A&D UC-321 Manuel utilisateur

WM:PD4000285

Precision Health Scale

Model UC-321

Before Use

Precautions ................................... 1

Scale Components ........................ 2

Display Symbols ............................ 3

Installing (or Replacing) Batteries .. 3

Operations

Normal Measurement .................... 4

Memory Function ........................... 6

Target Function .............................. 8

BMI Indication .............................. 10

References

Specifications .............................. 12

Maintaining the Scale .................. 12

Before Requesting Service .......... 12

Precautions

Please read this booklet before using your scale.

Do not place your scale on a soft, wet or slippy floor.

It is recommended you place your scale on the solid and level floor.

Your scale contains delicate, high-precision parts. Avoid extremes in

temperature, humidity, direct sunlight, shock, moisture and dust.

Do not step on your scale with your feet wet so as to prevent you from

slipping and falling down. It is recommended that you step on the cen-

ter portion of your scale gently.

Do not step on the display window.

Do not open the case of the scale.

If you press and hold the measurement switch, the battery power is

consumed.

Indications for Use

The UC-321 was designed for adult use at home.

Compliance with European Directive

The scale complies with the statutory EMC (Electromagnetic Compatibility) directive 89/

336/EEC and the Low Voltage Directive 73/23/EEC. Note: The displayed value may be

adversely affected under extreme electromagnetic influences.

Scale Components

Display

OK Mark

Low Battery Mark

Front

Measurement Switch

Back

Slide Switch

Battery Compartment

The following four measurements can be selected by the function switch.

Refer to

“Normal Measurement” and “Measuring a baby or an animal”

WEIGHT

The function to measure your weight, the weight of a baby or

animal.

BMI Refer to “BMI Indication”.

The BMI is a helpful indicator of body weight condition, in adults.

Refer to “Memory Function”.

MEMORY

Up to 31 weight data can be stored in memory.

The difference from the previous result is displayed automatically.

Refer to “Target Function”.

TARGET

The difference between the preset target weight and the current

weight can be displayed.

The scale has the “automatic-power-off” function to turn the scale off after no

operation for ten seconds. Therefore, the scale has no off switch.

Function Indicator

- 2 -

Display Symbols

OK mark. This mark is displayed, when measurement display is stable.

Low battery mark. If this mark is displayed, replace the batteries with

new ones.

, Function indication. The current function is indicated.

Installing (or Replacing) Batteries

Caution

Insert each battery with its positive (+) and negative (-) terminals properly

aligned with the corresponding marks on the scale. If you fail these battery

directions, it may cause battery leakage.

Replace all four batteries with new ones, when mark is displayed.

Do not mix used and new batteries. It may cause damage to the battery or

scale, if used.

When batteries are completely drained, mark is not displayed.

The battery life is dependant upon the environmental temperature, battery

performance and usage.

Remove the batteries from the battery compartment, when the scale is not to

be used for a long time. They may leak and damage your scale.

The battery life of accessory batteries may be shorter than new ones.

Steps for Installing (or Replacing) Batteries

1Remove the battery compartment cover on the

underside of the scale by gently pushing on

the arrow and lifting the cover backward.

2Place four new batteries with the positive (+)

and negative (-) terminals properly aligned with

the corresponding marks on the scale.

3Replace the cover by sliding it into the com-

partment and gently pressing into place.

- 3 -

Normal Measurement

Measuring Your Weight

1Set the slide switch to “WEIGHT”.

2Press the measurement switch gently.

All display segments are indicated for several

seconds,thendisplaying0.00kgandthe mark..

3Step on your scale.

Step on your scale gently. When the mark

disappears, the measurement is started. Remain

still during measurement.

If the condition to display 0.00 kg is maintained

for approximately ten seconds, the scale is au-

tomatically turned off.

4Your weight can be read after the

mark is displayed.

The scale is turned off automatically after ap-

proximately five seconds.

5Step off the scale.

Slide switch Measurement switch

- 4 -

Measuring a Baby or an Animal

1Set the slide switch to “WEIGHT”.

