AC500-S

Usage of AC500 Digital Standard I/Os

in Functional Safety Applications

up to PL c (ISO 13849-1)

Application Note

Application Note for “Usage of AC500 digital standard I/Os in functional safety applications up to PL c (ISO 13849-1)”, V1.0.0

Page 2/24

We reserve all rights in this document. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. Ó2015 ABB Ltd.

Contents

1Introduction _____________________________________________________3

1.1 Purpose .............................................................................................................................3

1.2 Document history...............................................................................................................4

1.3 Validity...............................................................................................................................4

1.4 Important user information..................................................................................................4

1.5 Definitions, expressions, abbreviations...............................................................................4

1.6 References / Related documents........................................................................................5

2Usage of digital standard I/Os in functional safety applications up to PL c _____6

2.1 Overview............................................................................................................................6

2.2 Task...................................................................................................................................8

2.3 Solution..............................................................................................................................8

3Example ______________________________________________________14

3.1 General............................................................................................................................14

3.2 Safety function.................................................................................................................14

3.3 Functional description.......................................................................................................15

3.4 Design features................................................................................................................16

3.4.1 Implementation details 16

3.4.2 Common cause failures 18

3.4.3 Systematic failures 19

3.4.4 Safety function response time 20

3.5 Calculation of the probability of failure and correspondence to PL (ISO 13849-1)..............20

4Conclusion_____________________________________________________23

Application Note for “Usage of AC500 digital standard I/Os in functional safety applications up to PL c (ISO 13849-1)”, V1.0.0

Page 3/24

We reserve all rights in this document. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. Ó2015 ABB Ltd.

1 Introduction

1.1 Purpose

The number of used digital safety input channels in safety applications is often signifi-

cantly higher than the number of digital safetyoutput channels. In some customer PLC

applications, there are often free spare digital standard I/O channels. There is a ques-

tion if thesefree spare digital standard I/O channels can be used together with SM560-

S Safety CPU to realize functional safety functions. If yes, one could avoid using addi-

tional Safety I/O modules with digital safety input channels and, thus, save control sys-

tem costs and reduce control cabinet dimensions in some customer applications.

We analyzed a possible usage of AC500 digital standard I/Os to realize functional

safety functions. This application note describes a possible usage of digital standard

I/O modules from AC500 platform (www.abb.com/PLC) in functional safety application

up to PL c (ISO 13849-1). The functional safety calculation according to ISO 13849-1

is used as an example to show the compliance of the proposed approach with the

relevant functional safety requirements for PL c (ISO 13849-1). The functional safety

calculation according to IEC 62061 standard (applications up to SIL CL 1) can be sim-

ilarly done, if required.

In special cases, digital standard I/O modules from AC500 platform can be also used

in functional safety applications up to PL d (ISO 13849-1) and SIL CL 2 (IEC 62061).

However, more detailed functional safety application analysis is required (contact

AC500 technical support at www.abb.com/PLC for more details) and, thus, is not

shown in this document.

Application Note for “Usage of AC500 digital standard I/Os in functional safety applications up to PL c (ISO 13849-1)”, V1.0.0

Page 4/24

We reserve all rights in this document. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. Ó2015 ABB Ltd.

1.2 Document history

Rev.

Description of

version / c

hanges

Who

Date

1.0.0 Final release ABB 15.12.2015

1.3 Validity

The data and illustrations found in this documentation are not binding. ABB reserves

the right to modify its products in line with its policy of continuous product development.

ABB assumes no liability or responsibility for any consequences arising from the use

of this document information. ABB is in particular in no way liable for missed profits,

loss of income, loss of life, loss of use, loss of production, capital costs or costs asso-

ciated with an interruption to operation, the loss of expected savings or for indirect or

follow up damages or losses no matter of what kind.

1.4 Important user information

This documentation is intended for qualified personnel familiar with Functional Safety.

You must read and understand the safety concepts and requirements presented in

AC500-S Safety User Manual [1] as well as further referenced documents prior to op-

erating AC500-S Safety PLC system.

The following special notices may appear throughout this documentation to warn of

potential hazards or to call attention to specific information.

DANGER

The notices referring to your personal safety are highlighted in the

manual by this safety alert symbol, which indicates that death or

severe personal injury may result if proper precautions are not

taken.

NOTICE

This symbol of importance identifies information that is critical for

successful application and understanding of the product. Itindicates

that an unintended result can occur if the corresponding information

is not taken into account.

