ABB XLP-BB Manuel utilisateur

PRODUCT MANUAL

VMS - LV modular system

XLP-BB

2CDC508200D0111 Rev B

Contents

1 Icons.................................................................................................................................... 3

2 Material...............................................................................................................................4

2.1 Material - included............................................................................................................................. 4

2.2 Material - not included......................................................................................................................4

2.2.1 Accessories................................................................................................................................ 4

3 Assembly steps................................................................................................................. 5

Additional drawings and instructions can be found in the ABB Library:

1Icons

Icon Description

Warning / Caution

Note

Material - included

Material - not included

Tools

Tightening torque (Nm)

2Material

2.1Material - included

Box with busbar support and IP cover plate SKU-codes Description

4TBV853214C0100

4TBV853221C0100

4TBV853222C0100

4TBV853223C0100

4TBV853224C0100

4TBV853225C0100

4TBV853230C0100

4TBV853231C0100

4TBV853238C0100

4TBV853634C0100

VMS 32H w. 60mm BB 250/400A for DIN00

VMS 33 w. 60mm BB 250/400A for DIN00 /D

VMS 63H w. 60mm BB 250/400A for DIN00 /D

VMS 63V w. 60mm BB 250/400A for DIN00/D top

VMS 63V w. 60mm BB 250/400A for DIN00/D bot

VMS 63V w. 60mm BB 400A for DIN1 3p top

VMS 63V w. 60mm BB 400A for DIN1 3p bot

VMS 64V w. 60mm BB 400A for DIN1 3p top

VMS 64V w. 60mm BB 400A for DIN1 3p bot

VMS 43H w. 60mm BB 250/400A for DIN00 /D

2.2Material - not included

2.2.1Accessories

Nr. 1 Nr. 2

Nr. 3

Nr. 4 Nr. 5

Item nr. Accessory SKU Accessory Description

1 2CPX062374R9999 Reserve section cover - Z

2 4TBV854313C0100 Reserve section cover - flat

3 2CPX062952R9999 Front frame 1x XLP00

4 2CPX062953R9999 Front frame 2x XLP00

5 4TBV854306C0100 Trim frame VMS

3Assembly steps

1. Material: overview

1 VMS base

2 Cover

3 Cover screws (4)

4 Busbars

5 Front frame or Trim

frame

6 Bus-mounted fuse

base or Fuse switch

disconnector(s)

7 Reserve section cover

2. Remove IP cover plate and then the top part

of the busbar supports

1 Cover plate screws (4x)

2 IP cover plate

3 Busbar supports (2x)

3. Break "walls" and place blocks (where

necessary for busbars with thickness of 5

mm)

1 Busbar support "walls"

2 Busbar blocks

4. Place busbars and remount the busbar

supports

1 Busbars

2 Busbar supports

5. Mounting Bus-mounted fuse base on busbars

(A) or mounting Fuse Switch Disconnector on

busbars (B)

1 Bus-mounted fuse

base

2 Busbars

If copper width of PE or N =12 mm,

use the following configuration:

If copper width of PE or N >12 mm,

use the following configuration:

(remove side panels and break small

walls to obtain a 10 mm opening.)

See Installation Instruction of

fuse switch disconnectors on

how to open the device, enabling

connections of cables:

1 Fuse switch discon-

nector(s)

2 Busbars

XLP 00/1-A60/60...

XLP00

XLP1

6. Insert Frames and Cover plate

Insert the Trim frame VMS

in the IP cover plate and re-

install the assembly onto

the VMS box. Check first

needed width of trim frame

VMS and break off where

necessary.

1 Trim Frame

2 IP cover plate

3 Cover plate screws (4x)

First place front frame Xx XLP00

around device(s), then mount

reserve section cover - Z onto

the IP cover plate and reinstall

this assembly onto the VMS box.

1 Front frame

2 Reserve section cover - Z

3 IP cover plate

4 Cover plate screws (4x)

- When using 1x XLP00, use

Front frame 1x XLP00 and close

opening with adjusted Reserve

section covers - flat.

- When using 1x XLP1, no addi-

tional accessories are needed.

1 Reserve sections covers - flat

7. Fastening VMS box cover

1. Snap cover screws each time in the four corners.

2. Fit cover on box (one turn on screws, max. 2.5Nm).

3. If necessary, stick total isolation symbol on cover.

8. Installation complete