2Press the measurement switch gently

and step on your scale.

All display segments are indicated for several sec-

onds. Step on the scale without any baby or ani-

mal in your hands before displaying 0.00 kg.

3Pick up the baby or animal and step

on the scale again.

Step on your scale with the baby and animal

within ten seconds after displaying 0.00 kg and

the mark. Remain still during measurement

until displaying mark.

4The weight of the baby or animal can

be read after displaying the mark.

The scale is turned off automatically after

approximately five seconds.

5Step off the scale.

- 5 -

The Memory Function

Up to 31 weight data can be stored in memory. The 32nd data is stored by

deleting the oldest stored data. The difference from the previous result is

displayed automatically.

Storing a Current Weight.

1Set the slide switch to “MEMORY”.

2Press the measurement switch gently.

The last weight is displayed.

3Step on your scale.

Step on your scale gently, after displaying

0.00 kg and the mark. When the mark

disappears, the measurement is started. Re-

main still during measurement.

If the condition to display 0.00 kg is main-

tained for approximately ten seconds, the

scale is automatically turned off.

4The weight can be read after the

mark is displayed.

5Step off the scale.

6The weight is stored in memory

and the difference from the last

weight is displayed.

The weight data is stored in memory

and the difference from the previous

result is displayed for approximately

five seconds. And, the scale is auto-

matically turned off.

- 6 -

Displaying Weight Data Stored in the Scale

The stored measurement data is displayed in order beginnings with the

most recent measurement.

1Set the slide switch to “MEMORY”.

2Press and hold the measurement switch

gently in the condition of turning off the

scale.

Weight data are displayed in order from the last

result. The scale is automatically turned off.

If you want to stop the display, press the mea-

surement switch.

Slide switch Measurement switch

- 7 -

The Target Function

The difference between the preset target weight and the current weight can

be displayed.

Presetting a New Target Weight

1Set the slide switch to “TARGET”.

2Press and hold the measurement switch

gently in the condition of displaying

nothing.

The last preset target weight is displayed.

3Press the measurement switch gently to

display a new target weight.

Press and hold the measurement switch to in-

crease the display, until the desired value is in-

dicated to specify a new target weight.

4Release the measurement switch to

store the new target weight, when

displaying it.

The scale is automatically turned off after dis-

playing a new target weight for approximately

five seconds.

Slide switch Measurement switch

- 8 -

Comparing a Current Weight with a Preset Target Weight

1Set the slide switch to “TARGET”.

2Press the measurement switch gently.

The stored target weight is displayed.

3Step on the scale.

Step on your scale gently after displaying

0.00kg and the mark.Whenthe mark

disappears, the measurement is started.

Remain still during measurement.

If the condition to display 0.00 kg is main-

tained for approximately ten seconds, the

scale is automatically turned off.

4The difference between the pre-

set target weight and the current

weight is displayed.

The scale is automatically turned off

after the difference has been displayed

for approximately five seconds.

5Step off the scale.

- 9 -

BMI Indication

BMI

Body Mass Index or BMI (kg/m2), based

on an individual’s height and weight, is

a helpful indicator of underweight, over-

weight or obesity, in adults.

According to the new NHLBI (National

Institutes of Health) guidelines, the BMI

score means the following list.

Underweight Below 18.5

Normal 18.5 to 24.9

Overweight 25.0 to 29.9

Obesity 30.0 and Above

Presetting Your Height

Store your height before measuring your weight to calculate the BMI.

The scale can store a height between 30 cm and 220 cm in increments of

0.1 cm.

1Set the slide switch to “BMI”.

2Press and hold the measurement switch gently

in the condition of displaying nothing.

The preset height is displayed.

3Press the measurement switch gently to dis-

play a new height.

Press and hold the measurement switch to increase the

display, until the indicated value is correct, to specify

a new target weight.

4Release the measurement switch to store a

new height, when displaying it.

The scale is automatically turned off after displaying

the new height for approximately five seconds.

- 10 -