1.5 Definitions, expressions, abbreviations

AC500 ABB PLC, refer also to www.abb.com/PLC for further details

Application Note for “Usage of AC500 digital standard I/Os in functional safety applications up to PL c (ISO 13849-1)”, V1.0.0

Page 5/24

We reserve all rights in this document. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. Ó2015 ABB Ltd.

AC500-S ABB Safety PLC for applications up to SIL3 (IEC 61508 ed. 2 and

IEC 62061) and PL e (ISO 13849-1), refer also to

www.abb.com/PLC for further details

AB Automation Builder (ABB Automation Builder is the integrated soft-

ware suite for machine builders and system integrators which co-

vers the engineering of ABB AC500 PLC, AC500-S Safety PLC,

control panels, drives, motion and robots)

CCF Common Cause Failure

CPU Central Processing Unit

DCavg Diagnostic Coverage - average

DPRAM Dual-ported Random Access Memory

IEC International Electro-technical Commission Standard

I/O Input/Output

EMC Electromagnetic compatibility

FB Function Block

FSDT Functional Safety Design Tool (ABB tool for functional safety calcu-

lation according to ISO 13849-1 and/or IEC 62061)

MTBF Mean Time Between Failures

MTTFd Mean Time To Failure dangerous

PFH Probability of Failure per Hour (1/h)

PL Performance Level according to ISO 13849-1

PLC Programmable Logic Controller

SIL Safety Integrity Level (IEC 61508 ed. 2)

TÜV Technischer Überwachungs-Verein (Technical Inspection Associa-

tion)

1.6 References / Related documents

[1] AC500-S Safety User Manual, 3ADR025091M0204

[2] Cyclic Non-safe Data Exchange between SM560-S Safety CPU and PM5xx

Non-Safety CPU, 3ADR025195M0201

[3] BGIA Report 2/2008e, Functional safety of machine controls - Application of

EN ISO 13849

[4] AC500 Documentation, refer to www.abb.com/PLC and then navigate to

Downloads area

Application Note for “Usage of AC500 digital standard I/Os in functional safety applications up to PL c (ISO 13849-1)”, V1.0.0

Page 6/24

We reserve all rights in this document. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. Ó2015 ABB Ltd.

2 Usage of digital standard I/Os in functional safety

applications up to PL c

2.1 Overview

In this document, we discuss the usage of AC500 digital standard I/O modules on the

input side of AC500-S Safety PLC. The output side has to be implemented using safety

output modules as further explained in the notice below. SM560-S Safety CPU has to

be used for safety logic processing and diagnostic measures for digital standard I/O

modules.

NOTICE

Usage of standard output channels on standard I/O modules in

AC500 platform for functional safety applications is not considered

in this document because of the complexity of its implementation in

practice and results in very limited cost saving (two output channels

from two different standard output modules will be needed (contact

ABB technical support at www.abb.com/PLC for more details)). As

a result, safety output channels from DX581-S module [1] or built-

in drive safety functions (Safe Torque Off, Safe Stop 1, Safely Lim-

ited Speed, etc.) accessible through PROFINET / PROFIsafe [1]

shall be used on the output side of the Safety PLC.

Figure 1 gives an overview on the minimumexemplary AC500 configuration to be used

for PL c safety functions with digital standard I/O modules (PM573 standard CPU and

DC523 digital standard I/O modules are taken as examples here but other CPUs and

I/O modules from the AC500 range could also be used).

DX581-S digital safetyinput/output module is includedin Figure 1 as one of options for

Safety PLC output part (another option is the usage of PROFINET/PROFIsafe com-

munication to trigger safety functions in drives with safety option). In addition to avail-

able digital safety input channels on DX581-S, one can use digital standard I/O chan-

nels from standard I/O modules, like DC523.

Application Note for “Usage of AC500 digital standard I/Os in functional safety applications up to PL c (ISO 13849-1)”, V1.0.0

Page 7/24

We reserve all rights in this document. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. Ó2015 ABB Ltd.

Figure 1. Basic setup with AC500/AC500-S modules for usage of AC500 digital

standard I/O modules in functional safety application up to PL c

Remote digital standard I/O modules can be used as well (refer to www.abb.com/PLC

for more details on available AC500 modules).

Application Note for “Usage of AC500 digital standard I/Os in functional safety applications up to PL c (ISO 13849-1)”, V1.0.0

Page 8/24

We reserve all rights in this document. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. Ó2015 ABB Ltd.

2.2 Task

We want to show and describe an approach how AC500 digital standard I/O channels

can be used for functional safety applications up to PL c (ISO 13849-1) in combination

with SM560-S Safety CPU.

