrect installation and

usage as described in this booklet.

This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand

the hazards involved. Children shall not play with the appliance.

•Children should be supervised to ensure that they do not play with the

appliance.

•If the supply lead is damaged it must be replaced by a qualified person

using the correct lead, available from 0345 209 7461.

•Packaging material is dangerous to children. Never allow children to play

with packaging material.

•Check the appliance for damage after unpacking it. Do not connect the

appliance if it has been damaged in transport.

•The appliance can only be used safely if it is correctly installed according

to the safety instructions. The installer is responsible for ensuring that

the appliance works correctly after installation.

•A defective appliance may cause electric shock. Never switch on a

defective appliance. Unplug the appliance from the mains or switch off

the circuit breaker in the fuse box. Contact the customer services.

•The appliance is not intended to be operated by means of an external

timer or separate remote control system.

•This appliance is intended for domestic use and the household

environment only. The appliance is not intended for use outside.

Safety Instructions

•Do not tamper with the appliance. If necessary, call our customer

helpline.

•Do not switch on the appliance if it is damaged in any way. Contact our

customer helpline.

•Do not leave the appliance unattended during operation. The

manufacturer is not liable for damage which is caused by improper use

or incorrect operation.

•The accessible parts become very hot when in operation. Never touch

hot parts. Keep children at a safe distance.

•In the event of a malfunction, turn off the appliance’s electricity

supply. For repairs, call customer services.

•Ensure that your mains voltage corresponds to that stated on the

appliance.

•The appliance should be connected to an earthed main socket.

•Before cleaning, always unplug the appliance from the power supply.

•Repairs can only be undertaken by a competent qualified electrician.

•This appliance is intended only for drying textiles washed in water.

Product Overview

Unit & Spare Parts

If any of the above parts are missing please contact the customer service team on

0345 209 7461.

1. Upper wings

2. Middle wings

3. Lower wings

4. Legs

5. Locking arms

6. Drying poles

7. Power switch

8. Shoe drying poles

9. Cover

Usage

Note: When opening/unfolding and closing/folding the clothes airer then please

be careful to not trap your fingers or hands.

To use the clothes airer please follow the below steps:

1. Unfold the clothes airer so it is slightly open (approximately 30⁰), ensuring the

clothes airer is fully upright and placed on a stable floor.

2. Unfold each drying wing and ensure they are fully open/horizontal and the

arms are locked in position. Be careful to not trap your fingers or hands.

Usage

Note: When opening/unfolding and closing/folding the clothes airer then please

be careful to not trap your fingers or hands.

3. Plug the appliance into an earthed mains socket. Locate the power switch

which is on the side of the unit and press the switch to the ON position, the

light will illuminate. After a short period of time (approximately 5-10 mins) the

electric clothes rack will reach its operation temperature. Put the laundry on

the airer as required and if required place the cover over the airer and the

clothes (by using the cover the laundry should dry faster).

4. Switch off after use. Allow to cool down before closing/unfolding. Be careful to

not trap your fingers or hands.

Max load (kg) Total –15kg

Single layer –5kg

Cleaning and Maintenance:

How to clean:

•Clean the surface of each pole with a warm damp cloth and allow to dry.

Trouble Shooting:

Problem

Solution

The appliance doesn't work

Check that the appliance is switched on.

Check that there has not been a power cut.

Check that the plug is not

faulty.

Check that the fuse has not blown.

Check that the voltage is correct for the appliance.

Guarantee

This product is guaranteed for 12 months from the date of the original

purchase. If any defect arises due to faulty materials or workmanship you

must contact customer services with the original proof of purchase so a

replacement or refund can be arranged.

Refund or replacement is at the discretion of Customer Services.

The following conditions apply:

•Customer Services will require a valid proof of purchase at the point of

replacement or refund.

•The product must be installed and used in accordance with the

instructions contained in this instruction guide and any other

instructions for use which has been supplied.

•It must be used for domestic purposes only and for its intended use.

•This guarantee does not cover wear and tear, damage, misuse or

consumable parts.

This does not affect your statutory rights.

For Customer Services & Spare Parts please call 0345 209 7461

Technical Specification

Model number AECRD2002

Rated Voltage 220V –240V ~ 50Hz

Wattage 300W

IP rating IP21

Temperature range 45 - 55⁰C

Max load (kg) Total –15kg

Single layer –5kg

Unfolded Dimensions (H x W x D) (CMS) 135cm x 66cm x 72.8cm

Folded Dimensions (H x W x D) (CMS) 140cm x 66cm x 7.2cm