NOTICE

It is always highly recommended to use digital safety input channels

even for functional safety applications up to PL c (ISO 13849-1).

Thus, the presented approach with the usageof digital standard I/O

channels is only an option if spare digital standard I/O channels are

available and their reuse for functional safety functions up to PL c

is needed to satisfy specific customer requirements (e.g., limited

space in the control cabinet to add additional digital safetyI/O mod-

ule, cost saving, etc.).

Customer benefits from using spare AC500 digital standard I/O channels for functional

safety applications up to PL c (ISO 13849-1) are:

- Smaller control cabinet dimensions are possible

- Cost savings on additional Safety I/O modules.

2.3 Solution

The proposed solutionis based on the design analysis andadditional diagnostic safety

measures which can be implemented using AC500/AC500-S setup shown in Figure 1

to enable usage of AC500 digital standard I/O channels in functional safety applica-

tions up to PL c (ISO 13849-1).

Figure 2 shows an overview on reachable Performance Levels depending on Cate-

gory, DCavg and MTTFd values, as defined in ISO 13849-1. As one can see from

Figure 2 (see a selection in blue), one of the most attractive approaches to satisfy PL

c (MTTFd = High or Medium) and even PL d (MTTFd = High) requirements is the usage

of Category 2, DCavg = Low.

Application Note for “Usage of AC500 digital standard I/Os in functional safety applications up to PL c (ISO 13849-1)”, V1.0.0

Page 9/24

We reserve all rights in this document. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. Ó2015 ABB Ltd.

Figure 2. Relationship between Categories, DCavg, MTTFd of each channel and PL

from ISO 13849-1 with a focus on Category 2

Category 2 architecture based on ISO 13849-1 is shown in Figure 3.

Figure 3. Category 2 architecture from ISO 13849-1

Application Note for “Usage of AC500 digital standard I/Os in functional safety applications up to PL c (ISO 13849-1)”, V1.0.0

Page 10/24

We reserve all rights in this document. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. Ó2015 ABB Ltd.

Key requirements for Category 2 (ISO 13849-1) are:

- Requirements of systemB (refer to ISO 13849-1 for details) and the use of well-

tried safety principles shall apply

- Safety function shall be checked at suitable intervals by the machine control

system

- The occurrence of a fault can lead to the lossof the safety function between the

checks

- The loss of safety function is detected by the check

Category 2 architecture realization using AC500/AC500-S modules (see Figure 1) is

shown in Figure 4.

Figure 4. Category 2 equivalent architecture using AC500/AC500-S modules

As one can see from Figure 4, safety logic processing and safety output part are fully

covered by SM560-S Safety CPU (SIL3, PL e) and DX581-S digital safety input/output

module, which even significantly exceed the requirements from PL c (ISO 13849-1).

Nevertheless, we need an additional analysis for the input partin which standard (non-

safety) AC500 modules (DC523 and PM573) are used. This input part will be always

application-specific and will require additional measures to satisfy PL c requirements.

Autres manuels pour AC500-S

Table des matières

Autres manuels ABB Contrôleurs

ABB

ABB RMC-100 Guide de l'utilisateur

ABB

ABB BALDOR ACB530 Manuel utilisateur

ABB

ABB ACS550-01 Manuel utilisateur

ABB

ABB PP10 Mode d’emploi

ABB

ABB Totalflow mflo Series Guide de l'utilisateur

ABB

ABB Advant Controller 450 Manuel utilisateur

ABB

ABB AC 800M Manuel utilisateur

ABB

ABB COM600 series Manuel utilisateur

ABB

ABB ACS880-07 Manuel utilisateur

ABB

ABB MS132-K Manuel utilisateur

ABB

ABB ACS800-01 Manuel utilisateur

ABB

ABB MS116 Manuel utilisateur

ABB

ABB UMC22-FBP Manuel de la liste des pièces

ABB

ABB Relion 630 Series Manuel utilisateur

ABB

ABB Jokab Safety Safeball JSTD1 Manuel utilisateur

ABB

ABB Advant Controller 450 Manuel utilisateur

ABB

ABB PSTX30 105 Series Manuel de la liste des pièces

ABB

ABB ACS355 series Manuel utilisateur

ABB

ABB RHDE250 Manuel utilisateur

ABB

ABB ACS 600 Series Manuel utilisateur

ABB

ABB ControlMaster CMF Manuel utilisateur

ABB

ABB COM600 4.0 Manuel utilisateur

ABB

ABB TZIDC-110 Comment utiliser

ABB

ABB ControlMaster CM10 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur

3M MicroTouch EX113 Manuel utilisateur
